Britax Safe'n'Sound Instructions For Installation & Use

Baby capsule, birth to 12 months (approx.)
Hide thumbs Also See for Safe'n'Sound:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Use and Installation Instructions
NOTE: Style may vary from image shown.
IMPORTANT: KEEP THIS BOOKLET IN THE PLACE
PROVIDED ON THE CHILD RESTRAINT BASE
BABY CAPSULE
Birth to 12 months (approx.)
Instructions for Installation & Use
Series No. BS0040B-020133
Instructions for Installation & Use
Birth to
12 months
(approx.)
1
