Stream i ng M ir ror Ca r Da shCa m

T R U T H

B E

T O L D

MODEL: M3

U S E R M A N U A L

www.rovedashcam.com

Table of Contents

Need help?

Do you have a question about the M3 and is the answer not in the manual?

Questions and answers

Summary of Contents for ROVE M3

Page 2 CUSTOMER SERVICE Response in just 6 hours help@rovedashcam.com For faster response text us 1 (401) 484-ROVE(7683) Hours: Mon - Fri 9am-5pm PST Scan the QR Code to Email US Scan the QR Code to Text US Just Scan the QR Code with your iPhone or Android’s...
Page 3 HOW TO VIDEOS Visit our website www.rovedashcam.com/pages/videos Understanding ROVE M3 Rear Cam Watch HOW-TO VIDEOS to learn & understand all the features so you can get the maximum benefit out of it.
Page 4: Table Of Contents
C O N T E N T G U I D E USER AGREEMENT PRECAUTION USER WARNING DISCLAIMER OUT OF THE BOX INSTRUCTIONS TECHNICAL SPECIFICATION PACKAGE CONTENTS PRODUCT DIAGRAM INSTALLATION INSERTING / REMOVING A MICRO SD CARD POWERING ON/OFF THE DASH CAM UNDERSTANDING ICONS PLAYBACK INTERFACE UNDERSTANDING SYSTEM SETTINGS...
Page 5: User Agreement
USER MANUAL USER AGREEMENT By purchasing ROVE Dash cam, it is assumed that by default you agree with precautions, user warnings and all the terms & conditions of warranty. If for any reason you do not agree with any of the terms mentioned in this manual, then you may return the product in its original packaging unused within its return window for a full refund.
Page 6 This camera is intended to use inside motor vehicle. Don’t install it where it will block the driver’s view of the road including mirrors or the deployment of airbags. The reverse camera is designed to be used for reference only. Please drive and use the actual judgement based on road and driving condition.
Page 7 USER MANUAL Do not leave the camera in the direct sunlight for a long period of time or where temperature could go above 140°F (60°C). The camera is designed to be used for normal daily commute recording. It is not made to continuously record 24/7 365 days. Some countries or USA states prohibit drivers from mounting anything on windshield or prohibit mounting on certain area of the windshield.
Page 8: Disclaimer
DISCLAIMER ROVE M3 Streaming Mirror Dash Camera is designed to be use as a driver’s assistant. Although this is healpful in visual aid, it dose NOT remove the responsibility of driving the vehicle from the driver. The legal responsibility and safe driving practice always remains with the driver.
Page 9: Out Of The Box Instructions
(See Page 20) ROVE M3 Rear Cam is programmed to turn ON and START RECORDING automatically when it receives the power, and STOPS RECORDING and turns OFF automatically within 4-5 seconds when the power is disconnected.
Page 10: Technical Specification
TECHNICAL SPECIFICATION Rove M3 Model 9.66-inch IPS Touch Screen Screen size MS8339 Chipset Streaming video, LDWS Advance function External Front： (-20℃ ~ 60℃) Operating Temperature Rear： (-10℃ ~ 70℃) Storage Temperature Front： (-30°C ~ 70°C) Rear： (-20℃ ~ 75℃) Product Dimensions 260*70.5*15mm...
Page 11 USER MANUAL Front View Camera Image Sensor SC2363, 1/2.9 inch Sensor resolution Video resolution 1080P Max frames 30fps Lens 6G+IR Aperture F/1.8 Rear Camera SC2363, 1/2.9 inch Image Sensor Sensor resolution 1080P Video resolution 30fps Max frames 6G+IR Lens F/1.8 Aperture Speciﬁcations are subject to change without prior notice...
Page 12: Package Contents
PACKAGE CONTENTS Rove M3 mirror dash cam Rear dash cam 6M rear cam cable GPS Module 2.5 ft USB data cable 5X Cable Clips 12 ft USB Power Cable 4 Rubber fasteners Wire Trim Tool S t re a min g Mir ror C ar Da shC a m...
Page 13: Product Diagram
USER MANUAL PRODUCT DIAGRAM T R U T H T O L D STREAMING MIRROR CAR DASH CAM MODEL: M3 SN # M3546001245 www.rovedashcam.com MINI USB Port Reset Rear Cam Input Speaker Memory Card Slot Power Key Front Camera Rear Camera...
Page 14 Ref. Component Description -Connect to MINI USB cable & charge MINI USB Port battery. -Connect to PC for data from (SD card) transmission. Rear Cam Input Connect to the Rear Camera. Memory Card Slot Support MicroSD max to 512 GB, Class 10, U3 Speed Check your route when you playback the videos Via CAR DV Player.
Page 15: Installation
Add EVA PADS in case the mirror is loose to provide more stability. Put the M3 mirror dash cam in position on the front face of your existing rear view mirror ensuring the camera lens clears the edge of your rear view mirror.
Page 16 Front camera wiring diagram Note: Make sure that the camera’s view is not obstructed by any window tint or any other objects. If your vehicle has side curtain airbags please be very careful when running any cables along your vehicle windows. Ensure you are not running cable past any of the airbags as this can prevent the airbags from deploying.
Page 17 USER MANUAL Installing The Rear camera Select a ﬂat and centered location near the number plate lamp at the rear of the vehicle to mount camera. Attach tape to the bracket of the camera to hold the camera in position while installing, and drill two small holes, one for the ﬁrst screw, the second to run the reverse camera cable through.
Page 18 Mark the position suitable for the second screw and drill a small hole for it. Fix the second screw and securely tighten both screws NOTE : Do NOT plug the rear camera into the front camera while it is turned ON. Only od so when it is turned OFF.
Page 19 USER MANUAL Rear camera wiring diagram Here are three examples of where to guide rear camera’s wire. Plug the rear camera cable into the AV input socket of front camera. Connect the red wire of the camera to the reversing light. Install Rear Ramera Wiring at a glance Car Cigarette Lighter...
Page 20: Inserting / Removing A Micro Sd Card
TO INSTALL LCD/Mirror Side -Make sure the ROVE M3 is turned OFF. -Insert the Micro-SD Card half way in ( GOLD Contacts - Facing the Back/Lens Side) - Now gently push the card in until it clicks & looks in place.
Page 21 USER MANUAL FORMATTING MEMORY CARD Formatting the Micro-SD card will delete all information on the inserted Micro SD card and prepare the card for use with the Mirror DVR. Touch to stop the Mirror DVR from recording. Touch the to enter the Settings Menu. Use the Buttons to navigate the Settings Menu and touch the Format SD-Card to select.
Page 22: Powering On/Off The Dash Cam
Manual Power ON: Press the Power button Once to turn ON the ROVE M3 Manually Manual Power OFF: To Manually turn OFF ROVE M3 - Long Press the Power Button for 3-Seconds. Note: Be sure to insert the SD card before powering up the device.
Page 23: Understanding Icons
USER MANUAL UNDERSTANDING ICONS Tap on the screen of Rove M3 mirror dash to open main menu 0:00:00 13:36 2019.03.25 FRYDAY Icon Description Feature Recording Touch to turn on/off recording Photo Shooting Touch to take photos. Touch to turn on/off audio Audio recording.
Page 24 Icon Description Feature Touch/tap to open playback Playback interface. System Setting Touch/tap to open system setting. Touch/tap (+) or (-) sign to LCD brightness increase or decrease the LCD control brightness Recording timer Shows the elapsed recording time 0:00:00 Parking mode Shows the parking mode status Motion Shows the Motion detection status...
Page 25: Playback Interface
USER MANUAL PLAYBACK INTERFACE Touch to open playback interface. [ 1 / 1 ] [ 00 : 00 : 01 ] FILE190125-153307-000003F FILE190125-153329-000004F 13:36 FILE190201-063542-000007F 2019.03.25 FILE190203-063543-000008F FILE190175-063423-000009F FRYDAY FILE190203-063545-000002F FILE190125-153307-000003F FILE190125-153307-000003F 00 : 00 : 00 00 : 00 : 00 / 00 : 00 : 01 / 00 : 00 : 01...
Page 26 Icon Description Feature Back Touch to back to main menu. Emergency Touch to lock the ﬁle you lock selected. Touch to delete the ﬁle you Delete selected. Front Video Touch to play front videos. Rear Video Touch to play rear videos. Locked Front Touch to play locked Video...
Page 27: Understanding System Settings
USER MANUAL UNDERSTANDING SYSTEM SETTINGS Video Resolution Loop Recording 13:36 Exposure 2019.03.25 LDWS FRYDAY 1. Video Resolution Here you can choose your desired video resolution • 1296P 30fps • 1080P 30fps (Default) • 720P 30fps 2. Loop Recording This feature allows the camera to continuously record loop by loop so it can delete the oldest video ﬁles automatically when the memory card becomes full so you don’t have to manually delete them.
Page 28 3. Exposure Adjust video exposure setting for either brighter or darker video according to your preference. • • • 0 (Default) • • 4. LDWS Lane Departure Warning System allows the front camera to mirror your driving positing based on road markings and car give you audio alart when the vehicle drifting away from the lane.
Page 29 USER MANUAL LCD Brightness 13:36 G-Sensor 2019.03.25 Parking Mode FRYDAY 5. LCD Brightness • • Off (Default) 6. WDR (Wide dynamic Range) WDR improves the exposure by taking the combinations of over exposed and under exposed image into one robust wide range of lighting with Higher depth image.
Page 30 CAUTION: In the event of an accident please make sure you retrieve your footage before using your camera again to prevent the loss of important Video ﬁle due to the loop cycle function, in case the force was minor which did NOT trigger G-Sensor to lock the video ﬁle automatically.
Page 31 USER MANUAL LCD ON/OFF Language 13:36 Volume 2019.03.25 Frequency FRYDAY 9. LCD ON/OFF By turning ON this feature, the camera will automatically turn the display screen off. • Off (Default) • 1min • 2min • 3min 10. Language This setting allows you to choose your desired language setting for camera •...
Page 32 11. Volume • • High • Medium (Default) • 12 Frequency Here you should choose the frequency accordingly to your power supply speciﬁcation used in your country based on your geograph- ical location. • 50 Hz • 60 Hz (Default)
Page 33 USER MANUAL Streaming RearCam Date/Time 13:36 Stamp 2019.03.25 Format Memory Card FRYDAY Streaming RearCam • On (Default) • Date/Time Tap the Setting Date/Time option to adjust the value >> tap to next option >> tap to save. • 2019/3/25 13:36:02 •...
Page 34 We recommend you format the memory card every 3 months to keep it clean and for smooth operation. • Format Card? • All data will be deleted. • Reset Settings Firmware Version 13:36 2019.03.25 FRYDAY Reset Settings • All setting will be deleted. • Firmware Version • ROVE-M3-04022019-V1...
Page 35: Battery Information
USER MANUAL BATTERY INFORMATION This product contains Lithium-Ion inbuilt battery. With a full charge battery should last upto 2-5 minutes. Internal battery is NOT meant to last long time. The higher the video resolution you choose the more power it will consume, hence it will last short duration, and the lower video resolution you choose the less power it will consume, hence it will last longer.
Page 36 It is user’s responsibility to operate it correctly. Please adhere to your local or state laws for recycle of Li-Ion battery properly. Alwas charge the M3 using provoded charger. Improper charging the device may result in failure of the internal battery, heating or ﬁre.
Page 37 USER MANUAL ONE YEAR LIMITED WARRANTY We at ROVE InnoTech would like to provide One (1) full year of limited warranty for your product from the date of purchase to be free from defects in materials and craftsmanship. IMPORTANT: Please save your warranty/serial number card as an evidence.
Page 38 detected by the Authorized service center personnel, the warranty will be void and service / repairs will be done on chargeable basis only and subject to availability of parts. The company’s obligation under this warranty shall be limited to repair or providing replacement of part(s) only. The maximum claim(s) if entertained by the company will be subject to the maximum retail price of the product purchased or the purchase price, whichever is lower and on production of...
Page 39: Disclaimer Of Warranty/Limitations
ROVE InnoTech (here in after referred to as “the company”) guarantees to the purchaser that this product carries a warranty for the period mentioned above, commencing from...
Page 40 Damage is caused by using different power cord or chargers that are not supplied by us. In addition, ROVE reserves the right to refuse warranty against any product or services that are obtained and/or used in contravention...
Page 41: Faq/Troubleshooting
USER MANUAL FAQ/TROUBLESHOOTING Resetting the device If the Mirror DVR does not function normally, try restarting the Mirror DVR. To restart the Mirror DVR with a ﬂattened paper clip, press the small button on top of the Mirror DVR next to the USB port. Camera does not turn ON Use Included USB Cable &...
Page 42 Detection” or “Parking Mode” is set to OFF. My oldest video ﬁles are missing Your ROVE Dash Cam has Loop Cycle Recording. When it is set to either 1, 3, 5 or 10-mins, it will delete oldest ﬁles and record newer ﬁles over and over when the memory card is full.
Page 43 Ail rights are reserved. reproduction, transfer, distribution of the contents herein in any manner without the prior written permission of ROVE Innotech is prohibited. ROVE Innotech reserves the right to add, modify or delete, any of the contents herein or withdraw this documents at any time without prior notice and without assigning any reasons thereof.
Page 44: User Manual Desclaimer
Camera upgrades, ﬁrmware, box contents can be changed without notice. Always see up to date information by visiting our website. This is the very ﬁrst version of this user manual we wrote for ROVE M3 As we are dedicated in keep improving this model by ﬁrmware updates and more features adition.
Page 45 QUESTIONS CUSOTMER SERVICE: Response in just 6 hours For faster response text us help@rovedashcam.com 1 (401) 484-ROVE(7683) Scan the QR Code to CONTACT US Scan to Email US: Scan to Text US: help@rovedashcam.com 1-401-484-7683...
