Zoeller
is a registered trademark
®
of Zoeller Co. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-584-8089, 7:30 a.m. - 5:00 p.m., EST, Monday - Friday.
Purchase Date
© 2017 . All rights reserved.
SUBMERSIBLE SUMP
MODELS #1073-0001, 1075-0001
1
PUMPS
Español p. 9
SW1139 B
Advertisement
Table of Contents
Related Manuals for Zoeller 1073-0001
Summary of Contents for Zoeller 1073-0001
- Page 1 SUBMERSIBLE SUMP PUMPS MODELS #1073-0001, 1075-0001 Zoeller is a registered trademark ® of Zoeller Co. All Rights Reserved. Español p. 9 ATTACH YOUR RECEIPT HERE Purchase Date Serial Number Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-584-8089, 7:30 a.m.
-
Page 2: Package Contents
PACKAGE CONTENTS DESCRIPTION QUANTITY Pump SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. NOTE: Pumps with the “UL” Mark and pumps with the “US” mark are tested to UL Standard UL778. CSA certified pumps are certified to CSA Standard C22.2 No. - Page 3 WARNING • ELECTRICAL SHOCK ALERT. Before installing this product, have the electrical circuit checked by an electrician to ensure proper grounding. All electrical installations must conform to the National Electric Code and all local codes. • ELECTRICAL SHOCK ALERT. Connect this product to a properly-grounded 115 volt circuit equipped with a Ground Fault Circuit Interrupter (GFCI) device.
-
Page 4: General Pump Information
0 FT. 5 FT. 10 FT. 15 FT. 1073-0001 1075-0001 GENERAL PUMP INFORMATION This pump is designed to be installed in a sump basin for removing clear drain water and will usually pass small particles suspended in water. Heavy mud, sand, or pea gravel can clog the pump, which can usually be cleaned out by back-flushing with a garden hose through the pump discharge. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Make sure the sump basin is cleared of any debris or sediment, and place the sump pump on a hard surface inside the basin. IL2016 2. Connect the discharge pipe, fittings, and check Discharge pipe valve (not provided) to pump discharge. The and ttings discharge pipe should be the same size as the Check... - Page 6 INSTALLATION INSTRUCTIONS 4. Make sure your hands are dry and you are not standing in water. Connect the pump to a 115 V properly-grounded, GFCI electrical outlet. GFCI outlet WARNING: Do not use an extension cord. NOTE: Tape the electrical cord to the discharge pipe to prevent it from interfering with the motion of the float.
-
Page 7: Care And Maintenance
CARE AND MAINTENANCE WARNING: Always disconnect pump from power source before handling. Remove debris At least every three months: Remove any debris that may build up in the sump basin to prevent it from interfering with the operation of the float switch. Clean out the vent hole that was drilled in the Clean discharge pipe during installation. -
Page 8: Troubleshooting
TROUBLESHOOTING DANGER RISK OF ELECTRIC SHOCK. Always disconnect power source before attempting to install, service, or maintain the pump. Never handle a pump with wet hands or when standing on wet or damp surface or in water. Fatal electrical shock could occur. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION...
Need help?
Do you have a question about the 1073-0001 and is the answer not in the manual?
Questions and answers
Is the float switch adjustable? I need to turn on pump when only a few inches of water are in basin.
The manual does not specify whether the float switch on the Zoeller 1073-0001 model is adjustable to turn on the pump with only a few inches of water in the basin. It states that the pump will turn on when the water reaches the proper level but does not provide details on adjustability.
This answer is automatically generated
Can I but parts for this pimp. The Transistor/off is shorted. that turns it on
Yes, parts for the Zoeller 1073-0001 pump are available under the "Pumps and Pump Parts" section.
This answer is automatically generated
