HEED Questar User Manual

questar_guide1.1.qxd 2009.07.23.
TECHNICAL SPECIFICATIONS
Input:
Gain:
Frequency response:
THD (at 0 dB, 1 kHz):
Signal-to-noise ratio (A-weighted):
Headroom:
Channel separation:
Power consumption:
Dimensions:
Weight:
WARRANTY
If within three years of the purchase date your Heed QUESTAR proves
to be defective for any reason other than accident, misuse, neglect,
unauthorised modification or fair wear and tear, Heed Audio Ltd. will,
at its discretion, replace the faulty parts without charge for labour.
This factory warranty is valid only for units sold into countries with no
appointed Heed distributor. Service enquiries in countries with
appointed distributor should be addressed first to the supplying
dealer and or Heed distributor/importer. Warranties granted in
these countries are entirely at the discretion of distributor.
DISTRIBUTOR CONTACT
FACTORY CONTACT
HEED Audio Kft. (Ltd.)
Reviczky Gyula u. 9-11
H-1181 Budapest
Hungary
11:50 Page 1
3 mV/47 kOhm (Questar MM)
220 µV/100 Ohm (Questar MC)
42 dB (Questar MM)
64 dB (Questar MC)
20 Hz — 20 kHz/± 0,3 dB
0.02 %
82 dB (Questar MM)
74 dB (Questar MC)
20 dB (Questar MM)
18 dB (Questar MC)
50 dB (1 kHz)
<10 W
9x6x22 cm (W/H/D)
0.9 kg (PSU: 0.4 kg)
Tel/Fax: +36 1 2947401
Email: info@heedaudio.hu
Web: www.heedaudio.com
Heed Questar Users Manual 1.1 (2009)
Heed QUESTAR
Phono Preamplifier
Thank you for choosing our product!
The Heed QUESTAR is an excellent value-for-money phono
stage for the discerning music lover on a budget. In terms of
music reproduction, it is head and shoulders above the vast
majority of its direct competitors. A broad range of middle-
priced turntables and cartridges perform at their best with this
genuinely musical device.
We sincerely hope that you will agree, and that your QUESTAR
will provide you with many years of impeccable, trouble-free
operation.
Happy listening!
The Heed Team
The functions and operation of the QUESTAR are extremely simple and
straightforward. The following notes are provided to explain all aspects of
its installation and use, primarily as phono preamplifier but also in general
as a domestic audio component.
Please read them carefully.
