xcursion
travel system
user guide
IMPORTANT. KEEP FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xcursion and is the answer not in the manual?

Questions and answers

Related Manuals for mothercare xcursion

Summary of Contents for mothercare xcursion

  • Page 1 IMPORTANT. KEEP FOR FUTURE REFERENCE...
  • Page 2 The xcursion features a reversible seat unit, reclining backrest, adjustable footrest, lockable front swivel wheels and shopping basket. The shopping basket is intended to carry an evenly distributed maximum load of 4.5kg (9.9lbs). Built in adaptors enable the xcursion infant carrier to be fitted to the pushchair.
  • Page 3 parts checklist unfolding the chassis fig 1 Remove all packaging materials lay chassis on floor as shown. Unfasten the folding latch on the side of the chassis. fig 2 Step down onto basket to open. Ensure that the product has been locked out on both sides of the frame to the red line.
  • Page 4 preparation for use fitting the rear wheels fig 5 Press the wheel release button and attach the rear wheel as shown. Pull to make sure they are fully attached. attaching the seat unit fig 6 Attach seat unit to the chassis as shown. Check the seat unit is securely attached before use.
  • Page 5 preparation for use attaching the bumper bar fig 8 Attach the bumper bar as shown. Check that it is securely attached on both sides. in use securing your child fig 9 WARNING. Ensure your child wears a correctly fitting harness at all times. To fasten, insert both fasteners securely into the clasp.
  • Page 6 in use using the parking brake fig 11 To engage the parking brake step down on the rear peddle to stop the stroller moving whilst in a stationary position. Check that the brakes have engaged correctly by gently pushing the stroller. Pull up to release the brakes.
  • Page 7 in use reclining the seat unit fig 14 Release the lever and recline the seat as required. reversing the seat unit fig 15 Push the buttons inwards as shown on each side and lift the seat unit away from the frame. fig 16 Turn the seat unit around and replace into the adaptors until you hear a ‘click’.
  • Page 8 in use adjusting the handle fig 17 Push the button “1” on the underside of the handle to the right at the same time press the larger plastic button “2”. Adjust the handle as required. fig 18 fig 19 attaching the apron fig 20 Attach the apron by pushing in the press studs on either side of the pushchair.
  • Page 9 in use using the footmuff fig 21 Fit the footmuff to the seat unit by pulling the safety harness through the holes in the liner. The front of the footmuff may be removed for use in warmer weather. fitting the weathershield fig 22 Fit the weathershield over the pushchair and attach to the frame with the velcro tabs.
  • Page 10 after use removing the bumper bar fig 24 Push bumper bar pins in on both sides and pull up to remove as shown. removing the hood fig 25 Remove the hood as shown. removing the seat unit fig 25 Push the buttons inwards as shown on each side and lift the seat unit away from the frame.
  • Page 11 after use folding the chassis fig 27 Push the button “1” on the underside of the handle to the right at the same time press the larger plastic button “2” Press button “3” and at the same time, push the handle downwards.
  • Page 12 Brakes, wheels and tyres are subject to wear and should be replaced if necessary. This can be arranged through your local Mothercare store. Should parts of your pushchair become stiff or difficult to operate, ensure that dirt is not the cause.
  • Page 13 Do not use replacement parts or accessories, e.g. child seats, bag hooks, rain covers etc. other than those approved by Mothercare. They may make the pushchair unsafe. Never leave your child unattended, even for the shortest time.
  • Page 14 replacement parts chassis frame weathershield fabric seat unit apron hood front wheels rear wheels footmuff bumper bar...
  • Page 15 notes...
  • Page 16 If you have a problem with this product or require any replacement parts, please contact your nearest Mothercare store or telephone the Mothercare Customer Care Line on 08453 30 40 30 alternatively write to:...
