3. Using a 5/16" open end wrench, loosen the SMA connector on the end
of the semi- rigid cable that is connected to the PC board.
4. Slide the Option 106/115 assembly to the rear of the chassis, as neces-
sary, to expose the two gold- connectors at the front of the motherboard
near the front panel (J101 and J201).
Ultra-High Stability Timebase (Option 010)
NO TE
NO TE
GPIB Interface (Option 400)
•
•
•
•
53210A/53220A/53230A Option Installation
Option 010 (Ultra-High Stability Timebase) must be performed by technicians at an
Agilent Technologies Service Center. Go to www.agilent.com/find/assist for
information on contacting Agilent in your region, or contact your Agilent Technol-
ogies Representative.
To order the Ultra-High Stability Option 010, you will need to place an order with
Agilent for 53200U-010 and identify which counter you have (Agilent 53210A,
53220A, or 53230A).
Option 400 GPIB Connector Parts (53200U - 400)
Item
PC Board Assembly
Ribbon Cable, 16-pin
7mm Hex-head standoff
Washer, lock
53210A/53220A/53230A Option Installation
Agilent Part No.
P0001-63001
53200-61601
0380-0644
2190-0577
Qty.
1
1
2
2
7
