PerfectWall Explanation of symbols WARNING! This operating manual must be read and understood before installation, set up, operation and servicing. This device must be installed by a specialist. Improper installation can lead to serious injury. Alterations to the device can be extremely dangerous and lead to serious injury or damage to the device. -
Page 5: Important Safety And Installation Instructions
Important safety and installation instructions PerfectWall Important safety and installation instructions Please observe the safety instructions and stipulations issued by the vehicle manufacturer and service workshops. The manufacturer accepts no liability for damage in the following cases: Faulty assembly or connection Damage to the product resulting from mechanical influences Alterations to the product without express permission from the manufacturer Use for purposes other than those described in the operating manual... -
Page 6: Accessories
PerfectWall Accessories Awning width No. in fig. 1, Description 2.6 m, 4 m, 4.5 m 5 m, 5.5 m page 1 3 m, 3.5 m Mounting bracket (lower section) Mounting bracket (upper section) Crank bracket (lower section) Crank bracket (upper section) (only PW1500, PW1750) Rivets Pegs... -
Page 7: Intended Use
If you have questions regarding the accessories, please contact your local service partner. Intended use The PerfectWall PW1000, PW1500 and PW1750 awnings are suitable for installing on motorhomes or caravans. The awnings must only be used whilst the vehicle is stationary. Please observe the operating manual. - Page 8 PerfectWall Installing the awning A cleaning agent that is recommended for use with the adhesive A primer that is recommended for use with the adhesive Acid-free silicone Notes on the installation position When choosing the installation location, observe the following: WARNING! Keep a sufficient distance from objects or other vehicles.
- Page 9 Installing the awning PerfectWall The mounting plates are bolted to the vehicle in the area of the rear hinge. In ® addition, they are glued with installation adhesive (e.g. Sikaflex -221 or a similar product) to ensure the load is evenly spread and an optimal level of protection from moisture is maintained.
- Page 10 PerfectWall Installing the awning ➤ Clean the outer sides of the mounting plates and the installation surface on the vehicle. ➤ Fill the drill holes in the vehicle wall with an acid-free silicone. ➤ Insert the square-head bolts through the relevant holes in the mounting plates (fig.
- Page 11 Installing the awning PerfectWall Installing awning on the piping rail ➤ Select the location of the installation. In particular, check that there is enough space in the interior to mount the counter plates at the points where the screws will be. NOTE Measure the recommended mounting position for each counter plate against the drill hole in the lower section of the awning.
- Page 12 PerfectWall Installing the awning ➤ Clean the outer sides of the lower section and the installation surface in the vehicle. NOTE Make sure that no glue gets on to the movable upper section of the mounting bracket. ® ➤ To glue and seal, apply an elastic adhesive, such as Sikaflex -221 for example, to the back of the mounting bracket.
-
Page 13: Connecting The Awning (Pw1500 And Pw1750)
Connecting the awning (PW1500 and PW1750) PerfectWall Connecting the awning (PW1500 and PW1750) WARNING! Connect the ignition (D+ signal) to the orange line of the receiver. This is the only way to ensure that the awning cannot be opened while driving. Only use the original remote control supplied and optional original wall switch.The use of original parts is the only way to ensure that with connected D+ signal the power supply is disconnected and the... - Page 14 PerfectWall Connecting the awning (PW1500 and PW1750) Observe the required cable cross section when connecting to the power supply: Cable length Required cable cross section 1.5 mm 2.5 mm 4.0 mm 6.0 mm Legend to fig. m, page 2: Description Receiver 3 A fuse for LED awning light (optional) Orange line for D+ connection...
-
Page 15: Disposal
Disposal PerfectWall Programming the remote control and the wall switch ➤ Place the battery (see fig. n 1, page 2). ➤ Switch on the power supply. ✓ The receiver beeps once briefly. ➤ Press the programming button (fig. n 2, page 2) or the buttons the wall switch simultaneously (fig. - Page 16 AUSTRIA SOUTH AFRICA Dometic Austria GmbH MEXICO Dometic (Pty) Ltd. Neudorferstraße 108 Dometic Mx, S. de R. L. de C. V. Regional Office A-2353 Guntramsdorf Circuito Médicos No. 6 Local 1 South Africa & Sub-Saharan Africa +43 2236 908070 Colonia Ciudad Satélite...
