- Page 1 OWNER’S MANUAL...
-
Page 3: Table Of Contents
Introduction... Seat Post Setup... Frame Features... Frame Geometry... Schematic and Specifications... Warranty... -
Page 4: Introduction
No bicycle is indestructible. Downhill racing, severe off road riding, jumping, and stunt riding increases the stress on every part of your bicycle. Frames or parts under high stress may fail, causing you to lose control or fall. Because of the risk involved, Specialized recommends that you conduct a thorough inspection before each ride. If you miss a jump, ditch your bike in mid crash, dump or launch your bike without you on it, inspect yourself for injury, then carefully inspect your bicycle for damage. - Page 5 Technological advances have made bicycles and bicycle components more complex, and the pace of innovation is increasing. It is impossible for this manual or the accompanying manuals to provide all the information required to properly repair and/or maintain your bicycle. In order to help minimize the chances of an injury, it is critical for you to have work performed by an authorized Specialized retailer.
-
Page 6: Seat Post Setup
SEATPOST MINIMUM EXTENSION: All Specialized full suspension models with interrupted seat tubes have a small hole to identify the minimum extension allowed for your seatpost. If you cannot see the seatpost tube through this hole, your seatpost is too far extended. If a greater saddle height is required, replace the seatpost with a longer one. -
Page 7: Frame Features
BIG HIT FSR FRAME FEATURES 1. Main Frame 2. Seatstay 3. Chainstay 4. Shock Link 5. Main Pivot 6. Dropout (Horst) Pivot � � � 7. Shock Link at Seatstay Pivot � � 8. Shock Link at Frame Pivot � 9. -
Page 8: Frame Specifications
BIG HIT FSR FRAME GEOMETRY Small (mm) *Top Tube Length **Standover Height Head Tube Length Head Tube Angle (26” Steep) 68.2º Head Tube Angle (26” Slack) 66.3º Seat Tube Angle (26” Steep) 63.1º Seat Tube Angle (26” Slack) BB Height (26” High) BB Height (26”... - Page 9 BIG HIT FSR FRAME GEOMETRY...
- Page 11 NOTE: Bearing and Bolt Kits are available only through your local Specialized dealer. To retain your warranty and for your safety, all maintenance should be performed by your local Specialized dealer. Bearing Kit Parts Bolt Kit Parts...
-
Page 12: Warranty
ADDITIONAL CONDITIONS This Limited Warranty is made only to the original owner of this new Specialized bicycle or frameset purchased from an authorized Specialized dealer, and it shall remain in force only as long as the original owner retains ownership of the Specialized bicycle. This Limited Warranty is not transferable. In order to exercise your rights under this limited warranty, the bicycle or frameset must be presented to an authorized Specialized dealer, together with a receipt, bill of sale or other appropriate written proof of purchase which identifies the bicycle or frameset by serial number. - Page 13 Specialized bicycle or frameset. Any one or a combination of these conditions may result in an unpredictable failure of a Specialized bicycle or frameset that would not be covered by this warranty.
- Page 14 15130 Concord Circle Morgan Hill, CA 95037 www.specialized.com © 2003 Specialized Bicycles PN# W2040159...
