Page 1 OPERATOR'S MANUAL DG1500E MODEL : DG1500 DG3050E(R) DG3050 DG3500E(R) DG3500 DG4650 DG4650E(R) DG4950 DG4950E(R) DG5750 DG5750E(R) DG6500 DG6500E(R) DG7750 DG7750E(R) DG9250 DG9250E(R) DG11050 DG11050E(R) WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
Page 2: Table Of Contents
Table of Contents Fore ward....................3 Safety Precautions..................4 Safety Specifications................. 5 Safety Regulation..................6 Warning Labels..................7 Product Specifications................8 Component Identification.................9 Features.....................10 Operating Guide..................11 Operating....................12 Power Management..................14 Maintenance....................15 Trouble Shooting Guide................18 Remote Start.....................19 Electrical Schematic Diagram..............20...
Page 3: Foreward
Foreward Thank you for buying DUCAR generator unit. This product is a household generator which produces electrical power by means of an engine driving a alternator, and is used in situations where electricity supply is interrupted or as a primary source of power supply where power is unavailable.
Page 4: Safety Precautions
Safety Precautions Danger: Use outdoors only, exhaust gas Danger: Do not connect the released from the equipment contains Carbon generator unit with mains supply or other Monoxide (CO), which cannot be seen or smelt. power sources , use it alone. Excessive inhalation of CO may cause a loss of consciousness and may claim life in extreme circumstances.
Page 5: Safety Specifications
Safety Specification Danger: Electrocution hazard - Electricity can cause DEATH or SERIOUSINJURY  DO NOT use bare wire to connect power supply to electrical equipment, use a plug that meets local regulations.  During generator operation, do not touch exposed wires. ...
Page 6: Safety Regulation
Safety Regulations There is the warning decal on the machine to remind you of the safety regulations. FOR ELECTRICAL EQUIPMENT ONLY/ POUR MATERIEL ELECTRIQUE SEULEMENT FOR USE IN A WEATHER PROTECTED WELL VENTILATED AREA EMPLOYEZ UNIQUEMENT DANS UN EMPLACEMENT A L'ABRI DES INTEMPERIES ET BIEN AERE NEUTRAL BONDED TO FRAME NEUTRE MIS À...
Page 7: Warning Labels
Warning Labels Some of following symbols are used in the machine or the manual. To understand their meanings will make it easy and safe for you in operation. Symbol Name Meaning Volt Voltage Unit Ampere Current Unit Hertz Frequency Unit (1Hz=60 r/min) Watt Power Unit Revolution Per Minute...
Page 8: Product Specifications
DG1500 DG3050 DG3500 DG4650 DG4950 DG5750 DG6500 DG7750 DG9250 DG11050 Model DG1500E DG3050E(R) DG3500E(R) DG4650E(R) DG4950E(R) DG5750E DG6500E(R) DG7750E(R) DG9250E(R) DG11050E(R) Frequency 60HZ Voltage 120V 120V/240V Power factor 1.40kW 2.50kW 2.80kW 3.60kW 4.00kW 5.00kW 5.50kW 6.25kW 7.50kW 9.00kW Rated Power Peak Power 1.50kW...
Page 9: Component Identification
Component Identifaction Fuel tank Oil tank cap Control Panel AC Circuit Breaker AC output Chock valve Fuel Valve Engine switch Air filter Recoil Starter Grip Wheel Handle & Grips Oil drain Plug Spark plug Carburetor Cylinder head Muffler...
Page 10: Features
Features KNOW YOUR GENERATOR GROUND TERMINAL The safe use of this generator requires an The ground terminal is used to assist in understanding of the information provided inthis operator’s manual as well as a properly grounding the generator to help knowledge of the project you are attempting.
Page 11: Operating Guide
Operating Guide Unit grounding Shift the machine outdoors, use the grounding terminal connection wire to ground to earth. One end of the wire is pressed below the butterfly nut on the unit, screw it up tightly, and the other end is connected with the metal rod that is inserted into the ground. Pre-operational Add engine oil Open the fuel fill cap and fill with a Ethanol...
Page 12: Operating
Operation b. For the manual start generator by pulling the Starting the Engine recoil starting grip until the engine runs. NOTE: 1. Unplug all loads from the generator. Do not allow the grip to snap back after starting; return it gently to its original place. Allow the engine to run for 10-20 seconds, then move the choke lever to the RUN position.
Page 13 Operation Stopping the Engine To stop the unit quickly in an emergency: Turn the engine switch to the OFF position. 1. Remove any load from the generator. Warning: The surface temperature of the generator unit are still high after shutdown, and it should not be moved or touched before cooling down to avoid the possibility of burns.
Page 14: Power Management
Power Management Electric equipment Rated power(W) Starting power(W) Flat panel television 27" Energy saving lamp 5~50 5~50 Electric cooker 1000 1000 Computer Household Appliances Refrigerator 1600 Washing machine Electric fan Air-conditioner 2HP 1500 3000 Electric welder 2500 5000 Tools Electric hammer 1000 1500 Water pump...
Page 15: Maintenance
Maintenance Regular maintenance is the best guarantee of safe, economical and fault-free operation, and can also contributes to environmental protection. Maintenance schedule is as follows- Please carry out the recommended maintenance at the earlier of the stated hours or elapsed time. Every Every 20 Every 50...
Page 16 Maintenance Clean the air filter Foam filter element Air filter element Air filter cover Bolt The air cleaner system uses a foam element that can be washed and reused. 1. Open the cover with the lock nut and remove the foam air filter element. 2.
Page 17 Maintenance Clean the spark plug Recommended spark plug models: NGK: BPR7ES. Champion RN7YC. Spark plug socket spanner Spark plug cap 1 Remove the spark plug cap. 2 Clean the spark plug base. 3 Remove the spark plug with the spark plug socket spanner. 4 Inspect the spark plug insulator visually for damage.
Page 18: Trouble Shooting Guide
Trouble Shooting Guide Fault Cause Action No fuel Fill the oil tank with gasoline The Fuel valve is not turned Turn the fuel valve to ON The Fuel valve is blocked Clean the fuel bowl (refer to page 16) The unit can not No engine oil or the engine start Add oil...
Page 19: Remote Start
Remote start Remote start: Aim remote start the gasoline engine (distance between more than 50m). Requirement: 1. Turn off the machine manually after remote starting is acceptable; 2. Turn off the machine by remote key after manually start is acceptable; 3.
Page 20: Electrical Schematic Diagram
Recoil Start...
Page 21 Recoil Start...
Page 22 Remote Start schematic diagram...
Page 23 Remote Start schematic diagram...
Page 24 Electrical schematic diagram...
Page 25 Recoil Start...
