  • Page 1 Power Drives anual 600 I/690 I • Français – 15 • Castellano – pág. 31 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 2: Table Of Contents

    600-I/690-I Power Drives Table of Contents Recording Form for Machine Serial Number ......................1 Safety Symbols................................2 General Power Tool Safety Warnings Work Area Safety................................2 Electrical Safety ................................2 Personal Safety ................................3 Power Tool Use and Care ............................3 Service ..................................3 Specific Safety Information Power Drive Safety ..............................4...

  • Page 3: Recording Form For Machine Serial Number

    Read this Operator’s Manual carefully before using this tool. Failure to understand and follow the contents of 600-I/690-I Power Drives this manual may result in Record Serial Number below and retain product serial number which is located on nameplate. electrical shock, fire and/or serious personal injury.

  • Page 4: Safety Symbols

    600-I/690-I Power Drives Safety Symbols In this operator’s manual and on the product, safety symbols and signal words are used to communicate important safe- ty information. This section is provided to improve understanding of these signal words and symbols. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 5: Personal Safety

    600-I/690-I Power Drives • Do not abuse the cord. Never use the cord for tool safety principles. A careless action can cause severe injury within a fraction of a second. carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or Power Tool Use and Care moving parts.

  • Page 6: Specific Safety Information

    • Only one person must control the work process The 600-I Power Drive is designed to use RIDGID 11-R and tool operation. Additional people involved in the Drop Head Die Heads ( " – 1 "...

  • Page 7: Specifications

    600-I/690-I Power Drives 600-I Power Drive and 690-I Power Drive machine serial Warning Handle Warning Label (120V) Brush Switch number plate is located on the bottom of motor housing. Label (All) Handle The last 4 digits of the serial number indicate the month and year of the manufacture (MMYY).

  • Page 8: Pre-Operation Inspection

    600-I/690-I Power Drives ing. This contamination could cause corrosion and pre- mature failure. Careful evaluation of materials and meth ods for the specific service conditions, including chemical and temperature, should be completed before any installation is attempted. 2. Pull Up Pre-Operation Inspection Figure 5B –...

  • Page 9: Set-Up And Operation

    600-I/690-I Power Drives • Clear, level, stable, dry location for all equipment and operator. • Good ventilation. Do not use extensively in small, enclosed areas. • Properly wired electrical outlet of the correct voltage. If in doubt, have outlet inspected by a licensed elec- trician.

  • Page 10: Resisting Threading Forces

    Use appropri- ate pipe stands to support pipe length. 9. Check the level of RIDGID Thread Cutting Oil in the Figure 8 – Installing Adapter Into 690-I RIDGID 418 oiler. Remove the chip tray and confirm that the filter screen is clean and fully submerged in 6.

  • Page 11: Threading

    600-I/690-I Power Drives c. Do not place the power drive motor or handle Aligned against adjacent structural members to react threading forces, as this may cause power drive Support damage. d. Keep power drive against the structural member and do not place fingers or hands between the power drive and the structural member.

  • Page 12: Inspecting Threads

    13. Stop pushing on cover plate and use oiler to apply a 17. With dry hands unplug the power drive. generous quantity of RIDGID Thread Cutting Oil to the 18. Wipe oil and debris off the threads and out of the die area being threaded.

  • Page 13: Maintenance Instructions

    To reduce the risk of serious injury, only use acces- Dies sories specifically designed and recommended for use with the 600-I and 690-I Power Drives such as those listed below. Other Accessories suitable for Threaded Pipe use with other tools may be hazardous when used Die Head with the 600-I and 690-I Power Drives.

  • Page 14: Machine Storage

    Any problems not addressed by this section should only be handled by an authorized RIDGID service technician. Tool should be taken to a RIDGID Independent Service Center or returned to the factory. GlobalTestSupply 999-999-476.10_REV. D www.

  • Page 15: Troubleshooting

    600-I/690-I Power Drives Troubleshooting SYMPTOM POSSIBLE REASONS SOLUTION Brushes do not touch armature. Check brushes, replace if worn. Machine will not run. Machine not able to Dull dies. Replace dies. thread. Overload due to torn or out-of-round threads. See possible reasons below.

  • Page 16: Lifetime Warranty

    RIDGE TOOL COMPANY. ©2013, 2018, RIDGID, Inc. The Emerson logo and RIDGID logo are registered trademarks of Emerson Electric Co. or RIDGID, Inc. in the U.S. and other countries. All other trademarks belong to their respective holders.
