- Page 3 ___________________ Line filter Safety information ___________________ General ___________________ Mechanical installation SINAMICS ___________________ Electrical installation SINAMICS G120P ___________________ Line filter Technical specifications Operating Instructions Control version V4.6 11/2013 A5E32844996B AA...
- Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 5: Table Of Contents
Table of contents Safety information ........................... 7 Warnings ............................7 Safety and application instructions ....................8 Components that can be destroyed by electrostatic discharge (ESD) .......... 9 General ..............................11 Mechanical installation .......................... 15 Electrical installation..........................17 Technical specifications ........................19 Line filter Operating Instructions, 11/2013, A5E32844996B AA... - Page 6 Table of contents Line filter Operating Instructions, 11/2013, A5E32844996B AA...
-
Page 7: Safety Information
Safety information Warnings WARNING Dangerous electrical voltage Hazardous voltages are present when electrical equipment is in operation. Severe personal injury or substantial material damage may result if these warnings are not observed. Only qualified personnel are permitted to work on or around the equipment. These personnel must be thoroughly familiar with all the warnings and maintenance procedures described in these operating instructions. -
Page 8: Safety And Application Instructions
The Operating Instructions and machine documentation are written in different languages as specified in the delivery contracts. Note Support by SIEMENS service centers We recommend engaging the support and services of your local Siemens service center for all planning, installation, commissioning and maintenance work. Line filter Operating Instructions, 11/2013, A5E32844996B AA... -
Page 9: Components That Can Be Destroyed By Electrostatic Discharge (Esd)
Safety information 1.3 Components that can be destroyed by electrostatic discharge (ESD) Components that can be destroyed by electrostatic discharge (ESD) CAUTION Components sensitive to electrostatic charge The board contains components that can be destroyed by electrostatic discharge. These components can be easily destroyed if not handled properly. If you do have to use electronic boards, however, please observe the following: •... - Page 10 Safety information 1.3 Components that can be destroyed by electrostatic discharge (ESD) Line filter Operating Instructions, 11/2013, A5E32844996B AA...
-
Page 11: General
General Description The line filters limit the conducted interference emitted by the converter units to permissible values. To reduce emissions, the Power Modules are equipped as standard with a line filter in accordance with the limit values defined in category C3 (environment 2). The additional line filters described here can be fitted for use in environment 1 (category C2). - Page 12 NOTICE Use only approved line filters Using line filters not approved by SIEMENS for SINAMICS can lead to line-side harmonics that can interfere with or damage other loads powered from the network. NOTICE Component cooling Provisions for component cooling must be made at the installation site.
- Page 13 General Assignment of line filter and Power Module Table 2- 1 Assignment of line filter and Power Module Power Module Unit rating of the Power Module Suitable line filter Line voltage 380 – 480 V 3 AC 6SL3310-1PE33-0AA0 160 kW 6SL3000-0BE33-1AA0 6SL3310-1PE33-7AA0 200 kW...
- Page 14 General Line filter Operating Instructions, 11/2013, A5E32844996B AA...
-
Page 15: Mechanical Installation
Mechanical installation When the line filter is installed in a cabinet, it must be positioned directly beside the Power Module. The line reactor must be positioned between the line filter and Power Module. Cabling must be kept as short as possible. To prevent interference being injected into the interference-suppressed line cable (this can, in some cases, nullify the effects of the line filter), the line cable to the line filter must be routed separately from other cables. - Page 16 Mechanical installation Dimension drawing Figure 3-1 Dimension drawing, line filter Table 3- 1 Dimensions of the line filter (all data in mm) 6SL3000- 0BE33-1AA0 78.2 Lengths n1 and n2 correspond to the distance between holes Line filter Operating Instructions, 11/2013, A5E32844996B AA...
-
Page 17: Electrical Installation
Electrical installation Important safety precautions WARNING Dangerous electrical voltage The devices are operated with high voltages. All connection work must be carried out in a no-voltage condition! All work on the device must be carried out by trained personnel only. Death, serious injury, or substantial material damage can result if these warning notices are not observed. - Page 18 Electrical installation Connection When connecting the line filter and line reactor, you must take into account the following conditions to ensure that they function correctly: ● Use shielded control cables. The shield must be connected at both ends. ● With analog control cables, connecting the shield at both ends can result in coupled-in noise.
-
Page 19: Technical Specifications
Technical specifications General technical data Table 5- 1 General technical data Line frequency 47 ... 63 Hz Product standard EN 61800-5-1 Overload capacity 1.60 x I for 3 s followed by 1.36 x I for 60 s followed by 1.00 x I for 240 s Specific technical data Table 5- 2... - Page 20 Technical specifications Line filter Operating Instructions, 11/2013, A5E32844996B AA...
