Tiger Explorer XR Series
1. Thoroughly clean the inside and outside of the airbox.
Note
The air filter will only fit one way, do not force fit the air filter element.
2. Fit the air filter element into the airbox lower section as noted for removal.
3. Refit the airbox upper section and tighten the fixings to 1.5 Nm.
4. Reconnect the multiplug to the air temperature sensor.
Refit the fuel tank (see Fuel Tank - Installation).
Reconnect the battery positive, (red) lead first and tighten the terminals to 4.5 Nm.
Refit the rider's seat (see Rider's Seat - Installation).
Engine Electronic Control Module (ECM) - Removal
Before starting work, ensure the motorcycle is stabilised and adequately supported. This will help prevent it
from falling and causing injury to the operator or damage to the motorcycle.
Turn the ignition to the OFF position and wait at least 1 minute for the engine ECM to complete its power down
sequence.
Remove the rider's seat (see Rider's Seat - Removal).
Remove the battery (see Battery Removal).
Remove the fuel tank (see Fuel Tank - Removal).
Remove the seat bridge (see Seat Bridge - Removal).
Remove the engine ECM from its housing and disconnect the two electrical connectors (see Electrical
Connectors).
Engine Electronic Control Module (ECM) - Installation
Before starting work, ensure the motorcycle is stabilised and adequately supported. This will help prevent it
from falling and causing injury to the operator or damage to the motorcycle.
Fit the ECM into the under seat tray and reconnect the two connectors (see Electrical Connectors).
Refit the seat bridge (see Seat Bridge - Installation).
Refit the fuel tank (see Fuel Tank - Installation).
Refit and connect the battery (see Battery Installation).
Refit the rider's seat (see Rider's Seat - Installation).
Note
If a new Engine ECM is fitted it will need to be paired with the Chassis ECM as described in the
Safety/Security section of the Triumph diagnostic software.
Intake Air Temperature Sensor - Removal
Before starting work, ensure the motorcycle is stabilised and adequately supported. This will help prevent it
from falling and causing injury to the operator or damage to the motorcycle.
Remove the rider's seat (see Rider's Seat - Removal).
Disconnect the battery, negative (black) lead first.
318 of 746
WARNING
WARNING
WARNING
FUEL SYSTEM / ENGINE MANAGEMENT
