Replacing the stylus

1
Push the arm lock to
release the tone arm.
6
Make sure the audio-
lines are not touching
each other.
7
Carefully slide the
cartridge into the
cartridge holder.
12 | REMOTE CONTROL
2
2
Take off the cap of the
cartridge to expose
the needle.
5
Carefully insert the audio-
line connector to the new
cartridge.
8
Gently clip the cartridge
into the cartridge holder.
3
3
Separate the cartridge
from the cartridge
holder by loosening
the locker.
4
Gently pull the audio-
lines from the cartridge,
pull from the terminal
connector and not the
wire itself.
Be very careful when changing
the stylus cartridge, to avoid
damage to the tone arm and
audio wires.
