30 Amp Digital Switching Power Supply
Electrical specifications
Note: Specifications may change without prior notice
User information
The NS-1230D power supply enable you to run almost any electronic product.
Check the main supply voltage
Before you plug in and turn on the power supply for the first time, please check the main
supply voltage.
The voltage rating of the power supply is printed on a label on the cover of the unit. Verify
that it corresponds with your local main supply voltage (that is factory fixed at 110VAC).
Turning the power supply on
Turn the power supply on by pressing the power switch to the 'ON' Position.
Turning the power supply off
Before you turn the power supply off, turn the radio off as described in the user
documentation for the radio.
Turn the power supply off by pressing the power switch to the 'OFF' Position
Cooling
The NS-1230D power supply is cooled by convection and forced air cooling. That is normal
airflow around the power supply in combination with a temperature controlled fan to improve
cooling at higher levels of use. The fan is always activated and the speed is controlled by a
sensor. When the temperature rises, the fan speed increases.
NS-1230D
Model
Input Voltage
Input Frequency
Polarity Grounded
Output Voltage
Continuous (13.8V)
Surge(13,8V)
Ripple & Noise
Efficiency
Dimension(L*W*H mm)
Net Weight
User Manual
100~120V AC Fixed
(or 200~240V AC fixed)
47Hz ~ 63Hz
Negative
DC 5V~16V Adjustable
25A
30A
<100mV
75%
154 x127x63 (6"x5"x2.5")
1.35 kg (3.4 lB)
NS-1230D
Advertisement
Related Manuals for Nissei NS-1230D
Summary of Contents for Nissei NS-1230D
-
Page 1: Electrical Specifications
Turn the power supply off by pressing the power switch to the ’OFF’ Position Cooling The NS-1230D power supply is cooled by convection and forced air cooling. That is normal airflow around the power supply in combination with a temperature controlled fan to improve cooling at higher levels of use. -
Page 2: Front Panel
2. Connect the power cable’s positive (red) wire to the positive terminal and connect the negative (black) wire to the negative terminal on the back of the power supply. 3. Plug the power cable into the power socket on the back of the radio. Panel Description: NS-1230D Front panel: 1. Power indicator 2. -
Page 3: Important Safety Information
Important safety information Please read these warnings before using the NS-1230D power supply. Warning: Safe operation To reduce the risk of fire or electric shock, please adhere to these warnings: Moisture: Do not expose this appliance to water or moisture.
