- Page 1 130 X ®...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury. CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury. WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superficial injury. WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby, Inc. This manual contains instructions for safety, operation and mainte- nance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. Age Recommendation: Not for children under 14 years. • Never place any portion of the model in your mouth as it This is not a toy. could cause serious injury or even death.
-
Page 3: Table Of Contents
Before you get started though, you must read this manual. As simple as the Blade 130 X is to fly, it’s still a sophisti- cated Radio Controlled flying machine that has some features and pre-flight checks you’ll need to become familiar with before you fly. Table of Contents Blade 130 X Specifications First Flight Preparation ..... 4 305mm (12.0 in) Length Flying Checklist ......4 122mm (4.8 in) - Page 4 Charging Warnings The charger included with the 130 X has been designed to safely charge the included Li-Po battery. CAUTION: All instructions and warnings must be followed exactly. Mishandling of Li-Po batteries can result in a fire, personal injury, and/or property damage. • By handling, charging or using the included Li-Po battery you assume all risks associated with lithium batteries. • If at any time the battery begins to balloon or swell, discontinue use immediately. If charging or discharging, discontinue and disconnect. Continuing to use, charge or discharge a battery that is ballooning or swelling can result in fire. • Always store the battery at room temperature in a dry area for best results. • Always transport or temporarily store the battery in a temperature range of 40–120º F (4–49º C). Do not store battery or model in a car or direct sunlight. If stored in a hot car, the battery can be damaged or even catch fire. • Always charge batteries away from flammable materials. • Always inspect the battery before charging and never charge damaged batteries. • Only use a charger specifically designed to charge Li-Po batteries. Failure to charge the battery with a compat- ible charger may cause fire resulting in personal injury and/or property damage • Always constantly monitor the temperature of the battery pack while charging. • Always disconnect the battery after charging, and let the charger cool between charges. • Never discharge Li-Po cells to below 3V under load. • Never cover warning labels with hook and loop strips. • Never leave charging batteries unattended. • Never charge batteries outside recommended levels. • Only charge batteries that are cool to the touch. • Never attempt to dismantle or alter the charger. • Never allow minors to charge battery packs. • Never charge batteries in extremely hot or cold places (recommended between 40–120° F or 4–49° C) or place in direct sunlight.
-
Page 5: First Flight Preparation
First Flight Preparation Flying Checklist ❏ Always turn the transmitter on first • Remove and inspect the box contents • Charge the flight battery ❏ P lug the flight battery into the lead from the flybarless unit • Program your computer transmitter ❏ A llow the flybarless unit to initialize and • Install the fully charged flight battery in the arm properly helicopter ❏ Fly the model • Bind your transmitter to the helicopter ❏ Land the model • Familiarize yourself with the flight controls ❏ U nplug the flight battery from the flybarless unit • Find an open area for flying ❏... -
Page 6: Programming Your Transmitter
Programming Your Transmitter Program your transmitter before attempting to bind or fly the helicopter. Transmitter programming values are shown below for the Spektrum DX6i, DX7/DX7se, DX7s and DX8. The Spektrum model files for transmitters with AirWare™ software are also available for download online in the Spektrum Community. NOTICE: When using a Futaba® transmitter with a Spektrum DSM® module, you must reverse the throttle channel. Spektrum DX6i Transmitter Setup SETUP LIST Model Type Reverse Swash Type Timer HELI THRO—N 1 Servo 90 Degree Type—Down AILE—N Time—4:00 ELEV—N Switch—Trainer RUDD—N GYRO—N PITC—R ADJUST LIST... - Page 7 Spektrum DX7/DX7se Transmitter Setup SYSTEM LIST Model Type Swash Type Input Select AUX2 GEAR HELI 1 Servo Norm INH GYRO ADJUST LIST POS-0 POS-0 POS-1 AILE ELEV RUDD AILE ELEV RUDD AUTO EXP 40% EXP 40% EXP 0% EXP 40% EXP 40% EXP 0% NORM D/R 100% D/R 100% D/R 100% D/R 85% D/R 85% D/R 100%...
- Page 8 Spektrum DX7s Transmitter Setup SYSTEM LIST Model Type Swash Type Switch Select F Mode Setup Warnings Frame Rate Helicopter 1 Servo Normal All Switches INH Flight Mode — F Mode Throttle —Over 10 22ms Hold — Hold Stunt 1—Active DSMX Hold—Active Alarm—Tone/Vibe FUNCTION LIST SERVO SETUP THROTTLE CUT TRAVEL SUB TRIM* REVERSE INHIBIT THROTTLE THROTTLE THROTTLE...
- Page 9 Spektrum DX8 Transmitter Setup SYSTEM LIST Model Switch Frame Swash Type F Mode Setup Trim Step Warnings Type Select Rate 1 Servo All Switches Flight Mode — Helicopter THR 5 Throttle —Over 10 22ms Normal F Mode Hold — Hold AIL** 0 Stunt 1—Act DSMX ELE** 0 Stunt 2—Act RUD** 0 Hold—Act R TRIM 0 Alarm—Tone/Vibe L TRIM 0 TYPE Common **Changing trim step to zero disables the trim for that channel.
-
Page 10: Transmitter And Receiver Binding
Transmitter and Receiver Binding Binding is the process of programming the receiver of the control unit to recognize the GUID (Globally Unique Identifier) code of a single specific transmitter. You need to bind your chosen Spektrum DSM transmitter to ™ ® the flybarless unit before flying the helicopter. General Binding Procedure 1. Disconnect the flight battery from the helicopter. 2. Power off the transmitter and make sure the flight mode switch is in the Normal position. Move the throttle to the low/off position. 3. Connect the flight battery to the flybarless control unit. The LED on the flybarless unit flashes after 5 seconds. 4. Put the transmitter into bind mode while powering on the transmitter. 5. Release the bind button after 2–3 seconds. The helicopter is bound when the blue LED on the flybarless unit is solid. 6. Disconnect the flight battery and power the transmitter off. CAUTION: Futaba transmitters equipped with Spektrum modules require you to reverse the throttle channel. If you encounter problems, obey binding instructions and refer to the troubleshooting guide for other instructions. If needed, contact the appropriate Horizon Product Support office. -
Page 11: Installing The Flight Battery
Installing the Flight Battery 1. Lower the throttle. 2. Power on the transmitter. 3. Center the throttle trim. 4. Turn throttle hold on and move the flight mode switch to select Normal mode. 5. Install the flight battery in the battery holder. Connect the battery cable to the ESC. CAUTION: Always keep the power lead positioned AWAY from the elevator servo. Failure to do so could cause the lead to get caught, resulting in a crash causing property damage and injury. 6. Do not move the helicopter until the flybarless control unit initializes. 7. The LED on the flybarless control unit turns solid blue when the helicopter is initialized. 8. Once the ESC beeps signaling the ESC is initialized, the helicopter is ready for flight. CAUTION: Low voltage cutoff does not protect the Li-Po battery during storage. If you allow the Li-Po battery voltage to fall below 3V per cell, you will damage the battery. The battery will no longer accept a charge and you will need to replace the battery. The warranty does not apply to batteries damaged from over-discharge. -
Page 12: Reviewing The Primary Flight Controls
Reviewing the Primary Flight Controls If you are not familiar with the controls of your 130 X, take a few minutes to familiarize yourself with them before attempting your first flight. Throttle Descend Climb Throttle up Throttle down Rudder Rudder left Rudder right Nose Yaws Right Nose Yaws Left Elevator Left Side View Left Side View Backward Forward Elevator down Elevator up Aileron Rear View Rear View Left Right Aileron left Aileron right Low Voltage Cutoff (LVC) Low voltage cutoff (LVC) protects the Li-Po battery from overdischarge in flight and activates when the battery reaches 3V per cell under load. Set your transmitter timer for 4 minutes and land when the timer expires. -
Page 13: Flying The 130 X
Flying the 130 X Consult local laws and ordinances before choosing a location to fly your aircraft. Select a large, open area away from people and objects. The Blade 130 X can fly outdoors or indoors in a gymnasium. CAUTION: Familiarize yourself with the Blade 130 X primary controls before attempting your first flight. The Blade 130 X is more responsive than other Blade micro helicopters like the Blade mSR. Seek help from an experienced pilot if you are new to collective pitch helicopters. Takeoff Quickly increase the throttle to 1/2 throttle and establish a low level hover. CAUTION: Do not give any aileron, elevator or rudder commands before takeoff or the helicopter may crash. Flying The helicopter lifts off the ground when the rotor head reaches a suitable speed. Establish a low-level hover to verify proper operation of your helicopter. You will not need to set any trim; the flybarless design of the 130 X renders trim unnecessary. For pilots new to collective pitch helicopters, familiarize yourself with the 130 X in normal mode. Discover the rates that fit your flying style. Stunt Mode When the helicopter is in stunt mode: • The rotor head speed is constant and high. • The main rotor will increase negative pitch as the throttle/collective stick is moved from the middle stick position to the low stick position. Negative pitch allows the helicopter to fly upside down and perform aerobatics. -
Page 14: Exploded Views
Exploded Views... -
Page 17: Parts Listings
Parts Listings Part # Description Part # Description BLH3701 Brushless Flybarless 3-in-1 Control BLH3717 Tail Boom: 130 X Unit, RX/ESC/Gyros: 130 X BLH3718 Tail Boom Brace/Supports Set: 130 X BLH3702 Main FrameSet: 130 X BLH3719 Torque Tube: 130 X BLH3703 Main Gear: 130 X BLH3720 Tail Linkage Pushrod: 130 X BLH3704 4x7x2 Bearing (2) BLH3721 Tail Boom Support Mount/ Pushrod BLH3705 Canopy Mounts: 130 X Guide: 130 X BLH3706 Landing Gear Set: 130 X BLH3722 Stock Canopy: 130 X BLH3707 Brushless Main Motor BLH3723 Tail Servo Boom Mount: 130 X BLH3708 Servo Pushrod Set: 130 X BLH3724 Vertical Fin: 130 X SPMSH... -
Page 18: Optional Parts
Optional Parts Part # Description Part # Description BLH3715OR Fast Flight Main Rotor Blade Set, BLH3733GR Tail Rotor Blade Set, Green: 130 X Orange: 130 X BLH3733YE Tail Rotor Blade Set, Yellow: 130 X BLH3715GR Fast Flight Main Rotor Blade Set, EFLC3025 Celectra 80W AC/DC Green: 130 X Multi-Chemistry Battery Charger BLH3715YE Fast Flight Main Rotor Blade Set, DX8 DSMX Transmitter Only Yellow: 130 X DX7s DSMX Transmitter Only BLH3735 Optional Metal Bevel Gears: 130 X DX6i DSMX 6-Channel BLH3716OR High-Performance Main Rotor Blade Transmitter Only Set, Organge: 130 X EFLA7001UM Charger Plug Adapter THP BLH3716GR High-Performance Main Rotor Blade Set, Green: 130 X EFLA700UM Charger Plug Adapter EFL BLH3716YE High-Performance Main Rotor Blade BLH3722A... -
Page 19: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution 130 X control response is Disconnect the flight battery, center inconsistent or requires extra Control trim is not centered the control trim and re-initialize the trim to neutralize movement Helicopter Throttle too high and/or throttle trim Reset controls with the throttle stick and is too high throttle trim at the lowest setting Disconnect the flight battery and 130 X will not respond to 130 X moved during initialization re-initialize the 130 X while keeping the throttle Helicopter from moving Disconnect flight battery, reverse the Throttle channel is reversed throttle channel on the transmitter, reconnect flight battery 130 X does not function and Flight battery connected with the Replace the 3-in-1 board. Connect the smells burnt after connecting wrong polarity flight battery noting proper polarity the flight battery Flight battery charge is low Completely recharge the flight battery Inadequate power to flight battery Make sure the AC power supply, charger charger and adapter cord are connected 130 X has reduced flight Replace the flight battery and follow the time or is underpowered... -
Page 20: Limited Warranty
What this Warranty Covers to better answer your questions and service you in the event Horizon Hobby, Inc., (Horizon) warrants to the original pur- that you may need any assistance. For questions or assis- chaser that the product purchased (the “Product”) will be tance, please visit our website at www.horizonhobby.com,... -
Page 21: Warranty And Service Contact Information
Warranty and Service Contact Information Country of Horizon Hobby Address Phone Number/Email Address Purchase 4105 Fieldstone Rd 877-504-0233 Horizon Service Center Champaign, Illinois Online Repair Request: (Electronics and engines) 61822 USA visit www.horizonhobby.com/service United States of America 4105 Fieldstone Rd Horizon Product Support 877-504-0233 Champaign, Illinois (All other products) productsupport@horizonhobby.com 61822 USA Units 1-4 Ployters Rd Staple Tye +44 (0) 1279 641 097 United Kingdom Horizon Hobby Limited Harlow, Essex sales@horizonhobby.co.uk CM18 7NS United Kingdom Christian-Junge-Straße 1... -
Page 22: Compliance Information For The European Union
Compliance Information for the European Union Declaration of Conformity (in accordance with ISO/IEC 17050-1) No. HH2012041201 Product(s): Blade 130 X BNF Item Number(s): BLH3780 Equipment class: The object of declaration described above is in conformity with the requirements of the specifications listed below, following the provisions of the European R&TTE Directive 1999/5/EC and EMC Directive 2004/108/EC: EN 301 489-1 V1.7.1: 2006 EN 301 489-17 V1.3.2: 2008 EN55022: 2010 EN55024: 2010 EN61000-3-2:2006+A1:2009+A2:2009 EN61000-3-3:2008 EN 60950-1:2006+A1:2010 Signed for and on behalf of: Horizon Hobby, Inc. Champaign, IL USA April 12, 2012 Steven A. Hall Vice President International Operations and Risk Management... -
Page 23: St-2
©2012 Horizon Hobby, Inc Blade, E-flite, Celectra, Bind-N-Fly, DSM, DSM2 JR and ModelMatch are trademarks or registered trademarks of Horizon Hobby, Inc. DSMX is a trademark of Horizon Hobby, Inc., registered in the U.S. The Spektrum trademark is used with permission of Bachmann Industries, Inc. US 7,898,130. US D578,146. PRC ZL 200620079025.2. Other patents pending. Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan Created 3/2012 32724 BLH3780...
