ABB
Effective:
January 1997
Supersedes I.L. 41-681.1Q, Dated January 1988
( | ) Denotes Change Since Previous Issue
CAUTION
!
Before putting the Synchro-Verifier into ser-
vice, remove all blocking inserted for the pur-
pose of securing all parts during shipment.
Make sure that all moving parts operate
freely. Inspect the contacts to see that they
are clean and close properly. Operate the
relay to check the settings and electrical con-
nections.
1.
APPLICATION
The types CVE, CVE-1, CVE-2 and CVE-3, figures 1,
2, and 3, synchro-verifier relays are used to check the
voltages on both sides of a breaker to see that they
are approximately the same in magnitude and phase.
The synchro-verifier relays are not automatic syn-
chronizers and should not be used as such. Auto-
matic synchronizers are available with permit closing
ahead of synchronism at an angle of phase-advance
proportional to the beat frequency and determined by
the speed of operation of the circuit breaker so that
the two systems are connected at synchronism.
The CVE type relays supervise the automatic or man-
ual closing of a circuit breaker. A common application
of the synchro-verifier relay is in conjunction with
automatic reclosing equipment or loop systems fed
by generating stations at two or more points. When a
line section trips out, the synchro-verifier is used at
All possible contingencies which may arise during installation, operation or maintenance, and all details and
variations of this equipment do not purport to be covered by these instructions. If further information is
desired by purchaser regarding this particular installation, operation or maintenance of this equipment, the
local ABB Power T&D Company Inc. representative should be contacted.
Printed in U.S.A.
ABB Automation Inc.
Substation Automation and
Protection Division
Coral Springs, FL 33065
Types CVE, CVE-1, CVE-2
AND CVE-3
Synchro-Verifier Relays
one terminal to check synchronism after the remote
terminal is reclosed. If the two systems are in syn-
chronism, the synchro-verifier permits that automatic
equipment to reclose the breaker.
The CVE-1 has the CVE unit and is additionally
equipped with line and bus voltage sensing, tele-
phone type relays. These permit the relay reclosing to
be initiated when the bus is hot and the line is dead
(HBDL) or vice versa (HLDB). When both the line and
the bus are live and in synchronism, the synchro-veri-
fier relay permits the automatic reclosing equipment
to reclose the breaker.
The CVE-2 relay is comprised of three (3) telephone
type relays and two (2) over or under voltage tog-
gle-type relays in addition to the CVE unit and is used
for selective initiation of reclosures. The reclosing is
modified by the nature of the trip; high-speed relay
trips initiate high-speed and delayed-time reclosures;
time-delayed relay trips initiate only time-delayed
synchronism reclosures; and manual trips which do
not initiate reclosures.
The CVE-3 relay also has the CVE unit. A telephone
relay is added for the purpose of sealing-in the CVE
contacts once they have closed. The CVE-3 relay is
capable of being energized with the CVE unit con-
tacts closed and will carry current continuously.
2.
A. Operating Element (Rear Element) Figure 1
CONSTRUCTION
An "E" type laminated electromagnet is part of
the operating element of the synchro-verifier
Instruction Leaflet
41-681.1R

Advertisement

loading

Summary of Contents for ABB CVE

  • Page 1 The CVE-2 relay is comprised of three (3) telephone type relays and two (2) over or under voltage tog- gle-type relays in addition to the CVE unit and is used APPLICATION for selective initiation of reclosures. The reclosing is The types CVE, CVE-1, CVE-2 and CVE-3, figures 1, modified by the nature of the trip;...
  • Page 2 Figure 4 shows the external connections of the the applied voltages. This flux divides and CVE relay with two type SG relays for the line returns through the outer legs of the electromag- and bus voltage relays. Connected in this man- net.
  • Page 3 60 Hertz 50 Hertz The operating time of the CVE element of the relay is shown in figure 8. These time curves are obtained Volt-Amperes 10.62 13.29 from the number 11 time-dial setting when the Power Factor 0.64...
  • Page 4 = breaker closing time in seconds the unit under test. Let T = 0.5 seconds B. CVE (Figure 12) Then 40° + 17.3 x .05 = 48.6° Indicating Contactor Switch (ICS) - B. Indication Contactor Switch (ICS) - (When Used) (When used) Tap settings of either 0.2 or 2.0 amperes are required...
  • Page 5 20 ±1 second. AC Contactor Switch - (When Used) C. CVE-1 (Figures 13 and 14) The core screw, which is adjustable from the top of the ACS unit, determines the Indicating Contactor Switch (ICS) - pickup value.
  • Page 6 For units with double-trip con- tacts, the adjustment procedure is the b. Operating Circle - Set up the CVE same as with the single trip unit. relay per the test diagram in figures 13 and 14.
  • Page 7 The operation indicator target Telephone Relay should drop freely. In order to check the pickup of the CVE-3 The contact gap should be approximately telephone relay, the time-dial must be 0.047 inches between the bridging moving...
  • Page 8 12 in the face of the soft silver contact and thus impair- CVE-1 figures 12 and 14 ing the contact. CVE-2 figure 15...
  • Page 9 I.L. 41-681.1R F. Time Curve Install the permanent magnet on the relay. Adjust the FOR EXAMPLE permanent magnet keeper until the operating time of the relay from the number 11 time-dial position is 20 If a 40 degree circle is desired, adjust the left-hand ±0.6 seconds with V and V equal to rated voltage...
  • Page 10 External Schematic CVE-2 Relay - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 11 I.L. 41-681.1R Figure 1. CVE Relay Front & Rear Views, Out of Case Figure 2 .CVE-1 Relay Front & Rear View, Out of Case...
  • Page 12 I.L. 41-681.1R Figure 3 .CVE-3 Relay Front & Rear Views, Out of Case...
  • Page 13 27 59 – -------------------- - UNDER AND OVERVOLTAGE BUS RELAY, TYPE SG ‡ = INTERNAL SCHEME 185A122 WITH ICS ON CVE CONTACT † = 52b REQUIRED IF HIGH SPEED AUTOMATIC RECLOSING USED 184A863 Figure 4 .External Schematic of CVE 3527A76...
  • Page 14 I.L. 41-681.1R...
  • Page 15 I.L. 41-681.1R 184A887 184A998 Figure 7. Thpical Voltage Angle Characteristic of CVE for Figure 8. Typical Time Phase Angle Curves of CVE. Various Closing angle Settings. Rated Voltage Rated Voltage on Both Circuits No. 11 Dial on One Circuit. Time Settings.
  • Page 16 I.L. 41-681.1R 619457...
  • Page 17 I.L. 41-681.1R PHASE SHIFTER 185A001 Figure 1 2 . Diagram of CVE Test Connections 775B995 Figure 13. Diagram of CVE-1 Test Connections without Commoned Potential Coils. 775B994 Figure 1 4 . Diagram of CVE-1 Test Connections with Commoned Potential Coils.
  • Page 18 To Breaker Reclosing Scheme Synchronism- Check Supervised Reclosing RELAY NUMBER CHART - Synchro-Verifier Relay Type CVE-2: Int. Sch.: 188A389 Hot-Line Dead-Bus Reclose - Operating Electromagnet High-Speed Unsupervised Reclosing - Restraint Electromagnet Type - Voltage Bus Unit CVE-2 - Voltage Line Unit...
  • Page 19 WITH RELATIVE INSTANTANEOUS POLARITY AS SHOWN, THE CONTACTS CLOSE AS SHOWN, THE CONTACTS CLOSE 184A540 185A122 Figure 17. Internal Schematic CVE Relay without ICS Unit Figure 18. Internal Schematic CVE Relay with ICS Unit. OPENING 188A624 878A184 Figure 19. Internal Schematic CVE-1 for use with RC Figure 20.
  • Page 20 I.L. 41-681.1R 880A496 Figure 21 .Internal Schematic CVE-1 without Commoned Potential Coils (See Figure 5 for External Schematic). *188A389 Figure 22 .Internal Schematic CVE-2 * Denotes Changed since previous issue...
  • Page 21 I.L. 41-681.1R...
  • Page 22 Figure 25. Operating Times from the No. 11 Time-Dial Figure 24. V Voltage for Different Operating Circle. V2 Position for the Type CVE Relay Set for Differ- Equal to Rated Voltage at Zero Phase Angle. ent Operating Circles. V1 and V2 Equal to...
  • Page 23 I.L. 41-681.1R 3511A01 Sub 1 Figure 26. External Schematic CVE-1.
  • Page 24 I.L. 41-681.1R 408C823...
  • Page 25 I.L. 41-681.1R...
  • Page 26 I.L. 41-681.1R 57D7901 Figure 32. Outline & Drilling Diagram for Relay Case Type FT-21.
  • Page 27 I.L. 41-681.1R 57D7903 Figure 33. Outline & Drilling diagram for Relay Case Type FT-32.
  • Page 28 I.L. 41-681.1R ABB Automation Inc. 4300 Coral Ridge Drive Coral Springs Florida 33065 TEL: 954-752-6700 FAX: 954-345-5329 Printed in U.S.A.
