Installation Instructions

This document contains proprietary information of Fresenius USA, Inc. d/b/a Fresenius Medical Care North America
and its affiliates ("Fresenius Medical Care"). The contents of this document may not be disclosed to third parties,
copied, or duplicated in any form, in whole or in part, without the prior written permission of Fresenius Medical Care.
Fresenius Medical Care, the triangle logo, 2008, BlueStar, bibag and DIASAFE are trademarks of Fresenius Medical
Care Holdings, Inc., or its affiliated companies. All other trademarks are the property of their respective owners.
If there are any questions regarding these instructions, contact Fresenius Medical Care Technical Support at 800-227-2572.
© 2019, Fresenius Medical Care North America. All rights reserved.
PatientCard Reader
PatientCard Reader Installation Instructions
2008T BlueStar
Part Number 490330 Rev B
for
™
Hemodialysis Machines

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2008T BlueStar and is the answer not in the manual?

Questions and answers

Related Manuals for Fresenius Medical Care 2008T BlueStar

Summary of Contents for Fresenius Medical Care 2008T BlueStar

  • Page 1: Installation Instructions

    (“Fresenius Medical Care”). The contents of this document may not be disclosed to third parties, copied, or duplicated in any form, in whole or in part, without the prior written permission of Fresenius Medical Care. Fresenius Medical Care, the triangle logo, 2008, BlueStar, bibag and DIASAFE are trademarks of Fresenius Medical Care Holdings, Inc., or its affiliated companies.
  • Page 2 • 2008T BlueStar Functional software version 2.71 or greater* • 2008T BlueStar Actuator-Test software version 2.32 or greater* *Note: If a software update is needed, a 2008T BlueStar Standard Upgrade Kit (P/N 191137) must be ordered separately. Required Tools: • #2 Phillips screw driver •...
  • Page 3 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS IV Pole Removal The PatientCard Reader is incorporated into the IV Pole holder so the upper IV pole holder will need to be replaced. Note: The IV pole will need to be removed so remove the dialyzer holder and any other object that will hinder the IV pole removal.
  • Page 4 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS Note: The middle panels has a ground wire attached. Take care not to damage this wire when removing the panel. 11. Remove the middle panel covers. See Figure 4 for screw locations. Unplug the cover’s ground wire. Figure 4 –...
  • Page 5 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS 16. Locate the hole in the card cage shown in Figure 7 below. Figure 7 17. The card reader adapter board and cable assembly needs to be attached to the inside of the card cage using a plastic Snap Rivet (P/N 330801-03).
  • Page 6 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS 19. Insert Part A of the rivet through the hole in the card cage and mount the card reader adapter board holder onto the Snap Rivet Part A as shown in Figure 11. Hole in holder Snap Rivet Part A USB Cable...
  • Page 7 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS 22. Route the Serial Cable between the display assembly and the circuit boards. Once the cable end reaches the Functional board, plug the end into connector P32 as shown in Figure 14. Functional Board Serial Cable Connector P32 Figure 14 –...
  • Page 8 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS Card Reader/Upper IV Pole Holder Installation Caution: Care must be taken when handling circuit boards to prevent damage by Electrostatic Discharge (ESD). Use appropriate ESD precautions when handling electronic components. 24. Locate and remove the four (4) screws attaching the upper IV pole holder to the cabinet (see Figure 16). Figure 16 25.
  • Page 9 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS 28. Press the USB Cable into the cable channel shown in Figure 18 below. Cable Channel Figure 18 29. Route the excess card reader cable back through the cabinet opening in order to place the new Card Reader/Upper IV Pole Holder assembly onto the cabinet.
  • Page 10 2008T PATIENTCARD READER INSTALLATION INSTRUCTIONS 43. Once the blank PatientCard is read successfully, verify that the New Patient Information screen is displayed and the Save button is grayed out. 44. Enter the following information: • Patient ID: 0123456789 • First Name: Maxwell •...
  • Page 11 USB Cable (USB 2.0, A Male to Mini B Male) 365067-08 Serial Cable (Flat Ribbon cable) 191116 Snap Rivet 330801-03 PatientCard M35765 Contact Fresenius Medical Care Technical Support at 800-227-2572 if any parts are incorrect or missing. P/N 490330 Rev B Page 10 of 10...
