BCTV Zoom Lens
INFORMATION DISPLAY
取 扱 説 明 書
OPERATION MANUAL
使 用 说 明 书
ご使用の前に必ずこの取扱説明書をお読みください。
なお、取扱説明書は必要に応じてご覧になれるよう大切に保管してください。
Read this operation manual before using the product.
Keep the manual in place for future reference.
在使用本产品之前 , 请务必先仔细阅读本使用说明书。
请务必妥善保管好本书 , 以便日后能随时查阅 ( 保留备用 )。 请在充分理解内容的基
础上 , 正确使用。
（ 情 報 ディスプレ イ編 ）
(DISPLAY)
（ 信 息 显 示 屏 汇 编 ）
J/E/C

Advertisement

Table of Contents
loading

Related Manuals for Canon HJ40E

Summary of Contents for Canon HJ40E

  • Page 1 BCTV Zoom Lens INFORMATION DISPLAY 取 扱 説 明 書 （ 情 報 ディスプレ イ編 ） OPERATION MANUAL (DISPLAY) 使 用 说 明 书 （ 信 息 显 示 屏 汇 编 ） ご使用の前に必ずこの取扱説明書をお読みください。 なお、取扱説明書は必要に応じてご覧になれるよう大切に保管してください。 Read this operation manual before using the product. Keep the manual in place for future reference.
  • Page 3 ENGLISH...
  • Page 5 Introduction Introduction Thank you for purchasing a Canon BCTV zoom lens. This documentation includes the Lens Manual and Information Display CD-ROM. This Information Display Manual describes operating instructions and procedures for the information display. Refer to the manual as needed.

  • Page 6: Table Of Contents

    Introduction Contents Introduction General Safety Information ................. E 7 Handling the Product ........................E8 Dealing with Abnormalities ....................... E9 Maintenance and Inspection ......................E9 Storage ............................. E9 Legal Notices ..........................E10 Manual Layout .................... E 11 Manual Conventions ........................E12 Part Names ....................
  • Page 7 Introduction 3.1.4 Switching the IS Compensation Mode of the Horizontal Direction ........E29 3.1.5 Switching the IS Compensation Mode of the Vertical Direction ........... E30 3.1.6 Zoom Tracking ON/OFF ....................... E31 3.1.7 Assigning Functions to the AUX Switch ................E32 3.1.8 Assigning Functions to the AUX1 Switch ................
  • Page 8 Introduction 4.1.16 Specifying Iris A/M Switch ....................E99 4.1.17 Assigning Functions to the Seesaw .................. E100 4.1.18 Escape Operation ......................E101 4 . 2 Configuration from the Menu Screen ..........E 102 4.2.1 User Screen Settings ......................E103 4.2.2 Switch Screen Settings ....................... E120 4.2.3 IS Screen Settings ......................

  • Page 9: General Safety Information

    Introduction General Safety Information The safety warnings and cautions provided on the product or in this operation manual must be observed. Failure to observe these warnings and cautions provided to guard against hazards may result in injury or accident. Read this manual carefully to familiarize yourself with its contents and to ensure proper operation of this product. Also, keep this manual in a safe place where it can easily be referenced whenever required.

  • Page 10: Handling The Product

    5. Take measures to avoid sudden changes in temperature where the lens is used, which may prevent operation temporarily if condensation forms in the lens. 6. Before use in particular environments, such as places where chemical products are used, contact your Canon representative. Otherwise it may cause the malfuction of the product.

  • Page 11: Dealing With Abnormalities

    Warning If any of the following situations occurs, immediately disconnect the lens cable from the camera and contact your dealer or a Canon representative listed on the next page. • Smoke, fumes, or unusual noises • Entry of foreign objects (such as liquid or metal objects) inside the product...

  • Page 12: Legal Notices

    5. For further information on repairs, maintenance, or adjustments not mentioned in this operation manual, contact your Canon dealer or your Canon sales representative. 6. Note that Canon may be unable to undertake servicing or repair of a product if it is modified without consulting Canon or your Canon sales representative.

  • Page 13: Manual Layout

    Introduction Manual Layout Pages with instructions are organized as follows. Chapter title 4. Operation in Full Mode Function title 4.1.17 Assigning Functions to the Seesaw The zoom seesaw switch can be programmed to control either the {Zoom} or {Iris}. Important Summary of function, First, switch to the user for whom the settings apply.

  • Page 14: Manual Conventions

    Introduction Manual Conventions The following conventions are used in this manual. Convention Description Example ** screen Names of screens are underlined. The Top screen is displayed. Names of setting items are enclosed in square brackets. [Frame 1] is underlined. Names of options are enclosed in curly brackets. Select {Sped}.

  • Page 15: Part Names

    Introduction Part Names Part Names and Functions Display switch Press to activate the display. One press turns on the display, and another turns it off. Control keys Used to configure all settings shown on the display. Identified with five key names, depending on how this interface is used.

  • Page 16: Basic Sequence Of Operations

    Introduction Basic Sequence of Operations Turn on the lens. Note: For instructions on turning the lens on, refer to the camera manual. Press the Display switch. IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Shtl Fr1P The display is now illuminated. Use the control keys to complete settings.

  • Page 17: Screen Organization

    Screen Organization...

  • Page 18: Top Screen

    1. Screen Organization 1 . Screen Organization Screens contain 22 setting items in Basic mode, 35 in Full mode, and 3 in Analog mode, with Basic and Full modes also including a “follow” screen containing three setting items that have relative values. Frequently used items are displayed on the Top screen (the screen displayed by pressing the Display switch).
  • Page 19 1. Screen Organization Top Screen in Full Mode Initial Top Screen in Full Mode Of the 14 setting items in Full mode, the 8 most common are MENU shown on the Top screen. The other 6 can be accessed by [ Basic ] [Trk]OFF pressing down to scroll down the screen.

  • Page 20: Menu Screen

    1. Screen Organization 1 . 2 Menu Screen (For instructions on configuring the settings, see the "Menu Screen" section in the descriptions of each mode.) Setting items in each mode and on the “follow” screen are organized by function. All of these screens are collectively referred to as the Menu screen.
  • Page 21 1. Screen Organization Menu Screen in Full Mode In Full mode, the 35 setting items and three “follow” settings with relative values are organized by function into the following 9 screens. Icon of selected screen 1. User screen is highlighted. 2.
  • Page 22 1. Screen Organization Menu Screen in Analog Mode In Analog mode, 2 setting items are presented as the User screen. 1. User Screen User Mode: Analog Access: Unlock Icon of selected screen is highlighted. : There is no single Menu screen. Instead, these screens displayed by selecting [Menu] are collectively referred to as the Menu screen.

  • Page 23: Mode Selection

    Mode Selection...

  • Page 24: Modes

    2. Mode Selection 2 . Mode Selection 2 . 1 Modes The following 3 modes are available. Choose a mode that suits your purpose or preference. 1. Basic Mode: Restricted settings and information. Recommended for users who do not require sophisticated settings.

  • Page 25: Operation In Basic Mode

    Operation in Basic Mode...

  • Page 26: Configuration From The Top Screen

    3. Operation in Basic Mode 3 . Operation in Basic Mode 3 . 1 Configuration from the Top Screen The screen displayed by pressing the Display switch is referred to as the Top screen. A total of 10 items can be configured on the Top screen in Basic mode. The first screen displayed is referred to as the Initial Top screen.

  • Page 27: Selecting Basic Mode

    3. Operation in Basic Mode 3 . 1 . 1 Selecting Basic Mode Basic mode is the default mode, but it can also be accessed from other modes as follows. Switching from Full to Basic Mode Initial Top Screen in Full Mode MENU [ Basic ] [Trk]OFF...

  • Page 28: Top Screen

    3. Operation in Basic Mode 3 . 1 . 2 Top Screen A total of 10 items can be configured on the Top screen in Basic mode, and the first screen shown is referred to as the Initial Top screen, which displays 8 items. The other items can be displayed by pressing down to scroll down the screen. (See the following figure.) Status of some items can be checked simply by accessing this screen.
  • Page 29 3. Operation in Basic Mode Menu screen [Trk] Zoom tracking MENU See “3.2 Configuration from the Menu Screen.” Switch to ON when using zoom tracking. See “3.1.6 Zoom Tracking ON/OFF.” Auto iris gain A 1 AUX 1 switch Adjust the auto iris gain value. By default, the AUX1 switch for a zoom demand is assigned to the {Shuttle} function, but it can See “3.1.3 Specifying Auto Iris Gain.”...

  • Page 30: Specifying Auto Iris Gain

    3. Operation in Basic Mode 3 . 1 . 3 Specifying Auto Iris Gain [IG] Although this value is factory-set, it can be adjusted as needed. To adjust the value, use either the auto iris gain adjustment trimmer (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.

  • Page 31: Switching The Is Compensation Mode Of The Horizontal Direction

    3. Operation in Basic Mode 3 . 1 . 4 Switching the IS Compensation Mode of the Horizontal Direction Switch the IS compensation mode of the horizontal direction. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press The previous or default value is highlighted.

  • Page 32: Switching The Is Compensation Mode Of The Vertical Direction

    3. Operation in Basic Mode 3 . 1 . 5 Switching the IS Compensation Mode of the Vertical Direction Switch the IS compensation mode of the vertical direction. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press and then The previous or default value is highlighted.

  • Page 33: Zoom Tracking On/Off

    3. Operation in Basic Mode 3 . 1 . 6 Zoom Tracking ON/OFF [Trk] Activate or deactivate zoom tracking as needed. Important In Basic mode, any adjustments to this setting are not retained when the lens is turned off, and the default value is restored on startup.

  • Page 34: Assigning Functions To The Aux Switch

    3. Operation in Basic Mode 3 . 1 . 7 Assigning Functions to the AUX Switch Assign your desired functions to the AUX switch. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press twice. The default function is highlighted. MENU IG: 50 IS   STD...

  • Page 35: Assigning Functions To The Aux1 Switch

    3. Operation in Basic Mode 3 . 1 . 8 Assigning Functions to the AUX 1 Switch Assign your desired functions to the AUX1 switch. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press three times. The default function is highlighted.

  • Page 36: Assigning Functions To The Aux2 Switch

    3. Operation in Basic Mode 3 . 1 . 9 Assigning Functions to the AUX 2 Switch Assign your desired functions to the AUX2 switch. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press three times and once.

  • Page 37: Specifying Iris Torque

    3. Operation in Basic Mode 3 . 1 . 10 Specifying Iris Torque [I-Tq] Specify the desired level of torque in manual control of the iris ring. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press four times.

  • Page 38: Specifying Zoom Curve Mode

    3. Operation in Basic Mode 3 . 1 . 11 Specifying Zoom Curve Mode [Z.M.] Specifying Seesaw Switch Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the zoom seesaw switch. (Note: Another screen is displayed when this setting is configured.) Initial Top Screen IG: 50 MENU...
  • Page 39 3. Operation in Basic Mode Specifying Analog Demand Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the analog demand thumb ring. (Note: Another screen is displayed when this setting is configured.) Initial Top Screen IG: 50 MENU IS   STD IS   STD...

  • Page 40: Configuration From The Menu Screen

    3. Operation in Basic Mode 3 . 2 Configuration from the Menu Screen In Basic mode, you can view and configure 22 setting items and a “follow” screen with three setting items that have relative values from the Menu screen Specifically, the Menu screen in Basic mode is organized into 9 screens by function: User screen, Switch screen, IS screen, Preset screen, Iris screen, Zoom screen, Focus screen, Info screen, and Fol.

  • Page 41: User Screen Settings

    3. Operation in Basic Mode 3 . 2 . 1 User Screen Settings User B is the user in Basic mode. User Screen in Basic Mode The following setting items can be configured on the User screen. User Mode: Basic Switching Modes ResetAll Resetting Values...
  • Page 42 3. Operation in Basic Mode Switching Modes Switch to Full or Analog mode as needed. Important The new mode setting is retained even after the lens is turned off. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press User Screen...
  • Page 43 3. Operation in Basic Mode Resetting Values Reset a userʼs settings to default values as needed. Initial Top Screen Note: Iris gain values are not reset. The current value is retained. IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl User Screen Press User...
  • Page 44 3. Operation in Basic Mode Locking Functions To ensure that configured functions cannot easily be changed, you can lock the settings of certain functions. Unlocked Locked User User Mode: Basic Mode: Basic ResetAll ResetAll Access: Unlock Access: Lock Note In lock mode, only the following items can still be configured, and other settings are locked. •...
  • Page 45 No master password is used on this model. The password you enter each time to lock settings is the password used to unlock them. For this reason, we recommend making a note of the password each time. If you forget the password, contact Canon or your dealer. Passwords can be blank or up to 8 digits. Characters supported in passwords Options ＿－...
  • Page 46 3. Operation in Basic Mode (2) Unlocking Settings Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press User Screen The display switches to the User screen. User Mode: Basic ResetAll Access: Lock Press three times. User The previous or default value is highlighted.

  • Page 47: Switch Screen Settings

    3. Operation in Basic Mode 3 . 2 . 2 Switch Screen Settings The following setting items can be configured on the Switch screen. Assigning Functions to the AUX Switch Assigning Functions to the AUX1 Switch Assigning Functions to the AUX2 Switch can also be modified from the Top screen.
  • Page 48 3. Operation in Basic Mode Assigning Functions to the AUX Switch The AUX switch can be programmed to activate a function of your choice. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press and then Switch Screen The display switches to the Switch screen.
  • Page 49 3. Operation in Basic Mode Assigning Functions to the AUX 1 Switch The AUX1 switch for a zoom demand can be programmed to activate a function of your choice. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Switch Screen Press...
  • Page 50 3. Operation in Basic Mode Assigning Functions to the AUX 2 Switch The AUX2 switch for a zoom demand can be programmed to activate a function of your choice. Initial Top Screen IG: 50 MENU [Trk]OFF Fr1P Fr1P Shtl [I-Tq]H [Z.M.] Press and then...

  • Page 51: Is Screen Settings

    3. Operation in Basic Mode 3 . 2 . 3 IS Screen Settings The following setting items can be configured on the IS screen. Switching IS Compensation Mode (1) Switching the IS Compensation Mode of the Horizontal Direction (2) Switching the IS Compensation Mode of the Vertical Direction Specifying the Mode of when IS is OFF Specifying IS Switch Functions (1) Specifying the Method of IS ON/OFF Selection...
  • Page 52 3. Operation in Basic Mode Switching IS Compensation Mode (1) Switching the IS Compensation Mode of the Horizontal Direction Switch the IS compensation mode of the horizontal direction as needed. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl IS Screen...
  • Page 53 3. Operation in Basic Mode (2) Switching the IS Compensation Mode of the Vertical Direction Switch the IS compensation mode of the vertical direction as needed. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl IS Screen Press once and twice.
  • Page 54 3. Operation in Basic Mode Switching the Mode of when IS is OFF Specify the IS compensation function of when the IS compensation mode is switched to OFF, as needed. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press...
  • Page 55 3. Operation in Basic Mode Specifying IS Switch Functions (1) Specifying the Method of IS ON/OFF Selection Specify the method of IS ON/OFF selection of when pressing the IS switch and the switch to which the IS functions are assigned, as needed. Initial Top Screen IG: 50 MENU...
  • Page 56 3. Operation in Basic Mode (2) Switching the Polarity of the IS Switch Switch the polarity of the IS switch and the switch to which the IS functions are assigned, as needed. Important First, specify Mom as the method of IS ON/OFF selection of when pressing the IS switch and the switch to which the IS functions are assigned.

  • Page 57: Preset Screen Settings

    3. Operation in Basic Mode 3 . 2 . 4 Preset Screen Settings The following setting items can be configured on the Preset screen. Switching What Frame Preset 1 Controls Switching What Frame Preset 2 Controls Specifying the Preset Mode Zoom Speed...
  • Page 58 3. Operation in Basic Mode Switching What Frame Preset 1 Controls Switch what frame preset 1 controls, as needed. Zoom : Move the zoom position to the position in memory Focus : Move the focus position to the position in memory : Move the zoom and focus position to the position in memory Initial Top Screen IG: 50...
  • Page 59 3. Operation in Basic Mode Switching What Frame Preset 2 Controls Switch what frame preset 2 controls, as needed. Zoom : Move the zoom position to the position in memory Focus : Move the focus position to the position in memory : Move the zoom and focus position to the position in memory Initial Top Screen IG: 50...
  • Page 60 3. Operation in Basic Mode Specifying the Preset Mode Zoom Speed Configure the zoom speed from any position to the position in memory, as needed. To adjust the value, use either the Memo button (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.

  • Page 61: Iris Screen Settings

    3. Operation in Basic Mode 3 . 2 . 5 Iris Screen Settings The following setting items can be configured on the Iris screen. Specifying Iris Gain (1) Specifying Auto Iris Gain (2) Specifying Remote Iris Gain Specifying Iris Torque Iris Compensation ON/OFF Iris Close Detection ON/OFF Items labeled...
  • Page 62 3. Operation in Basic Mode Specifying Iris Gain (1) Specifying Auto Iris Gain Although this value is factory-set, it can be adjusted as needed. To adjust the value, use either the auto iris gain adjustment trimmer (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.
  • Page 63 3. Operation in Basic Mode (2) Specifying Remote Iris Gain Although this value is factory-set, it can be adjusted as needed. The same remote iris gain value applies to all users. Initial Top Screen Note: Do the following when adjusting gain while checking iris operation.
  • Page 64 3. Operation in Basic Mode Specifying Iris Torque Specify the desired level of torque in manual control of the iris ring. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press once and three times. Iris Screen The display switches to the Iris screen.
  • Page 65 3. Operation in Basic Mode Iris Compensation ON/OFF The amount of light decreases when an extender (2.0x) is used. You can specify a function that compensates by opening the iris by an amount equivalent to f/2. Initial Top Screen IG: 50 MENU IS   STD IS   STD...
  • Page 66 3. Operation in Basic Mode Iris Close Detection ON/OFF The iris cannot be fully closed when correction is active and an extender (2.0x) is used. As a countermeasure, you can specify a function to detect iris close and close the iris as needed. Initial Top Screen Note: With some cameras, iris...

  • Page 67: Zoom Screen Settings

    3. Operation in Basic Mode 3 . 2 . 6 Zoom Screen Settings The following setting items can be configured on the Zoom screen. Specifying Seesaw Curve Responsiveness Specifying Analog Demand Curve Responsiveness Demand-Based Zoom Speed Adjustment ON/OFF...
  • Page 68 3. Operation in Basic Mode Specifying Seesaw Switch Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the zoom seesaw switch. (Note: Another screen is displayed when this setting is configured.) Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF...
  • Page 69 3. Operation in Basic Mode Specifying Analog Demand Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the analog demand thumb ring. (Note: Another screen is displayed when this setting is configured.) Initial Top Screen IG: 50 MENU IS   STD IS   STD...
  • Page 70 3. Operation in Basic Mode Demand-Based Zoom Speed Adjustment ON/OFF Enable or disable adjustment of the maximum drive unit zoom speed based on the zoom demand. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl Press once and four times.

  • Page 71: Focus Screen Settings

    3. Operation in Basic Mode 3 . 2 . 7 Focus Screen Settings The following setting items can be configured on the Focus screen. Specifying Focus Demand Curve Responsiveness...
  • Page 72 3. Operation in Basic Mode Specifying Focus Demand Responsiveness Specify responsiveness in analog focus demand operations as needed. Initial Top Screen Note: These settings take effect when the curve selection switch on the focus demand is IG: 50 MENU set toward FAR. IS   STD IS   STD [Trk]OFF...

  • Page 73: Info Screen Settings

    3. Operation in Basic Mode 3 . 2 . 8 Info Screen Settings The following setting items can be configured on the Info screen. Specifying the 3D Function (For information on specifying the 3D function, see the instruction manual of the BC-100 3D cable.) Specifying Encoder Output Serial Communication with Camera ON/OFF...
  • Page 74 3. Operation in Basic Mode Specifying Encoder Output Enable or disable encoder output as needed. Enabling output enables virtual connector output. For details, contact Canon or your dealer. Initial Top Screen IG: 50 MENU IS   STD IS   STD [Trk]OFF Fr1P Fr1P Shtl...
  • Page 75 3. Operation in Basic Mode Serial Communication with Camera ON/OFF Two types of camera–lens interfaces are available: analog control or control via serial communication. This setting enables you to switch between auto control detection and analog control. By default, this setting is ON, enabling auto detection of whether serial or analog control is used. To restrict the interface to analog control, set it to OFF.

  • Page 76: Fol. Screen Settings

    3. Operation in Basic Mode 3 . 2 . 9 Fol. Screen Settings The following setting items can be configured on the Fol. screen. Viewing Lens Follow Settings (Iris, Zoom, Focus)
  • Page 77 3. Operation in Basic Mode Viewing Lens Follow Settings (Iris, Zoom, Focus) Indicates values in the full range of mechanical iris, zoom, and focus operations, expressed as relative values in the range of 0–1000. Initial Top Screen Note: As long as the Fol. screen is shown, the display will not turn off automatically after 2 IG: 50...

  • Page 78: List Of Settings

    3. Operation in Basic Mode 3 . 3 List of Settings Default Value Options MENU 1 on the next page 01–99 IS　　 STD / HIGH / OFF IS　　 STD / HIGH / OFF Fr1P VTR / RET / Fr1P/ Fr1F / Fr2P / Fr2F / Sped / Shtl / IS / NON [ Trk ] OFF / ON Shtl...
  • Page 79 3. Operation in Basic Mode ＊ From 3 To Default Options Value MENU ＊ User ＊ Mode Basic Basic / Analog / Full ResetAll User y / n Access Unlock Unlock / Lock Switch VTR / RET / Fr1P / Fr1F / Fr2P / Fr2F / Fr1P Sped / Shtl / IS / NON VTR / RET / Fr1P/ Fr1F / Fr2P / Fr2F / Sped...
  • Page 80 Memo...

  • Page 81: Operation In Full Mode

    Operation in Full Mode...

  • Page 82: Configuration From The Top Screen

    4. Operation in Full Mode 4 . Operation in Full Mode 4 . 1 Configuration from the Top Screen To access the Top screen, press the Display switch. A total of 16 items can be configured on the Top screen in Full mode. The first screen displayed is referred to as the Initial Top screen.

  • Page 83: Selecting Full Mode

    4. Operation in Full Mode 4 . 1 . 1 Selecting Full Mode Basic mode is the default mode, but Full mode can be accessed as follows. Switching from Basic to Full Mode Initial Top Screen in Basic Mode IG: 50 MENU IS   STD IS   STD...

  • Page 84: Top Screen

    4. Operation in Full Mode 4 . 1 . 2 Top Screen A total of 16 items can be configured on the Top screen in Full mode,and the first screen shown is referred to as the Initial Top screen, which displays 8 items. The other 8 can be accessed by pressing down to scroll down the screen.
  • Page 85 4. Operation in Full Mode Menu screen A 1 AUX 1 switch MENU See “4.2 Configuration from the Menu Screen.” By default, the AUX1 switch for a zoom demand is assigned to the {Shuttle} function, but it can be reassigned as needed. See “4.1.10 Assigning Functions to the AUX1 Switch.”...

  • Page 86: Switching Users

    4. Operation in Full Mode 4 . 1 . 3 Switching Users Settings for users 0–9 can be configured in Full mode. User 1–9 Configure advanced settings for each user needed. Settings for the users can then be saved. User 0 User 0 is the default user.

  • Page 87: Switching To Basic Mode

    4. Operation in Full Mode 4 . 1 . 4 Switching to Basic Mode [Basic] Switch to Basic mode from the Top screen as needed. Switching from Full to Basic Mode Initial Top Screen in Full Mode MENU [ Basic ] [Trk]OFF IS   STD IS   STD...

  • Page 88: Zoom Tracking On/Off

    4. Operation in Full Mode 4 . 1 . 5 Zoom Tracking ON/OFF [Trk] Activate or deactivate zoom tracking as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 89: Switching The Is Compensation Mode Of The Horizontal Direction

    4. Operation in Full Mode 4 . 1 . 6 Switching the IS Compensation Mode of the Horizontal Direction Switch the IS compensation mode of the horizontal direction. Initial Top Screen MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P Press twice.

  • Page 90: Switching The Is Compensation Mode Of The Vertical Direction

    4. Operation in Full Mode 4 . 1 . 7 Switching the IS Compensation Mode of the Vertical Direction Switch the IS compensation mode of the vertical direction. Initial Top Screen MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P Press twice and...

  • Page 91: Assigning Functions To The Aux Switch

    4. Operation in Full Mode 4 . 1 . 8 Assigning Functions to the AUX Switch Assign your desired functions to the AUX switch. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 92: Specifying Iris Gain

    4. Operation in Full Mode 4 . 1 . 9 Specifying Iris Gain [I-Gain] Specifying Auto Iris Gain Although this value is factory-set, it can be adjusted as needed. To adjust the value, use either the auto iris gain adjustment trimmer (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.
  • Page 93 4. Operation in Full Mode Specifying Remote Iris Gain Although this value is factory-set, it can be adjusted as needed. The same remote iris gain value applies to all users, regardless of the current user. Thus, there is no need to switch users in advance.

  • Page 94: Assigning Functions To The Aux1 Switch

    4. Operation in Full Mode 4 . 1 . 10 Assigning Functions to the AUX 1 Switch Assign your desired functions to the AUX1 switch. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 95: Assigning Functions To The Vtr Switch

    4. Operation in Full Mode 4 . 1 . 11 Assigning Functions to the VTR Switch Assign your desired functions to the VTR switch. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 96: Assigning Functions To The Aux2 Switch

    4. Operation in Full Mode 4 . 1 . 12 Assigning Functions to the AUX 2 Switch Assign your desired functions to the AUX2 switch. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 97: Assigning Functions To The Ret Switch

    4. Operation in Full Mode 4 . 1 . 13 Assigning Functions to the RET Switch Assign your desired functions to the RET switch. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 98: Specifying Iris Torque

    4. Operation in Full Mode 4 . 1 . 14 Specifying Iris Torque [I-Tq] Specify the desired level of torque in manual control of the iris ring. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 99: Specifying Zoom Curve Mode

    4. Operation in Full Mode 4 . 1 . 15 Specifying Zoom Curve Mode [Z.M.] Specifying Seesaw Switch Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the zoom seesaw switch. (Note: Another screen is displayed when this setting is configured.) Important First, switch to the user for whom the settings apply.
  • Page 100 4. Operation in Full Mode Specifying Analog Demand Responsiveness Configure the responsiveness of zoom speed adjustment in response to pressing the analog demand thumb ring. (Note: Another screen is displayed when this setting is configured.) Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...

  • Page 101: Specifying Iris A/M Switch

    4. Operation in Full Mode 4 . 1 . 16 Specifying Iris A/M Switch The iris A/M switch on the top of the drive unit can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...

  • Page 102: Assigning Functions To The Seesaw

    4. Operation in Full Mode 4 . 1 . 17 Assigning Functions to the Seesaw The zoom seesaw switch can be programmed to control either the {Zoom} or {Iris}. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...

  • Page 103: Escape Operation

    4. Operation in Full Mode 4 . 1 . 18 Escape Operation Instantly jump to user 0, with default settings, from the current user (0–9). Note Not available when settings are locked. Note The following settings remain the same even after jumping to user 0. Auto and remote iris gain values, encoder output setting, and camera follow voltage adjustments Hold down both the Display switch and for at least...

  • Page 104: Configuration From The Menu Screen

    4. Operation in Full Mode 4 . 2 Configuration from the Menu Screen In Full mode, you can view and configure 35 setting items and a “follow” screen with three setting items that have relative values from the Menu screen. Specifically, the Menu screen in Full mode is organized into 9 screens by function: User screen, Switch screen, IS screen, Preset screen, Iris screen, Zoom screen, Focus screen, Info screen, and Fol.

  • Page 105: User Screen Settings

    4. Operation in Full Mode 4 . 2 . 1 User Screen Settings For details on users available in Full mode, see “4.1.3 Switching Users.” The following setting items can be configured on the User screen. User Screen in Full Mode Switching Modes User Mode:...
  • Page 106 4. Operation in Full Mode Switching Modes Switch to Basic or Analog mode as needed. Important The new mode setting is retained even after the lens is turned off. Initial Top Screen MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P Press User Screen...
  • Page 107 4. Operation in Full Mode Switching Users Top Switch Users (0–9) as needed. To configure settings for individual users, switch to that user number. Initial Top Screen MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P Press User Screen The display switches to the User screen.
  • Page 108 4. Operation in Full Mode Naming Users Users can be named, as needed. Initial Top Screen Important First, switch to the user for whom the settings apply. MENU (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen [ Basic ] [Trk]OFF Settings: Switching Users.”) IS   STD...
  • Page 109 4. Operation in Full Mode Resetting Values (1) Resetting One User’s Settings Reset a userʼs settings to default values as needed. Important Initial Top Screen First, switch to the user for whom the settings apply. MENU (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: [ Basic ] [Trk]OFF Switching Users.”)
  • Page 110 4. Operation in Full Mode (2) Resetting All Users’ Settings Reset all usersʼ settings to default values as needed. Note: There is no need to switch users. Initial Top Screen MENU [ Basic ] [Trk]OFF Note: Iris gain values, encoder IS   STD IS   STD output setting, and camera...
  • Page 111 4. Operation in Full Mode Copying Settings Between Individual Users Settings configured for one user can be copied to another user. Important Initial Top Screen First, switch to the user for whom the settings apply. MENU (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: [ Basic ] [Trk]OFF Switching Users.”)
  • Page 112 4. Operation in Full Mode Continued from previous page Press and then Screen A User ResetAll Settings are copied to the specified user number, and the display Copy reverts to Screen A. ToOtherLens User MENU × 5 E110...
  • Page 113 Setting information can be copied between information displays of drive units mounted on the display. You can copy either settings for individual users or for all users. Copying requires a dedicated cable, sold separately. For details, contact Canon or your dealer. (1) Copying One User’s Settings to Another Lens...
  • Page 114 4. Operation in Full Mode Continued from previous page Copy Selection Screen The display switches to the Copy selection screen. User ToOtherLens UserCopy : AllCopy : Target User Selection Screen Press The display switches to the Target user selection screen. User ToOtherLens To No.
  • Page 115 4. Operation in Full Mode (2) Copying All Users’ Settings to Another Lens Copying requires a dedicated cable, sold separately. For details, contact Canon or your dealer. Note: Required Preparation 1. Plug one end of the dedicated cable (20 pin–20 pin) into the source lens and the other end into the 20-pin connector of the zoom/focus remote of the target lens.
  • Page 116 4. Operation in Full Mode Continued from previous page Screen B The display switches to Screen B. User ToOtherLens UserCopy : AllCopy : Press twice. [AllCopy] is underlined, and you can select {y} (yes) or {n} (no). User ToOtherLens UserCopy : AllCopy : Press AllCopy Screen...
  • Page 117 Error!! start. Confirm that the drive unit of the Settings cannot be copied Contact Canon or your dealer target lens is the same model. between lenses of different for details on models of drive generations of drive units.
  • Page 118 4. Operation in Full Mode Locking Functions To ensure that configured functions cannot easily be changed, you can lock the settings of certain functions. Once functions are locked, they are locked for all users. For instructions on locking settings in Analog mode, see “5. Operation in Analog Mode.” Unlocked Locked Lock...
  • Page 119 No master password is used on this model. The password you enter each time to lock settings is the password used to unlock them. For this reason, we recommend making a note of the password each time. If you forget the password, contact Canon or your dealer. Passwords can be blank or up to 8 digits. Characters supported in passwords Options ＿－...
  • Page 120 4. Operation in Full Mode (2) Unlocking Settings Settings can be unlocked in two ways, as follows. (Unlocking Setting 1) Initial Top Screen MENU Lock [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P Press [ ] Lock MENU [ Basic ] [Trk]OFF IS   STD...
  • Page 121 4. Operation in Full Mode (Unlocking Setting 2) Initial Top Screen Lock MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ] Fr1P User Screen Press The display switches to the User screen. User Mode: Full No.: Name: -------- Press seven times.

  • Page 122: Switch Screen Settings

    4. Operation in Full Mode 4 . 2 . 2 Switch Screen Settings The following setting items can be configured on the Switch screen. Assigning Functions to the AUX Switch Assigning Functions to the AUX1 Switch Assigning Functions to the AUX2 Switch Assigning Functions to the VTR Switch Assigning Functions to the RET Switch Specifying Iris A/M Switch...
  • Page 123 4. Operation in Full Mode Assigning Functions to the AUX Switch Top The AUX switch can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 124 4. Operation in Full Mode Assigning Functions to the AUX 1 Switch Top The AUX1 switch for a zoom demand can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 125 4. Operation in Full Mode Assigning Functions to the AUX 2 Switch Top The AUX2 switch for a zoom demand can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 126 4. Operation in Full Mode Assigning Functions to the VTR Switch Top The VTR switch can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 127 4. Operation in Full Mode Assigning Functions to the RET Switch Top The RET switch can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 128 4. Operation in Full Mode Specifying Iris A/M Switch Top The Iris A/M switch can be programmed to activate a function of your choice. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 129 4. Operation in Full Mode Assigning Functions to the Seesaw Top The zoom seesaw switch can be programmed to control either the {Zoom} or {Iris}. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 130: Is Screen Settings

    4. Operation in Full Mode 4 . 2 . 3 IS Screen Settings The following setting items can be configured on the IS screen. Switching IS Compensation Mode (1) Switching the IS Compensation Mode of the Horizontal Direction (2) Switching the IS Compensation Mode of the Vertical Direction Specifying the Mode of when IS is OFF Specifying IS Switch Functions (1) Specifying the Method of IS ON/OFF Selection...
  • Page 131 4. Operation in Full Mode Switching IS Compensation Mode (1) Switching the IS Compensation Mode of the Horizontal Direction Switch the IS compensation mode of the horizontal direction as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 132 4. Operation in Full Mode (2) Switching the IS Compensation Mode of the Vertical Direction Switch the IS compensation mode of the vertical direction as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 133 4. Operation in Full Mode Switching the Mode of when IS is OFF Specify the IS compensation function of when the IS compensation mode is switched to OFF, as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 134 4. Operation in Full Mode Specifying IS Switch Functions (1) Specifying the Method of IS ON/OFF Selection Specify the method of IS ON/OFF selection of when pressing the IS switch and the switch to which the IS functions are assigned, as needed. Important First, switch to the user for whom the settings apply.
  • Page 135 4. Operation in Full Mode (2) Switching the Polarity of the IS Switch Switch the polarity of the IS switch and the switch to which the IS functions are assigned, as needed. Important First, specify Mom as the method of IS ON/OFF selection of when pressing the IS switch and the switch to which the IS functions are assigned.

  • Page 136: Preset Screen Settings

    4. Operation in Full Mode 4 . 2 . 4 Preset Screen Settings The following setting items can be configured on the Preset screen. Switching What Frame Preset 1 Controls Switching What Frame Preset 2 Controls Specifying the Preset Mode Zoom Speed Specifying Zoom Start Responsiveness for Presets Specifying Zoom Stop Responsiveness for Presets E134...
  • Page 137 4. Operation in Full Mode Switching What Frame Preset 1 Controls Switch what frame preset 1 controls, as needed. Zoom : Move the zoom position to the position in memory Focus : Move the focus position to the position in memory : Move the zoom and focus position to the position in memory Important First, switch to the user for whom the settings apply.
  • Page 138 4. Operation in Full Mode Switching What Frame Preset 2 Controls Switch what frame preset 2 controls, as needed. Zoom : Move the zoom position to the position in memory Focus : Move the focus position to the position in memory : Move the zoom and focus position to the position in memory Important First, switch to the user for whom the settings apply.
  • Page 139 4. Operation in Full Mode Specifying the Preset Mode Zoom Speed Configure the zoom speed from any position to the position in memory, as needed. To adjust the value, use either the Memo button (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.
  • Page 140 4. Operation in Full Mode Specifying Zoom Start Responsiveness for Presets Specify initial responsiveness in zooming for preset operations. Important Initial Top Screen First, switch to the user for whom the settings apply. MENU (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen [ Basic ] [Trk]OFF Settings: Switching Users.”)
  • Page 141 4. Operation in Full Mode Specifying Zoom Stop Responsiveness for Presets Specify final responsiveness in zooming for preset operations. Important Initial Top Screen First, switch to the user for whom the settings apply. MENU (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen [ Basic ] [Trk]OFF Settings: Switching Users.”)

  • Page 142: Iris Screen Settings

    4. Operation in Full Mode 4 . 2 . 5 Iris Screen Settings The following setting items can be configured on the Iris screen. Specifying Iris Gain (1) Specifying Auto Iris Gain (2) Specifying Remote Iris Gain Specifying Iris Torque Iris Compensation ON/OFF Iris Close Detection ON/OFF Items labeled...
  • Page 143 4. Operation in Full Mode Specifying Iris Gain (1) Specifying Auto Iris Gain Although this value is factory-set, it can be adjusted as needed. To adjust the value, use either the auto iris gain adjustment trimmer (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.
  • Page 144 4. Operation in Full Mode (2) Specifying Remote Iris Gain Although this value is factory-set, it can be adjusted as needed. The same remote iris gain value applies to all users, regardless of the current user. Thus, there is no need to switch users in advance.
  • Page 145 4. Operation in Full Mode Specifying Iris Torque Specify the desired level of torque in manual control of the iris ring. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [Trk]OFF...
  • Page 146 4. Operation in Full Mode Iris Compensation ON/OFF The amount of light decreases when an extender (2.0x) is used. You can specify a function that compensates by opening the iris by an amount equivalent to f/2. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 147 4. Operation in Full Mode Iris Close Detection ON/OFF The iris cannot be fully closed when correction is active and an extender (2.0x) is used. As a countermeasure, you can specify a function to detect iris close and close the iris as needed. Important First, switch to the user for whom the settings apply.

  • Page 148: Zoom Screen Settings

    4. Operation in Full Mode 4 . 2 . 6 Zoom Screen Settings The following setting items can be configured on the Zoom screen. Zoom Tracking ON/OFF Specifying Zoom Servo Start Responsiveness Specifying Zoom Servo Stop Responsiveness Specifying Zoom Mechanical End Stop Responsiveness Specifying Seesaw Switch Responsiveness Specifying Analog Demand Responsiveness Specifying Maximum Zoom Speed Control...
  • Page 149 4. Operation in Full Mode Zoom Tracking ON/OFF Activate or deactivate zoom tracking as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ] [Trk]OFF...
  • Page 150 4. Operation in Full Mode Specifying Zoom Servo Start Responsiveness Specify initial responsiveness in zooming (using seesaw switch, for example) as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 151 4. Operation in Full Mode Specifying Zoom Servo Stop Responsiveness Specify final responsiveness in zooming (using seesaw switch, for example) as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 152 4. Operation in Full Mode Specifying Zoom Mechanical End Stop Responsiveness Specify final responsiveness at the mechanical end in zooming (using the seesaw switch, for example) as needed. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 153 4. Operation in Full Mode Specifying Seesaw Curve Responsiveness Top Configure the responsiveness of zoom speed adjustment in response to pressing the zoom seesaw switch. (Note: Another screen is displayed when this setting is configured.) Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 154 4. Operation in Full Mode Specifying Analog Demand Curve Responsiveness Top Configure the responsiveness of zoom speed adjustment in response to pressing the analog demand thumb ring. (Note: Another screen is displayed when this setting is configured.) Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 155 4. Operation in Full Mode Specifying Maximum Zoom Speed Control Specify the maximum speed to which the zoom speed can be adjusted using the drive unit knob. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 156 4. Operation in Full Mode Specifying Minimum Zoom Speed Control Specify the minimum speed to which the zoom speed can be adjusted using the drive unit knob. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...
  • Page 157 4. Operation in Full Mode Specifying Servo Type from Zoom Demand Specify either the speed or position servo as the type of servo to use from the zoom demand. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users”...
  • Page 158 4. Operation in Full Mode Demand-Based Zoom Speed Adjustment ON/OFF Enable or disable adjustment of the maximum drive unit zoom speed based on the zoom demand. Important First, switch to the user for whom the settings apply. (For instructions, see “4.1.3 Switching Users” or “4.2.1 User Screen Settings: Switching Users.”) Initial Top Screen MENU [ Basic ]...

  • Page 159: Focus Screen Settings

    4. Operation in Full Mode 4 . 2 . 7 Focus Screen Settings The following setting items can be configured on the Focus screen. Specifying Focus Demand Responsiveness E157...
  • Page 160 4. Operation in Full Mode Specifying Focus Demand Responsiveness Specify responsiveness in analog focus demand operations as needed. Initial Top Screen Note: These settings take effect when the curve selection MENU switch on the focus demand is set toward FAR. [ Basic ] [Trk]OFF IS   STD...

  • Page 161: Info Screen Settings

    Specifying the 3D Function (For information on specifying the 3D function, see the instruction manual of the BC-100 3D cable.) Specifying Encoder Output Serial Communication with Camera ON/OFF Configuring Settings in System Mode (Used by Canon Service Technicians Only) E159...
  • Page 162 4. Operation in Full Mode Specifying Encoder Output Enable or disable encoder output as needed. Enabling output enables virtual connector output. For details, contact Canon or your dealer. Initial Top Screen MENU [ Basic ] [Trk]OFF IS   STD IS   STD [ I-Gain ]...
  • Page 163 4. Operation in Full Mode Serial Communication with Camera ON/OFF Two types of camera–lens interfaces are available: analog control or control via serial communication. This setting enables you to switch between auto control detection and analog control. By default, this setting is ON, enabling auto detection of whether serial or analog control is used. To restrict the interface to analog control, set it to OFF.

  • Page 164: Fol. Screen Settings

    4. Operation in Full Mode 4 . 2 . 9 Fol. Screen Settings The following setting items can be configured on the Fol. screen. Viewing Lens Follow Settings (Iris, Zoom, Focus) E162...
  • Page 165 4. Operation in Full Mode Viewing Lens Follow Settings (Iris, Zoom, Focus) Indicates values in the full range of mechanical iris, zoom, and focus operations, expressed as relative values in the range of 0–1000. Initial Top Screen MENU [ Basic ] [Trk]OFF [ I-Gain ] Fr1P...

  • Page 166: List Of Settings

    4. Operation in Full Mode 4 . 3 List of Settings Default Value Options MENU 1 on the next page 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 0 [ Basic ] Basic [ Trk ] OFF / ON...
  • Page 167 4. Operation in Full Mode From 4 To Default Value Options MENU User Basic Basic / Analog / Full Mode 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 0 Name - / space / A–Z / a–z / 0–9 −...
  • Page 168 Memo...

  • Page 169: Operation In Analog Mode

    Operation in Analog Mode...

  • Page 170: Configuration From The Top Screen

    5. Operation in Analog Mode 5 . Operation in Analog Mode 5 . 1 Configuration from the Top Screen To access the Top screen, press the Display switch. A total of 3 items can be configured on the Top screen in Analog mode. The first screen displayed is referred to as the Initial Top screen.

  • Page 171: Selecting Analog Mode

    5. Operation in Analog Mode 5 . 1 . 1 Selecting Analog Mode Basic mode is the default mode, but Analog mode can be accessed as follows. Use this mode for operation of a conventional analog drive unit. Digital functions are not available in this mode. •...

  • Page 172: Top Screen

    5. Operation in Analog Mode 5 . 1 . 2 Top Screen A total of 3 items can be configured on the Top screen in Analog mode, and the first screen shown is referred to as the Initial Top screen. Status of some items can be checked simply by accessing this screen.

  • Page 173: Specifying Auto Iris Gain

    5. Operation in Analog Mode 5 . 1 . 3 Specifying Auto Iris Gain [IG] Although this value is factory-set, it can be adjusted as needed. To adjust the value, use either the auto iris gain adjustment trimmer (refer to the Lens Manual) or display operations. Regardless of the method of adjustment used, the most recent setting takes precedence.

  • Page 174: Switching To Basic Mode

    5. Operation in Analog Mode 5 . 1 . 4 Switching to Basic Mode [Basic] Switch to Basic mode from the Top screen as needed. Switching from Analog to Basic Mode Initial Top Screen in Analog Mode IG: 50 MENU [ Basic ] Press [Basic] is highlighted.

  • Page 175: Configuration From The Menu Screen

    5. Operation in Analog Mode 5 . 2 Configuration from the Menu Screen In Analog mode, you can view and configure 2 setting items from the Menu screen. From the Menu screen in Analog mode, you can access a User screen. Select [MENU] on the Top screen and press the Set key to access the User screen.

  • Page 176: User Screen Settings

    5. Operation in Analog Mode 5 . 2 . 1 User Screen Settings The following setting items can be configured on the User Screen. User Screen in Analog Mode Switching Modes Locking Functions User Mode: Analog Access: Unlock E174...
  • Page 177 5. Operation in Analog Mode Switching Modes Switch to Basic or Full mode, as needed. Important The new mode setting is retained even after the lens is turned off. Initial Top Screen IG: 50 MENU [ Basic ] Press User Screen The display switches to the User screen.
  • Page 178 5. Operation in Analog Mode Locking Functions To ensure that configured functions cannot easily be changed, you can lock the settings of certain functions. Once functions are locked, they are locked for all users. Two display operations are available in Analog mode: auto iris gain adjustment and user switching. However, you cannot switch users when functions are locked, because this function is also locked.
  • Page 179 No master password is used on this model. The password you enter each time to lock settings is the password used to unlock them. For this reason, we recommend making a note of the password each time. If you forget the password, contact Canon or your dealer. Passwords can be blank or up to 8 digits. Characters supported in passwords Options ＿－...
  • Page 180 5. Operation in Analog Mode (2) Unlocking Settings Initial Top Screen IG: 50 MENU [ Basic ] Press User Screen The display switches to the User screen. User Mode: Analog Access: Lock Press twice. User The previous or default value is highlighted. Mode: Analog Access:...

  • Page 181: List Of Settings

    5. Operation in Analog Mode 5 . 3 List of Settings Default Value Options Page MENU To *1 on the next page 01–99 [ Basic ] Basic Hold down both the Display switch and Escape Operation Jump to user 0 setting status Set key for at least 2 seconds.
  • Page 182 5. Operation in Analog Mode Default Options Page Value MENU ＊ User Mode Basic Basic / Analog / Full Access Unlock Unlock / Lock Go Top : Set key operation : Right key operation : Up key operation : Left key operation E180...

  • Page 183: Index

    Index ANALOG MODE ............ E22, E167 FULL MODE ............E22, E79 AUX ................. E32, E89 IRIS GAIN .............. E60, E141 BASIC MODE ............E22, E23 IS ................E49, E128 CAMERA SERIAL ..........E73, E161 RET ............... E95, E125 ENCODER ............. E64, E160 VTR ...............
  • Page 185 +1(905)795-2012, +1(905)795-2087 팩스 : (82)2-2191-8576 Mexico South & Southeast Asia Canon Mexicana, S. de R.L. de C.V. Canon Singapore Pte. Ltd. Call Center Div. REG ICP Sales & Marketing Div. Blvd. Manuel Avila Camacho No,138, 1 Fusionopolis Place, #15-10 Galaxis, Col.
  • Page 186 〒 146-8501 東京都大田区下丸子 3-30-2 仕様・外観・商品構成などはお断りなく変更することがあります。 CANON INC. 30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo, 146-8501, Japan Subject to change without notice. 进口商 ： 佳能（中国）有限公司 地址 ： 100005 北京市东城区金宝街 89 号　金宝大厦 15 层 因产品改进，规格或外观可能有所变更，敬请留意。 初版 :2016.8.1 原产地 : 日本 Pub No. B-IM-20246-0 1016S ©2016.08 CANON INC.

Table of Contents
