- Page 1 SQ600WC ATOLL SQUARE EXPOSED THERMO SHOWER VALVE For any further information please contact INSTALLATION INSTRUCTIONS Crosswater on: Or visit our web-site at www.crosswater.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
-
Page 2: Troubleshooting
SQ600WC CLEANING INTRODUCTION CARE OF YOUR SHOWER VALVE & RISER Please read these instructions carefully and keep in a safe place for future reference. We recommend cleaning the valve with a soft damp cloth. General Installation Requirements We strongly advise against the use of ALL cleaning products. The installation must comply with regulations of the Local Water Authority as contained in SHOWER ROSE &... -
Page 3: Installation
SQ600WC INSTALLATION MAINTENANCE Before carrying out any maintenance please remember to turn OFF all mains water and turn ON the isolating valves. THERMOSTATIC CARTRIDGES The concealed thermostatic valve should give trouble free service, but in the event of HOT INLET failure, servicing is straight forward. -
Page 4: Operation
SQ600WC DIMENSIONS OPERATION Turn the Flow control handle away from you to increase the flow of water to the shower rose. To divert the water to the handset press the button and turn the control handle towards you. Return the control handle to the upright position with the button on top to turn off the flow of water. -
Page 5: Temperature Setting
SQ600WC TEMPERATURE SETTING INSTALLATION Removing the handle/cover - unscrew (but do not remove) the hexagonal grub screw on First shut off your water heating system then, with your mains stop cock closed, open the underside of the handle/cover, pull off the handle/cover. the lowest hot and cold taps in the house and allow to run until the cold storage tank and Rotate the exposed thermostatic spindle (clockwise for cold, and anti-clockwise for hot) pipes are empty (the hot water storage cylinder always remains full). - Page 6 SQ600WC INSTALLATION INSTALLATION INSTALLATION WALL PLUGS RISER Warning! Please check for any hidden pipes and cables before drilling holes RISER SCREW in the wall. Fixing the riser Mark a vertical center line from the valve up the wall, slide the riser support onto the riser FIBRE WASHER BRACKET from the bottom followed by handset holder, temporally position the riser into the valve.
