Luminex Users Guide
5. Write a few strokes on the Luminex before starting realtime. If you loaded a dictionary onto your
Luminex, the translated steno displays on the Tilting screen.
6. When you are finished writing realtime using the virtual serial port connection, it is important that
you complete the following steps in order. This ensures your computer shuts down properly.
Touch End on the Luminex to close the file. If the option, Prompt to confirm ending job is active,
·
touch End again at the prompt.
Close and save the realtime file.
·
Unplug the Luminex USB cable from your computer and the Luminex.
·

Wireless Communication

The Luminex comes with built-in WiFi and Bluetooth communication capabilities for wireless realtime
writing. You can also export your Case CATalyst dictionary to your Luminex via WiFi. You can have
multiple network profiles depending on different work locations, if needed. See
for establishing communications with your network. The Luminex WiFi feature, version 1.17513 or
higher, allows realtime communication with Case CATalyst versions 16.06, 17.54, 18.56, 19.05 or
higher. The ability to export Case CATalyst dictionaries, Spell Check Wordlist and/or
Prefixsuffixrules.ini file is available in Case CATalyst 16.06 or higher. All Luminex WiFi wireless
features require that Case CATalyst is loaded on a computer with Windows® 7, Windows 8 or
Windows 10. Your computer must be wireless enabled or have a network interface card (NIC).
Stenograph's Bluetooth Wireless Realtime kit allows wireless communication between the Luminex
and Case CATalyst or a Windows based 32-bit or 64-bit CAT system on your Windows® 10,
Windows 8 and Windows 7 notebook computer. The kit includes the Bluetooth software, drivers and
adapter for your computer. See the Stenograph Bluetooth Wireless Communication guide included in
the kit for information on Bluetooth wireless communication set up, configuration and use.
Stenograph provides Luminex wireless support when the Luminex Bluetooth Wireless
Communication kit is used. Other wireless adapters and software may work but are not supported by
Stenograph.
Bluetooth is turned Off by default. To access the Bluetooth communication settings, do the
following:
1. From the Opening menu, touch Setup and then touch Wireless. See the Stenograph Bluetooth
Wireless Communication guide included in Stenograph's Bluetooth Wireless Realtime kit for
information on Bluetooth wireless communication set up, configuration and use.
2. At the Wireless menu, touch Bluetooth. The Bluetooth Information screen displays.
3. If Bluetooth is On and configured, Bluetooth information displays. If Bluetooth is Off, then Bluetooth
powered off displays. If Bluetooth is On and you want to turn it Off, touch On/Off.
4. To exit the Bluetooth screen, touch Quit. To return to the Opening menu, touch Quit, More and
then Quit.
