TMEZON MZ-IP-V739B User Manual

Ip 7 inch indoor monitor.
Hide thumbs Also See for MZ-IP-V739B:
Table of Contents

Advertisement

Quick Links

Contact us
Manufacturer:Zhuhai Tmezon Technology Co.,Limited
ADD: No.6.Pingbei 2nd.Rd,Nanping Science and Technology Industrial Community,
Zhuhai City,Guangdong,China
Official Website: http://www.tmezon.com
Technical Support: support@tmezon.com
Statement
* If there is any doubt or disputable regarding information in this manual, you can call our
company for clarification.
* There maybe some differences between the descriptions provided here and the actual
devices, as our products are constantly developing and upgrading. We apologize if this
manual does not contain all of the latest updates. Thanks.

OPERATION INSTRUCTION

IP 7 Inch Indoor monitor
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MZ-IP-V739B and is the answer not in the manual?

Questions and answers

Danyal
March 29, 2025

When someone rings the doorbell from outside, there is no sound of the bell ring alert from the monitor inside the house

User image 67e8076f1a33c
0
1 comments:
Mr. Anderson
March 29, 2025

There is no sound from the TMEZON MZ-IP-V739B monitor when the doorbell is rung because the Silence Mode is enabled. In Silence Mode, the indoor monitor is muted during the set time period, so it will not produce sound when a visitor calls or an alert occurs.

This answer is automatically generated

0

Related Manuals for TMEZON MZ-IP-V739B

Summary of Contents for TMEZON MZ-IP-V739B

  • Page 1: Operation Instruction

    OPERATION INSTRUCTION IP 7 Inch Indoor monitor Contact us User Manual Manufacturer:Zhuhai Tmezon Technology Co.,Limited ADD: No.6.Pingbei 2nd.Rd,Nanping Science and Technology Industrial Community, Zhuhai City,Guangdong,China Official Website: http://www.tmezon.com Technical Support: support@tmezon.com Statement * If there is any doubt or disputable regarding information in this manual, you can call our company for clarification.

  • Page 2: Limitation Of Liability

    We provide all-day mail service. Handle the appliance with care. Do not strike or shake, as this may damage the device. ※ Please send email to: support @tmezon.com...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 3. Web Browser Operation ................31 LIMITATION OF LIABILITY................1 3.1 Running Environment................31 DISCLAIMER OF WARRANTY.................1 3.2 Quick Setting..................31 SAFETY INSTRUCTIONS................1 3.3 System Login ..................33 CARING FOR THE ENVIRONMENT BY RECYCLING........2 4. Port Forwarding..................35 COPYRIGHT STATEMENT................2 5.

  • Page 4: Description Of The Indoor Monitor

    1. Description Of The Indoor Monitor 1.3 Note On Wiring Connection 1.1 Fittings The electric lock/source/camera is not include in the package, you can purchase an electric lock which is suitable for your need. For indoor monitor In the standard delivery the system supports locks with Normally Open (N.O.) door unlocking Screw anchors Bracket Indoor monitor...
  • Page 5 Note ※ The indoor monitor with built-in power supply can be connected directly to the plug or connected to the power box. If your 4 core cable doesn’t built with the white terminal, you can connect with the 4 pin connector we provided ※...

  • Page 6: Wiring Diagram

    NOTE: AUDIO VIDEO VIDEO * Avoid installation of the device near strong radiation e.g. TV set and PC etc. AC/DC power DOOR1 CAM 1 adapter for * Maintenance should be complied with a qualified technician. AUDIO camera AUDIO * Avoid hard shake , beating and collision, otherwise the internal exact components (not included) DATA VIDEO...

  • Page 7: Alarm Instructions

    1.6 Alarm Instructions Descriptions Name Power LED, the power indicator of the indoor monitor. CAM1 and CAM2 of this production have each an alarm function. When the trigger terminal and GND is shorted, the alarm is activate, the indoor monitor will emit alarm sound, the alarm ring time The door 1 state lights, to door 1 working when the LED is on.

  • Page 8: Operation Introduction On Indoor Monitor

    1.8 Operation Introduction On Indoor Monitor Monitoring VISITOR CALL Option in the settings in the menu: DOOR1, CAM1, DOOR2, CAM2 operating mode (open or closed) Please be aware of Connection of 2 outdoor cameras is required. Standby Mode Standby mode The Visitor press The Visitor press the call button on...

  • Page 9: Menu Operations On Indoor Monitor

    2. Menu Operations On Indoor Monitor Call Transfer To Other Extension Attention before using: Internal communication function requires at least two indoor and one outdoor units to be connected. 1. This indoor monitor includes OSD menu on it’s own device, users could set up some 2.1 Mouse Control parameters on the indoor monitor.

  • Page 10: Set System Parameters

    2.1 Set System Parameters 2.1.3 System – Information On system menu, move the cursor to “Information” and press “ ” to enter the Scroll the button “ ” upward or downward to move the cursor to the option “System”, then “Information”...

  • Page 11: System-Password

    [Return]: Exit the current menu. 2.1.5 System – Password On system menu, move the cursor to “Password” and press “ ” to enter the “Password” menu. User can set up the administrator’s password. The password set for entering the indoor monitor by web browser or the uCareHome app, default is “888888". [Return]: Exit the current menu.

  • Page 12: Set The Mode Of The Indoor Monitor

    2.3 Set the mode of the indoor monitor [CAM 1 Sensor type or CAM 2 Sensor type]: Each camera channel corresponds to an I/O status (see the following status explanations), which means that when an alarm On main menu, Move the cursor to “mode” and press “ ”...

  • Page 13: How To Connect Network

    Wired Network------APP Operation 2.6 How to connect Network Name Please download an app “uCareHome” via “Play Store” on a is the device name for your IP smart-phone/tablet with android system or via “APP Store” indoor monitor. on an iPhone/iPad with IOS system, then register an account. Password is the device password for login your IP indoor monitor.
  • Page 14 Make infoor monitor into AP mode Wireless Network------Make indoor monitor into AP Mode Wireless Network------APP Operation for Android phone Enter the menu “System->Network->Enter AP mode”, choose “Enter AP mode”, Step3 Step1 Step2 it will automatically reboot and wait for all button LEDs flashing then AP mode is ready.
  • Page 15 The icons on live view Wireless Network------APP Operation for iPhone Step1 Step3 Step2 Quality switch:HD/SD Snapshot Record/Stop record Adjust volume of speaker/Microphone Video full screen display Step5 Step4 Step6 Connect/disconnect view Talk back, semi-duplex communication. Hear the sound from the outdoor bell. The Microphone, transfer the sound to the outdoor bell.
  • Page 16 Push Mode System setting DND mode Lock Time Turn off all push function of the device. unlock time can be adjusted, and values can be set from 1 to 10s. Online Mode One-Key Unlock Turn on all push function of the device. After turn on this switch, no need App system default is away mode.

  • Page 17: Web Browser Operation

    3. Web Browser Operation Press “LAN Search”: 3.1 Running Environment Install the software through the Internet browser of OS to conveniently operate the network from a remote location. This device supports C/S, B/S, and access in LAN and WAN. It also supports IP and domain name visiting.

  • Page 18: System Login

    3.3 System Login 1) Open the web browser, and enter IP address “http://XXX.XXX.XXX.XXX” which can be searched by the app “uCareHome” on LAN. Note: If the device is connected to the WAN, the IP address should be a public IP address. The system will automatically enter the GUI as follows.

  • Page 19: Port Forwarding

    Note: Different router has different settings for port forwarding; please kindly follow your 4) After login, it will enter into “Home” interface of the live view as follows. router guide to do the port-forwarding. After the port-forwarding is done, you could view the indoor unit from WAN now. IPDoor 2015-03-25 11:20:08 5.

  • Page 20: Media

    3) Maximum Frame: User can choose a certain frame rate, when the bandwidth is limited, : Adjust brightness of image. Values can be set from 0~100.By default, the suggest reducing the value. Generally, the video is fluency if the value is more 15 frames. value is set at 80.

  • Page 21: Network--Ddns

    A. LAN Settings [IP Type]: There are two options: “Fixed IP Address” and “dynamic IP Address”. After selecting an Internet connection setting - such as fixed IP address (static) or dynamic IP address (DHCP) – and allocating a port, users can access the indoor unit remotely via the Internet.

  • Page 22: Event--Motion Detect

    Click “Parameters—Event—Motion Detect” to access the “Motion Detect” menu and the dialog window where Enable Switch, MD Area, Sensibility, E-Mail, Alarm Output and motion detection schedule settings can be set will be appear. Motion Detect Record 1) Status: “ ”indicates that the motion detection alarm of the login channel is enabled. 2) Sensibility: There are four levels: “very high”, “high”, “Normal”...

  • Page 23: Event--Record

    5.4.2 System-Time Setting If users select “Work Mode”, click “ ” to access the interface as follows. Users can set 5.4.1 System-User up three different time period on workday and weekend, the max number of time span is 24. Click “System—Time setting” to access time setting menu. There are four types of time mode: keep current, manual, Sync with computer time and Sync with NTP.

  • Page 24: System-Initialize

    5.4.3 System-Initialize 5.4.5 System-Storage Device Click “System—Storage Device” to enter the interface of SD card information as follows. Click “System—Initialize” to access initialize setting menu. This interface includes settings If the indoor monitor doesn’t detect an TF card or there is no TF card plugged in, the option for Reboot, Factory Default and Upgrade.

  • Page 25: System-System Log

    Click “pic” to enter into the snapshot file list. Click one on the list to playback the snapshot. Appendix 1. Accessing the indoor monitor via Mozilla Firefox Click “Parent Folder” to return to the parent directory. 1.F irst, install Firefox on Windows(This document will use Firefox 28.0 as an example). 2.

  • Page 26: Appendix 3 How To Ensure Reliable Remote Viewing Of The Indoor Monitor Through Ie Browser On Win 7/Win 8 64Bit Os

    4. During installation, the following figure will appear, click “Add” to confirm to install “IE Tab” Appendix 3. How to ensure reliable remote viewing of the add-on. indoor monitor through IE browser on Win 7/Win 8 64bit OS 1. Run 32bit IE on Windows OS (64bit) Note: On a 64-bit version of a Windows operating system, there are two versions of the Internet Explorer files: * The 64-bit version is “C:\Program Files\ Internet Explorer \iexplore.exe”.
  • Page 29 Note on lock connection The electric lock usually divide NC lock and NO lock, their wiring is different to our doorbell,the NC lock need to work with the additional power supply control. Note: 1.The doorbell or the monitor will not provide the power to door lock. 2.The doorbell can support door locks within 30V.
