GARDEN 5 IN 1 PETROL TOOL
CAUTION!: Read the manual carefully before operating this machine!
Vers.No. 180823
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garden 5 in 1 Petrol Tool and is the answer not in the manual?

Questions and answers

Related Manuals for Gardenline Garden 5 in 1 Petrol Tool

Summary of Contents for Gardenline Garden 5 in 1 Petrol Tool

  • Page 1 User Manual GARDEN 5 IN 1 PETROL TOOL CAUTION!: Read the manual carefully before operating this machine! Vers.No. 180823 Original Instructions...

  • Page 3: Table Of Contents

    Contents Overview Contents of box Utilisation Warranty Details Explanation of symbols Introduction Layout Scope of delivery Intended use General Safety Warnings Technical data Before starting the equipment Attachment and operation Working instructions Maintenance Cleaning / Storage / Transport Disposal and recycling Troubleshooting Repair and Refurbished Goods or Parts Notice...

  • Page 4: Overview

    Overview...
  • Page 5 Utilisation...

  • Page 6: Contents Of Box

    Contents of Box Contents of Box 1x Motor drive unit (7) 1 x Front handle (1) consisting of: (4 screws M5x35 (A), Front handle (1), Rubber insert (A1), Distance tool (A2), 4 Nuts M5 (A3) preassembled at Distance tool) 1 x Grass trimmer (Nylon cutting head) (8) 1 x Combined oil/petrol cylinder (9) 1 x Spark plug wrench (10) 1 x Open-ended spanner (8 mm / 10 mm) (11)

  • Page 7: Utilisation

    Utilisation AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 8 Utilisation AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 9 WIND CORD AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 10 9 mm AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 11 2 mm AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 12: Warranty Details

    AFTER SALES SUPPORT 1300 855 831 support@scheppach.com.au YEAR WARRANTY AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool Trimmer PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 13: Explanation Of Symbols

    Do not expose the appliance to rain. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 14 Warning! Keep all children, bystanders and helpers 15 meters away from the tool! AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 15: Introduction

    I. INTRODUCTION Congratulations on choosing to buy a GARDENLINE® product. All products brought to you by GARDENLINE® are manufactured to the highest standards of performance and safety, and as part of our philosophy of customer service and satis- faction, are backed by our comprehensive 3 Years Warranty.

  • Page 16: Layout

    • If possible, keep the packaging until the end of the guarantee period. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 17: Intended Use

    AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 18: General Safety Warnings

    à Avoid any unnatural posture. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 19 AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 20 à Only use the 5 in 1 Petrol Tool, when the guard is attached. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 21 • Never start the cut with the bar tip and never cut with the bar tip. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 22: Technical Data

    Max. Cutting length mm AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 23 The impact of noise can cause damage to hearing. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 24: Before Starting The Equipment

    Then shake the bottle well. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 25: Attachment And Operation

    • Tighten the four screws at the protection shield (26) again with a screwdriver. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 26 • When standing in a normal working posture, the cutting head should touch the AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 27 (19). AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 28 Reverse the above sequence to remove the drive tube. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 29 AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 30 AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 31: Working Instructions

    AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 32 Oil the blades and the angle adjustment each time before starting work, with environ- AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 33 - oil quantity increases (+) AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 34 AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 35 Always start with running at full speed chain to cut. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 36 5 mm. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 37 (C) AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 38: Maintenance

    (A6). AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 39 • When the electrode is severely worn out or reveals a strong incrustation, the spark AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 40 • Clean the saw chain. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 41 Untypical noises of the cutting tools AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 42 • Type of machine AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 43: Cleaning / Storage / Transport

    Storing the equipment AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 44 AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 45: Disposal And Recycling

    • Contact the service centre. AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 46 • Have the chain sharpened or replace it. AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.

  • Page 47: Repair And Refurbished Goods Or Parts Notice

    AUS Hotline Costs: Local rate for landline calls* AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider. *Charges may vary dependent upon network operator or mobile network provider.
  • Page 48 AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 49 1.10 AFTER SALES SUPPORT   1300 855 831 support@scheppach.com.au AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 50 AFTER SALES SUPPORT   support@scheppach.com.au 1300 855 831 AUS Hotline Costs: Local rate for landline calls* MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019 *Charges may vary dependent upon network operator or mobile network provider.
  • Page 51 Garden 5 in1 Petrol Tool AFTER SALES SUPPORT  support@scheppach.com.au 1300 855 831  MODEL: Garden 5 in 1 Petrol Tool PRODUCT CODE: 58903 03/2019...
  • Page 52 Customer Service Hotline. Made in China GARDENLINE® is a registered trademark of ALDI Stores DISTRIBUTED BY: ALDI STORES 1 SARGENTS ROAD MINCHINBURY NSW 2770 www.aldi.com.au...
