- Page 1 User Manual MOPPING ROBOT...
-
Page 2: Table Of Contents
Contents Overview ..................4 Device parts ..................6 Device parts (instalment) ............... 7 Information about these operating instructions ......8 Proper use ..................10 Safety information ................. 11 Safe handling of batteries/rechargeable batteries .......15 Package contents ................17 Using the appliance for the fi rst time .......... 18 Charging the wiper robot ..............18 Attaching the cleaning rollers ............19 Attaching the wiper lip ................19... -
Page 6: Device Parts
Device parts Device parts Main Unit Underside of main unit and water tank Unlocking the water tank Drop sensors Handle Charging contacts Bumpers Front drive wheel Wheels Clean water nozzles Locking pin for the air intake and dirty Dirty water drain water suction ports Control fi... -
Page 7: Device Parts (Instalment)
Device parts (instalment) Device parts (instalment) Remote control Forwards control Right turn control Cleaning mode: Automatic cleaning Cleaning mode: Cleaning along a wall Operating mode: Return to starting point Cleaning mode: Surface cleaning Reverse control Left turn control Cleaning mode: Spot cleaning... -
Page 8: Information About These Operating Instructions
Information about these operating instructions Information about these operating instructions Thank you for choosing our product. We hope you enjoy using it. Read the safety instructions and all other instructions carefully before using the device for the fi rst time. Note the warnings on the device and in the operating instructions. - Page 9 Information about these operating instructions Products that feature this symbol meet the requirements of the EC directives (see section ‘Declaration of conformity’) Please follow the guidelines in the operating instructions. • Bullet point/information on operating steps and results − Tasks to be performed Safety instructions to be performed −...
-
Page 10: Proper Use
Proper use Only use charging station provided. Indoor use Appliances with this symbol are intended solely for indoor use. Dispose of the appliance in compliance with environmental regulations (see “9. Disposal” on page <?>) IP20 The AC/DC adapter offers protection class IP20 in compliance with DIN EN 60529. -
Page 11: Safety Information
Safety information − Only use replacement parts or accessories that we have supplied or approved. − Comply with all the information in these operating instructions, especially the safety information. Any other use is considered improper and can cause personal injury or property damage. Safety information WARNING! Risk of injury! - Page 12 Safety information DANGER! Risk of electric shock! Live parts. There is a risk of electric shock/short circuit. − Use the supplied mains adapter and the charging station to charge the batteries. − The mains adapter may only be used in dry rooms. −...
- Page 13 Safety information − Never immerse the wiper robot, charging station or mains adapter in water or other liquids! Always unplug the mains adapter from the socket before cleaning or servicing the appliance and before fi tting or removing accessories. − Do not expose the appliance to extreme conditions. Avoid: –...
- Page 14 Safety information − Remove all fragile items (e.g. glass, lamps, vases) and objects that could become trapped in the brushes or sucked up (e.g. cords, clothing, newspapers, curtains) from the working area before operating the appliance. − Do not cover the sensors and ventilation slots on the wiper robot.
-
Page 15: Safe Handling Of Batteries/Rechargeable Batteries
Safety information − The stair height must be at least 8 cm. − Do not stand beneath unsecured edges or stairs when the appliance is in use. − Clean the sensors on the wiper robot regularly. − Do not place the charging station close to heat sources. Safe handling of batteries/rechargeable batteries This appliance contains a lithium-ion battery block. - Page 16 Safety information WARNING! Risk of explosion! There is a risk of explosion if batteries are replaced incorrectly! − Always use new batteries of the same type. Never use old and new batteries together. − Pay attention to the polarity (+/–) when inserting the batteries. −...
-
Page 17: Package Contents
Package contents Package contents DANGER! Risk of choking and suffocation! Risk of choking and suffocation through swallowing or inhaling small parts or plastic wrap. − Keep the plastic packaging out of the reach of children. Please check your purchase to ensure that all items are included. If anything is missing, please contact us within 14 days of purchase. -
Page 18: Using The Appliance For The Fi Rst Time
Using the appliance for the fi rst time Using the appliance for the fi rst time Charging the wiper robot The wiper robot is fi tted with a lithium-ion battery block. After unpacking the appliance, fi rst charge the battery block for approx. 4.5 hours. This benefi ts battery performance in the long run. -
Page 19: Attaching The Cleaning Rollers
Using the appliance for the fi rst time − Guide the cable out of the charging station through one of the four cable guides. − Connect the mains adapter to a socket. − Position the charging station in a quiet and safe location on the ground and place the wiper robot on the charging station. -
Page 20: Filling The Water Tank
Using the appliance for the fi rst time Filling the water tank − Lift the handle and press the unlocking mechanism for the water tank. − Lift up the water tank and turn it around. − Open the clean water tank cover. −... -
Page 21: Attaching The Water Tank
Using the appliance for the fi rst time − If the area to be cleaned is covered with coarse dirt, add one or two drops of non-foaming, pH-neutral detergent to the water. − Clean the fi ller opening and closing cap of the clean water tank with a cloth so that the tank always remains clean and closes tightly. -
Page 22: Cleaning Mode
Cleaning mode − Replace the battery compartment cover on the battery compartment and close the cover until you hear it latch into place. Cleaning mode To achieve the best cleaning performance, ensure that all loose objects (curtains, clothing, paper, loose cables and extension cables) are removed from the fl oor. NOTICE! Possible material damage! Loose cabling can get caught around your wiper robot during... -
Page 23: Sleep Mode
Cleaning mode Sleep mode − Use the remote control to start a cleaning mode of your choice (for instance − Press the same button on the remote control again (here: The wiper robot interrupts the current cleaning program and comes to a stop. After about 3 minutes, the LEDs on the appliance go out and a signal tone sounds. - Page 24 Cleaning mode Surface mode After switching on, the wiper robot cleans an area of 25 m² in front of the appliance. The wiper robot covers the area in a zigzag pattern and returns to the starting point once the cleaning is fi nished. Automatic mode This cleaning mode is ideally suitable for large areas and performs a standard cleaning, depending on obstructions.
-
Page 25: Spot Cleaning
Cleaning mode Spot cleaning This cleaning mode is suitable for cleaning an area (80 x 80 cm) around the starting point of the wiper robot. The wiper robot covers the area in squares and returns to the starting point once the cleaning is fi nished. 0.8 m Cleaning along a wall This cleaning mode is ideally suitable for cleaning the corners and edges of a room. -
Page 26: Manual Control Of The Wiper Robot
Cleaning and storage Manual control of the wiper robot − By pressing the ; ; and buttons. − The wiper robot can be recalled to its starting point by pressing the button. − Empty the dirty water tank after each cleaning and clean the appliance as described in section “7. -
Page 27: Cleaning The Dirty Water Tank
Cleaning and storage Your wiper robot is easy to clean and maintain. Empty the dirty water tank, and clean the cleaning roller, wiper lip and fi lter before each use. • Do not use any solvents or caustic/gaseous cleaning agents to clean the appliance’s surfaces. -
Page 28: Cleaning The Cleaning Rollers And Wiper Lip
Cleaning and storage − Pour the water out again. − Make sure there are no detergent or dirty water residues in the tank and rinse the tank thoroughly with clean water. − Clean the discharge opening and closing cap of the dirty water tank with a cloth so the tank always remains clean and closes tightly. -
Page 29: Cleaning The Air Fi Lter
Cleaning and storage − Clean both parts under running water. − If hairs or similar obstructions have become wrapped around the cleaning roller, remove these too. − Allow the cleaning roller and wiper lip to dry in the air after cleaning. Cleaning the air fi... -
Page 30: Cleaning The Air Intake And Suction Port
Cleaning and storage Cleaning the air intake and suction port − Press down the locking pin for the air intake and dirty water suction ports. − Rinse both openings with running water. − Then pour the water out of the dirty water tank again. Cleaning the front wheel −... -
Page 31: Energy Management For The Wiper Robot
Troubleshooting Energy management for the wiper robot You use the wiper robot occasionally If you do not intend to use the wiper robot several times a day, daily or regularly for cleaning, we recommend disconnecting the charger and/or mains adapter from the socket each time after it is fully charged. -
Page 32: Voice Outputs
Troubleshooting Voice outputs Voice output Symbols on Possible cause Solution control panel PLEASE CHECK The water tank is − Check whether : lights up AND INSTALL not in the appliance the water WATER TANK or has not been tank has been : lights up attached properly. -
Page 33: Other Faults
Disposal Voice output Symbols on Possible cause Solution control panel PLEASE PUT The wiper robot is − Place the wiper : lights up ROBOT BACK not on the ground. robot back on the TO GROUND ground. : lights up PLEASE CHECK The bumper is −... - Page 34 Disposal Appliance All old appliances marked with the symbol illustrated must not be disposed of in normal household waste. In accordance with Directive 2012/19/EU, the appliance must be properly disposed of at the end of its service life. This involves separating the materials in the appliance for the purpose of recycling and minimising the environmental impact.
-
Page 35: Technical Specifi Cations
0.6 A Remote control Battery operation 2x 1.5 V type AAA Declaration of Conformity MEDION AG hereby declares that the product conforms to the following European requirements: • EMC Directive 2014/30/EC • Low Voltage Directive 2014/35/EC • Ecodesign Directive 2009/125/EC • RoHS Directive 2011/65/EU. -
Page 36: Service Information
• In our Service Community, you can meet other users, as well as our staff, and you can exchange your experiences and pass on your knowledge there. You will fi nd our Service Community at http://community.medion.com. • Alternatively, use our contact form at www.medion.com/contact. -
Page 37: Privacy Statement
Privacy statement Privacy statement Dear customer, We wish to inform you that we, MEDION AG, Am Zehnthof 77, 45307 Essen, Germany process your personal data as a data controller. For matters regarding data protection, we are supported by our company data protection offi... -
Page 38: Legal Notice
These operating instructions are protected by copyright. Mechanical, electronic and any other forms of reproduction are prohibited without the written permission of the manufacturer. Copyright is owned by the company: MEDION AG Am Zehnthof 77 45307 Essen Germany Please note that you cannot use the address above for returns. Please always contact... - Page 39 PRODUCED IN CHINA FOR: MEDION AG AM ZEHNTHOF 77 45307 ESSEN GERMANY AFTER SALES SUPPORT 21589 0333 3213106 1 800 992508 Standard local land- Free hotline line call rate www.medion.co.uk YEARS MODEL: WARRANTY 11/2019 MD 18999...
