Bring smart phone entertainment to the big screen!
User Manual
Rev 2.00
Download EZMiraApp
Please Scan QR code on screen to download
App for quick connection and setup for iOS
and Android devices.
Video Guide
http://youtube.com/c/MiraScreen
Subscribe to our handy videos to learn more
about mirroring with MiraScreen
User Tips
http://www.MiraScreen.com/help
Customer Service
Support@MiraScreen.com
We'd love to hear from you!
+
8268C
Advertisement
Table of Contents
Related Manuals for MiraScreen HDMI5690
Summary of Contents for MiraScreen HDMI5690
- Page 1 Please Scan QR code on screen to download App for quick connection and setup for iOS and Android devices. Video Guide http://youtube.com/c/MiraScreen Subscribe to our handy videos to learn more about mirroring with MiraScreen User Tips http://www.MiraScreen.com/help Customer Service Support@MiraScreen.com We’d love to hear from you!
-
Page 2: Hardware Installation
Hardware Installation 1. Turn on your TV and power up the MiraScreen dongle by connecting the USB cable from the dongle to a USB adapter (5V1A). Please place the WiFi receiver at a location with good WiFi reception. 2. Connect the MiraScreen dongle directly into an HDTV input port on your TV. - Page 3 Setup for iOS (iPhone/iPad) 1. Wait for MiraScreen main screen after power on. 2. Connect your iPhone with MiraScreen via Wi-Fi. Launch browser (http://192.168.203.1) on your iPhone to setup Internet for MiraScreen (connect MiraScreen to your Home WiFi Router). 3. Connect you iPhone to Home WiFi Router. Swipe up on your iPhone and tap on AirPlay Mirroring, then select MiraScreen as target.
-
Page 4: Setup For Android
Setup for Android 1. Wait for MiraScreen main screen after power on. 2. Turn on your Android menu, and then enable Miracast. 3. Select MiraScreen as target and wait for connection. 4. Your Android screen will be shown on your TV,... - Page 5 2. Launch the EZMira App 3. Click “Connect” button to start mirroring from Android Connect to Home WiFi Router 1. Wait for MiraScreen main screen after power on. 2. Connect your Android with MiraScreen via WiFi. 3. Launch browser to access (http://192.168.203.1) on your Android to setup Internet for MiraScreen (connect MiraScreen to your home WiFi Router).
- Page 6 Please connect MiraScreen to home WiFi router* in advance. Download Google Home App from Google Play. Launch the Google Home App, login with Google account. Then you may mirror Android to MiraScreen using Google Home as below. Note: MiraScreen dongle need to be connected to...
-
Page 7: Setup For Mac
Setup for Mac 1. Wait for MiraScreen main screen after power on. 2. Connect your Mac with MiraScreen via Wi-Fi. Launch browser (http://192.168.203.1) on your Mac to setup MiraScreen (Connect MiraScreen to your Home WiFi Router). 3. Connect you Mac to Home WiFi Router. Turn on AirPlay, then select MiraScreen as target. -
Page 8: Setup For Windows
Setup for Windows 1. Wait for MiraScreen main screen after power on. 2. For Windows 8.1, execute “Windows Start Menu > Settings > PC and devices >Devices> Add a device”, and then search for MiraScreen dongle. For Window 10, execute “Windows Start Menu >... - Page 9 Wireless 2.4GHz and 5GHz network (Available for 5G dongles only) MiraScreen will operate at the same wireless band as the router. Therefore, please connect MiraScreento an 5G wireless home router for using 5GHz WiFi Band MiraScreen’s WiFi SSID and Password are shown on the TV screen.
- Page 10 IP address (Shown on main screen) of MiraScreento enter setup page. 2. If MiraScreen does NOT connected to any Home WiFi router, then please connect your phone or laptop to SSID of MiraScreenvia WiFi.Launch web browser on your phone or laptop, then access the IP address (http://192.168.203.1) of MiraScreento enter setup page.
