BlueStar RBCT Manual

Drop-in cooktop
Hide thumbs Also See for RBCT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual and Installation Instructions
DROP-IN COOKTOP MANUAL
Drop-in Cooktop
RBCT
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RBCT and is the answer not in the manual?

Questions and answers

Related Manuals for BlueStar RBCT

Summary of Contents for BlueStar RBCT

  • Page 1 DROP-IN COOKTOP MANUAL Drop-in Cooktop RBCT...
  • Page 2 BlueStar® Drop-In Cooktop MODELS RBCT THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLATION. INSTALLATION MUST BE PERFORMED BY AN APPROVED GAS INSTALLER OR GAS SERVICE TECHNICIAN OR THE WARRANTY IS VOID.
  • Page 3 Please take a few moments now to fill in the information below for your future reference. In the event you require parts or service, this information will be needed to ensure you receive the highest quality service we can provide. DATE OF PURCHASE DEALER’S NAME DEALER’S ADDRESS...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS may become hot. Do not place combus- To avoid personal injury or property damage, tible materials or plastics on this shelf. please read and follow these important safety 8. Do not store items of interest to children precautions. above the appliance.

  • Page 5: Site Preparation

    SITE PREPARATION Your Drop-in Cooktop may be installed into a If installed in a countertop along a wall at the counter top in a row of cabinets or into an is- rear the surface must be inflammable material land. Refer to the illustration above for key extending at least six inches upward.

  • Page 6: Installation

    INSTALLATION UNPACKING POSITIONING 1. Check the package for damage. If any 1. The importance of the proper installation damage is visible you should mark the bill of gas cooking equipment cannot be over- of lading you sign that there may be con- stressed.
  • Page 7 INSTALLATION will withstand an input pressure of ½ PSI GAS CONNECTIONS 1. The installation of this appliance must (12” wc). If the incoming pressure ex- conform with all applicable local codes. ceeds the maximum rating a step-down In the absence of local codes, the installa- regulator is required.
  • Page 8 INSTALLATION be redone and/or fine tuned by the install- WARNING er. These adjustments are the responsibil- This appliance is equipped with a three- ity of the installer and are not covered by pronged grounding plug for your protec- your warranty. tion against shock hazard and should be 16.

  • Page 9: Operation

    OPERATION GENERAL BURNERS  As part of the installation protective plas- Remove the ring grates and top grates and   tic wrappers on stainless steel surfaces thoroughly wash them with hot soapy wa- should be removed. These wrappers must ter, rinse and wipe dry.
  • Page 10 CLEANING BODY All stainless steel and painted parts should  be cleaned regularly with hot soapy water. Commercially available stainless steel  cleaners may be use don stainless steel. Be sure to follow manufacturer’s instruc- tion for use. Do NOT use steel wool or metal pads or ...

  • Page 11: Troubleshooting

    TROUBLESHOOTING Burner won’t light—no “clicking” from igniter Insure appliance is plugged in Insure circuit is not tripped or fuse blown Burner won’t light—”clicking”, no flame Insure gas is turned on Insure burner ports are clean Try a second burner for same or different result Insure electrode is plugged in Insure electrode is properly lined up Insure electrode is not cracked—spark not in correct...
  • Page 12 Igniter / Electrode replacement The following procedure is required to replace any top burner igniter. A Phillips head screwdriver is required. Shut off the gas & power to the product. Remove the ring grate & the square bowl grate associated with the igniter in question of replacing. For rear burner igniter replacement, also remove the grates on the front burner.
  • Page 13 PERFORMANCE CHECKLIST This checklist has been developed to assure proper installation of your appliance. To validate your warranty you must mail or submit online this form within 90 days of installation and a copy of your receipt to: Warranty Department, Prizer-Painter Stove Works Inc., 318 June Avenue Blandon, PA 19510 or www.bluestarcooking.com/support/product-registration/.
  • Page 14 Abbaka ventilation hoods and remote blowers purchased in the continental U.S. and ® Canada on or after April 1, 2019. This Warranty applies only to Product sold by a BlueStar authorized dealer or Prizer-Painter directly for use in residential properties only. Products must be installed by a qualified, licensed installer.
  • Page 15 (30) calendar days from the date of delivery of the Product to the owner’s home ® from a BlueStar authorized dealer. Cosmetic components include top grates, ring grates, plate rail, kick panel, body sides, glass, control panel, door panel, back guards, oven seals), front sides of hoods, and hoods strapping.
  • Page 16 Prizer-Painter is under no obligation, at law otherwise, to provide you with any concessions, including repairs, pro-rates or Product replacement, once this warranty has expired. What Is Not Covered This Warranty does not cover, and specifically excludes:  Damages caused by shipping. ...
  • Page 17 INCLUDING BUT NOT LIMITED TO DAMAGES FOR EXPENSES, SUCH AS, EXTRA UTILITY EXPENSES, SHIPPING COSTS RELATED TO REPAIR OR REPLACEMENT OF ANY PRODUCT OR DAMAGES TO PROPERTY, RESULTING FROM BREACH OF THIS WARRANTY OR ANY IMPLIED WARRANTY. Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages, so these provisions may not apply to you.
  • Page 18 ARBITRATION CLAUSE BlueStar® Cooking Appliances, BlueStar® Ventilation Hoods, Prizer Hoods® Ventilation Hoods and Abbaka Ventilation Hoods and remote blowers ARBITRATION CLAUSE. IMPORTANT. PLEASE REVIEW THIS ARBITRATION CLAUSE. IT AFFECTS YOUR LEGAL RIGHTS. YOU SHOULD ALSO CONSIDER CONSULTING WITH OTHERS ABOUT ARBITRATION BECAUSE THE INFORMATION PROVIDED IS NOT INTENDED TO CONTAIN A COMPLETE EXPLANATION OF THE CONSEQUENCES OF ARBITRATION.
  • Page 19 Arbitration Act (9 U.S.C. § 1 et seq.) rather than by state law concerning arbitration. The law governing your substantive warranty rights and other claims will be the law of the state in which you purchased your Prizer- Painter Product. Any court having jurisdiction may enter judgment on the arbitration award. Rules of the Arbitration: If the amount in controversy is less than $50,000, the arbitration will be decided by a single arbitrator to be appointed according to the rules of the arbitration association that is chosen.
