2-2.

Configuration of Power Supply Units

Component parts of a power supply unit are indicated below.
2-2-1. Power Regeneration Type MPS Unit
(1) MPS unit: power regeneration type
Configuration of I set of power supply unit: PSB + MFP1 card + MPS PU + MPS-ACL
In the table below, indication of "(1)" in the Q'ty column indicates that any of the indicated units
should be selected meeting the motor capacity.
Category
Control board
Display card
Power regeneration
type unit
AC choke coil
2-2-2. Resistor Regeneration Type MPR Unit
(1) MPR unit: resistor regeneration type
Configuration of 1 set of power supply unit: MPR* PU
Category
Resistor regeneration
type unit
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
SECTION 2 DC POWER SUPPLY UNIT (MPS, MPR UNIT)
Order Name Q'ty
PSB-MPS10 (1) 1006-2103
PSB-MPS30 (1) 1006-2104
MFP1 CARD 1 1006-2105
MPS10 PU (1) 1006-2200
MPS20 PU (1) 1006-2201
MPS30 PU (1) 1006-2202
MPS45 PU (1) 1006-2203
MPS60 PU (1) 1006-2204
MPS10-ACL (1) 1006-2285
MPS20-ACL (1) 1006-2281
MPS30-ACL (1) 1006-2282
MPS45-ACL (1) 1006-2283
MPS60-ACL (1) 1006-2284
Order Name Q'ty
MPR5 PU (1) 1006-2205
MPR10 PU (1) 1006-2206
Order No.
Power regeneration type control board for
MPS10
Power regeneration type control board for
MPS20 to 60
Card with status indicator
DC power supply unit: Continuous power
supply capacity 11 kW (15 hp)
DC power supply unit Continuous power
supply capacity 20 kW (27 hp)
DC power supply unit: Continuous power
supply capacity 30 kW (40 hp)
DC power supply unit: Continuous power
supply capacity 45 kW (60 hp)
DC power supply unit: Continuous power
supply capacity 60 kW (80 hp)
AC reactor for MPS10 (with Capacitor)
AC reactor for MPS20 (with Capacitor)
AC reactor for MPS30 (with Capacitor)
AC reactor for MPS45 (with Capacitor)
AC reactor for MPS60 (with Capacitor)
Order No.
DC power supply unit: Continuous power
supply capacity 5 kW (6.7 hp)
DC power supply unit: Continuous power
supply capacity 10 kW (13.3 hp)
4742-E P-62
Eeospcsa2004
Eeospcsa2005
Description
Eeospcsa2006
Description
