Summary of Contents for Nolan N-com B601 X Series
- Page 2 USER INSTRUCTIONS AND SAFETY Congratulations on your purchase of a Nolangroup N-Com product. N-Com B601 was made using the most advanced technologies and the best materials. Long-running tests and thorough system development have allowed the highest audio quality to be achieved. For additional information about B601, and to download high-definition instructions as well as the latest Firmware version, visit the website www.n-com.it Firmware Version: 1.0...
-
Page 3: Table Of Contents
Contents WARNINGS AND SAFETY ........................4 1.1.Road safety ......................................4 1.2.Switching on the system in safe environments ........................ 4 1.3.Interferences ...................................... 4 1.4.Appropriate use ....................................4 1.5.Qualified personnel ..................................5 1.6.Accessories and batteries ................................5 1.7.Disposal ........................................ 5 CONTENT OF THE PACKAGING ......................6 INSTALLATION ON THE X-903 HELMET .................. -
Page 4: Warnings And Safety
WARNINGS AND SAFETY Read this User Manual carefully, as well as the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and the like. -
Page 5: Qualified Personnel
Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and safety characteristics of the helmet itself, thus creating dangerous conditions. Install the N-Com system according to the instructions provided in the product documentation. In case of doubt, please contact your local N-Com dealer. Warning: Listening to other equipment should not interfere with driving the vehicle, which must be the top priority at all times. -
Page 6: Content Of The Packaging
CONTENT OF THE PACKAGING The N-Com B601 package contains: e-box with wiring Microphone Microphone for helmet X-903 Rechargeable battery Adesive Keypad Mini USB jack wire Flat head tool Microphone foam Key, Screw, Microphone securing Microphone securing Adhesive strips clip stickers for loudspeakers... -
Page 7: Installation On The X-903 Helmet
INSTALLATION ON THE X-903 HELMET The X-903 helmet is pre-set for the EASYFIT simplified installation of the N-Com system. Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter 18.5). The installation video can be seen at www.n-com.it / Support section. - Page 8 Note: In the event that the keyboard is not positioned correctly, peel it off right away with extreme care and repeat the positioning. Note: It takes up to 24 hours for the keyboard to stick completely. During this time, do not expose the helmet to atmospheric agents.
-
Page 9: Positioning The Microphone In The X-903 Helmet
3.3. Positioning the microphone in the X-903 helmet Hook up the specific microphone for full-face helmets in its seat in the chin guard (Fig. 13). Position the microphone wire in the vertical groove (Fig. 14) and afterwards behind the cheek pad lining. -
Page 10: Repositioning The Padding
Fig. 19 Fig. 20 Fig. 21 Position the right loudspeaker in its housing, inserting the cable in the special groove (Fig. 22). If necessary, secure the earphone using the adhesive supplied as standard equipment. Position the wiring and the connectors behind the cheek pad lining, lifting it up with the help of a flat head tool. -
Page 11: Installation On The X-Lite Helmets
INSTALLATION ON THE X-LITE HELMETS This procedure must be followed for the installation of N-Com systems on X-lite helmets other than model X-903. Important: Prior to installing the N-Com system, it is recommended to write down the identification code affixed to the product (see chapter 18.5). The installation video can be seen at www.n-com.it / Support section. - Page 12 ONLY FOR X-702 HELMET: Position the battery connector and wiring underneath the shell gasket (Fig. 27). Cut along the pre-cut lines of the plastic tab on the back of the comfort padding (Fig. 28). Secure the wiring underneath the plastic tab. Close the cut ...
-
Page 13: Microphone Positioning
Note: In the event that the keyboard is not positioned correctly, peel it off right away with extreme care and repeat the positioning. Note: It takes up to 24 hours for the keyboard to stick completely. During this time, do not expose the helmet to atmospheric agents. - Page 14 Fig. 38 Fig. 39 Fig. 40 On certain helmets, the housing for the microphone rod must be created by cutting out the helmet border gasket along the pre- cut area (Fig. 41). Fig. 41 FULL-FACE HELMETS Take the polystyrene check pad (left side) and position the microphone in the special housing, as illustrated in Fig.
-
Page 15: Repositioning The Padding
4.4. Repositioning the padding Pass the USB mini wire through the elastic band found on the comfort padding. Replace the internal comfort padding by following the specific instructions found in the helmet user manual. Warning: Always verify the proper length of your chinstrap and adjust it if necessary, referring to the specific helmet instructions. -
Page 16: Basic Functions
BASIC FUNCTIONS Note: Before using the N-Com device for the first time, recharge the battery completely for at least 10 hours. To obtain best performances from the battery, it is recommended to completely recharge the battery the first few times. Afterwards, you can recharge the battery for shorter periods. Whenever possible, it is best to recharge the battery completely. -
Page 17: Configuration Menu
CONFIGURATION MENU All Bluetooth pair ups and other adjustments are carried out in this mode. To put the system in “Configuration mode” (starting from a switched off system) press the “n” key and keep it pressed for 4 seconds, until you hear the voice announcement “ Configuration ”. Once in the “Configuration”... -
Page 18: Mobile Phone
MOBILE PHONE To pair up a mobile phone to the B601 system, follow the procedure illustrated in Chapter 8. Answering a phone call Briefly press any key when you hear the incoming call signal. When you hear the ringtone, say any word out loud. Vocal answer (VOX phone) You can enable / disable the “VOX phone”... -
Page 19: Conference Call Function
9.2. Conference call function When a call comes in on a mobile phone connected via Bluetooth to B601, the intercom is temporarily turned off. However, if you wish to share the phone call with the other helmet, simply turn on the intercom manually during the phone call. During the phone call, briefly press “n”... -
Page 20: Music Via Bluetooth
12. MUSIC VIA BLUETOOTH To pair up an Mp3 device to the B601 system, follow the procedure illustrated in Chapter 8. Play music (Play) Press “” and keep it pressed for about 2 seconds. Pause function (Pause) When the player is playing music, press “” for 2 about seconds. Next track (Skip) When the player is playing music, press “”... -
Page 21: N-Com Intercom
14. N-COM INTERCOM The N-Com B601 system allows communication with other N-Com systems, up to a maximum distance of about 150 m (in open field, with no obstacles). The range of the communication varies depending on the N-Com systems used. Important: The procedure described below refers exclusively to the pairing up and operation between the B601 and the “900”... -
Page 22: Universal Intercom" Intercom
15. “UNIVERSAL INTERCOM” INTERCOM The N-Com B601 system can be connected via Bluetooth to intercom systems of other brands or to N-Com systems other than the “900” / “600” series, thanks to the UNIVERSAL INTERCOM function. Important: N-Com systems other than the “900” / “600” series must be paired up to the N-Com B601 by following the procedure “Pairing up the Universal Intercom”. -
Page 23: Battery And Recharge
16. BATTERY AND RECHARGE 16.1. Low battery signal During its operation, the system alerts the user with a voice message when the battery is low. From the first message, the system has a 1-hour autonomy. Warning is given every 10 minute. 16.2. -
Page 24: Summary Table Of Controls
17. SUMMARY TABLE OF CONTROLS Button Turning on 2 sec Turning off 6 sec Increase Volume Decrease Volume Answer phone call* Voice call 2 sec Speed Dialling Menu** Hang up/reject a phone call 2 sec Manual Device Connection 2 sec Phone Conference Activation CHANNEL 1... -
Page 25: Limited Warranty
18. LIMITED WARRANTY With this LIMITED WARRANTY CERTIFICATE, Nolangroup warrants this Product to be free from defects in material and workmanship at the time of its original purchase by the buyer. We invite you to: Read the cautions pertaining to safety and proper use. ... -
Page 26: Validity Of This Limited Warranty
18.3. Validity of this limited warranty This warranty is valid only if the enclosed warranty form is duly and completely filled out with the following information: Product identification code Name and stamp of the authorized dealer. Product purchase date. ... -
Page 27: Warranty Registration Form
19. WARRANTY REGISTRATION FORM Product name B601 X SERIES Identification code Buyer’s Information Name Last name Address Phone e-mail Dealer’s stamp Date of purchase... - Page 28 www.n-com.it...
