Fresh Freezing Compartment - Panasonic NR-F603GT-X6 Operating Instructions Manual

When the temperature setting of the prime fresh/chilled select room is set to "1", "2" and "3", Prime Fresh Quick
Mode is set and operated automatically.
■
While Prime Fresh Quick Mode is operated, cold air comes out more than usual
and the time to freeze foods partially is reduced.
●
When closing the flap of the case, the select room lamp (LED) is turned from light blue to
blue, and Prime Fresh Quick Mode starts and automatically ends. (The select room lamp
is turned to light blue after the completion of Prime Fresh Quick Mode.)
●
Depending on usage state, Prime Fresh Quick Mode may start with a delay.
●
It may take longer time to freeze foods partially depending on types of food, packing
conditions, amount stored and the operating situation.
●
When storing in the case, put your food within the height of the case.
(Foods may fall in the back from the case and the flap may not be closed firmly and
sensor detection may not work correctly.)
●
While Prime Fresh Quick Mode is on, the sound becomes slightly louder and energy
consumption increases more than usual.
In these cases, Prime Fresh Quick Mode time may become shorter
or Prime Fresh Quick Mode may not start.
• When amount of food stored is small, or when refrigerator judges that Prime Fresh Quick Mode is not
necessary because the temperature of food is low enough.
• Immediately after Prime Fresh Quick Mode ends. (to avoid that the food is cooled too much).
• During defrosting.

Fresh Freezing compartment

■
Freeze ingredients or heated food such as hot rice instantly to keep the freshness of them.
Press .
The function setting
section appears. (The
indicator of function
currently activated is lit.)
Press to set
Fresh Freezing function.
When setting is
completed,
turns on.
While Fresh Freezing is operated,
When Fresh Freezing is completed,
3 conditions of delicious Fresh Freezing
Tightly wrap the food.
Make the food closely contact
with the aluminum plate.
Wrap hot food too.
Aluminum plate
Using "QUICK MODE"
•When "Fresh Freezing" or "Quick Ice Making" has been set.
Using "FRESH FREEZING"
is lit.
turns off.
●
Wrap the food with plastic wrap or place it in freezer
storage packs, and put it on the aluminum plate.
●
Fresh Freezing ends automatically after
approximately 150 minutes.
●
When you want to stop Fresh Freezing in the
middle, do the same operation as described on the
left.
●
When food is stored for long periods after Fresh
Freezing, store it in the freezer compartment.
●
You can use as a freezer compartment when the
Fresh Freezing does not operate.
●
Store ice creams which contain much milk fat etc. in
the freezer compartment.
●
Do not put bottles or cans. (They may split or burst.)
●
Do not put food that is taller than the case. (It
will prevent the door from being closed properly,
resulting in frost.)
●
During Fresh Freezing, energy consumption
increases more than usual.
●
Prime Fresh Quick Mode or ECONAVI does not
operate when Fresh Freezing has been set.
Operation
During Prime Fresh
Quick Mode the select
room lamp (LED) is lit
in blue
Wrap the food with
plastic wrap or place
the food in freezer
storage packs. Do not
stack them on top of
each other.
Approx. -19 °C ~ -17 °C
13
