Charlton & Jenrick PARAGON 2000 Plus SLIDE CONTROL Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
PARAGON 2000 Plus & 2000 Plus Low Lintel SLIDE CONTROL
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 5049 (ISS 2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARAGON 2000 Plus SLIDE CONTROL and is the answer not in the manual?

Questions and answers

Related Manuals for Charlton & Jenrick PARAGON 2000 Plus SLIDE CONTROL

Summary of Contents for Charlton & Jenrick PARAGON 2000 Plus SLIDE CONTROL

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions PARAGON 2000 Plus & 2000 Plus Low Lintel SLIDE CONTROL Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR EXTENDED FIVE YEAR PARTS WARRANTY ....2 PARTS WARRANTY Benchmark Scheme ............. 3 SECTION ONE Introduction (user instructions) ..5 In order to validate your extended 5 years parts SECTION TWO Operation (user instructions) ..... 6 warranty please read the Benchmark Scheme on the SECTION THREE Fuel Bed Cleaning and Layout (user opposite page and ensure your installer has filled in the...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: 2000 Plus S/C Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (User Instructions)

    INTRODUCTION The PARAGON 2000 Plus SLIDE CONTROL is a decorative fuel effect appliance with a radiant heat conserver box for improved efficiency. The PARAGON 2000 Plus SLIDE CONTROL is designed and tested to the requirements of the EN 509 The PARAGON 2000 Plus SLIDE CONTROL is available in two versions Natural Gas or LPG (Propane Gas Only).

  • Page 6: Section Two Operation (User Instructions)

    The PARAGON 2000 Plus SLIDE CONTROL incorporates a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces, for instance due to insufficient ventilation or a blocked flue.

  • Page 7: Section Three Fuel Bed Cleaning And Layout (User Instructions)

    SECTION THREE Fuel Bed Cleaning and Layout (user instructions) Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care. The loose parts and moulded shapes may be removed for cleaning.
  • Page 8 Slide front support over the front edge of fire where the left & right front coals meet, see below Note the loose coal provided consist of :- 5 off shaped as coal "A" 9 off shaped as coal "B" NOTE :- 1x ”A” shape to be omitted on Low Lintel versions. Separate the coal into the two size groups ...
  • Page 9 P2000 Plus Version Only  Lay third row of loose coals 2 off “B” shape and 1 off “A” shape as shown for standard P2000 plus and P2000 plus extra.  FOR LOW LINTEL VERSIONS SEE BELOW ** PLEASE NOTE ** Low Lintel Version Only ...
  • Page 10 FUEL BED LAYOUT (PEBBLE OPTION) not available on Low Lintel. Fuel Bed Components Pebble identification  Base Matrix  L & R Front Pebbles Heart Shape  Numbered Pebbles :- Oblong Shape Large Shape Medium shape Small shape Total PEBBLE LAYOUT Warning Take great care when positioning the pebbles to avoid...
  • Page 11  Lay one row of pebbles at the front of the fire as shown.  Lay another row of loose pebbles shown.  Lay another row of loose pebbles as shown. www.charltonandjenrick.co.uk LT5049 (ISS 2)

  • Page 12: Section Four Important Information (User Instructions)

    Servicing It is advised that the PARAGON 2000 Plus SLIDE CONTROL fire is serviced annually this is more likely to provide trouble-free operation. A competent person must carry this out, i.e. Gas Safe Registered Installer in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended).
  • Page 13 Fret (Fire Front) A Fret must be used with this appliance, and must conform too: -  It must be made from non-combustible material.  Its general construction should enable it to stand firmly across the full width of the burner. ...

  • Page 14: Section Five Specification (Installation Instructions)

    SECTION FIVE Specification (installation instructions) NOTE! Low Lintel version fire box height is 497mm (551mm standard P2000+) NATURAL GAS PROPANE GAS Category of Appliance: Category Gas type: Gas Pressure: 20 mbar 37 mbar Gas input high: 7.00 kW Gross 7.00 kW Gross Gas input low: 2.40 kW Gross 2.40 kW Gross...

  • Page 15: Section Six Regulations And Warnings

     This PARAGON 2000 Plus SLIDE CONTROL is for use ONLY with the GAS STATED ON THE DATA BADGE this may be G20 for Natural Gas or G31 for Propane Gas. CHECK YOU HAVE THE CORRECT APPLIANCE FOR THE GAS YOU ARE USING.

  • Page 16: Section Seven Siting The Appliance (Installation Instructions)

    SECTION SEVEN Siting the Appliance (installation instructions) The fire can be installed in the following flues and locations: - CLASS ONE A conventional brick or stone chimney as used for a solid fuel appliance with a typical effective cross-sectional dimension of 225 x 225 mm (9 x 9 ins) or a lined flue with a minimum diameter of 125 mm (5 ins) Note: The restrictor plate, which is separately packed, may be fitted to flue of 175mm (7") or greater.
  • Page 17 CLASS TWO PRE-CAST A pre-cast flue conforming to the requirements of BS 1289 part 1 & 2 A suitable fire resisting fire surround will be required, spaced out to the correct thickness, between the face of the flue blocks and the rear of the appliance frame. IMPORTANT: - the flue restrictor plate must not be fitted when the appliance is installed in this type of flue.

  • Page 18: Section Eight Fireplace Requirements (Installation Instructions)

    SECTION EIGHT Fireplace Requirements (installation instructions) A flat face of 605 mm high x 500 mm wide must be provided around the fireplace opening for the fixing of the appliance to ensure that a good seal is formed. The base of the fire opening must be flat to ensure sound fixing of the appliance.

  • Page 19: Section Nine To Install The Appliance (Installation Instructions)

    CLEARANCE TO SHELF Minimum clearance from hearth to underside of combustible shelf should be 700mm provided shelf depth 150mm or less. This height may be reduced to 640mm for a shelf depth of 100mm or less. ( Low Lintel 650mm for shelf of 150mm).
  • Page 20 PREPARING THE APPLIANCE FOR A GAS CONNECTION If it is intended to be a concealed connection the 8mm supply should be positioned in the opening first. The pipe should be positioned so that when the appliance is pushed back into the opening it enters the grommet hole at least 180mm, taking into account the requirements of BS 6891 1988 dealing with enclosed pipes.
  • Page 21 GAS CONNECTION FROM THE FRONT Connections may be made from the front of the appliance from either the left or right in 8-mm diameter pipe. If a left-hand connection is required the tube should be routed below the gas control and onto the inlet elbow. The inlet elbows should be rotated to the required position.
  • Page 22 NOTE LOW LINTEL VERSION The 460mm measurement up from the bottom eye’s can be reduced to 410mm on the Low Lintel Version. Fix the fire casing back into the opening using the cable fixing system as shown in do not cut off loose ends of cable after fixing, coil and tuck carefully back Note: when using the cable fixing kit with the spacer, fix and seal the spacer to the rear of the appliance flange with the...
  • Page 23 FUEL BED LAYOUT Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material. Lay fuel bed as shown in the Section 3 of these instructions. ENSURE THE FUEL BED IS PLACED AS INDICATED IN THESE INSTRUCTIONS. CHECKING OPERATION OF FIRE Remove the screw from the pressure test point on the inlet elbow and fit pressure gauge.

  • Page 24: Section Ten Maintenance Instructions (Maintenance Instructions)

    ADVISE CUSTOMER THAT:  This appliance has a naked flame, as with all such fires it is recommended that a fireguard should be used for the protection of children, the elderly and infirm. Fireguards should conform to BS 6539 (1984) (Fireguards for use with solid fuel appliances).
  • Page 25 PILOT LINTING Check pilot aeration holes for linting, use a vacuums cleaner nozzle taking care not to damage the pilot head. (This should be done every time the fire is serviced) REPLACEMENT OF GAS CONTROL AND OR THE SPARK GENERATOR 1.
  • Page 26 REPLACEMENT OF INJECTOR 1. Repeat operations 1-10 for removal of gas control and spark generator 2. Repeat operation 2 for removal of burner and or silencer. 3. Disconnect gas connection to injector and gas control. 4. Unscrew the locking nut fixing injector to mounting bracket. 5.
  • Page 27 www.charltonandjenrick.co.uk LT5049 (ISS 2)
  • Page 28 LT5049 (ISS 2)
  • Page 29 Register your appliance online today to active your warranty www.charltonandjenrick.co.uk LT5049 (ISS 2)

  • Page 30: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 31: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 32 A-0027 A-0402 Product Serial No ID Label Prefix A-0029 JH (LPG) Burner Tray / Box Assembly Ceramics Set (Part no 5568) Fixing Kit (0705) eye bolt foam strip screw magnets wall plug Qty 4 Qty 1 Qty 4 Qty 4 Qty 4 Magnets Special Qty 4...
