  • Page 1 1/36 ENGLISH Installation and maintenance Download this document on www.aereco.com MS Management System VBP+ TF5602_E Aereco S.A.

  • Page 2: Table Of Contents

    Default ‘Temperature’ ..............................30 Default ‘Fan’ ..................................31 Permanent "MAXIMUM LEVEL" mode ..........................32 TECHNICAL MAINTENANCE ..............................33 WARRANTY .................................... 34 ENVIRONMENTAL CONCERNS ............................34 VBP + is marketed in France by ACTHYS company under the brand “HELYS 800”. Aereco S.A.

  • Page 3: Introduction

    Power cable modification or replacement must only be carried out by qualified personnel or by After-sales  Service in order to avoid any accident. Children being supervised not to play with appliance.  Aereco S.A.

  • Page 4: System Overview

    Returns default information on distant indicator that can be used in particular in the context of BMS. This length allows to comply with the CEM and to limit the lost tension. It allows also to connect 2 modules located on two appended DIN rail. Aereco S.A.

  • Page 5: Specific Components

    Specific components MS management system has 3 specific components, available exclusively at Aereco or its resellers. Other system components (circuit breaker, power, etc...) can be bought on the market as long as they respect the technical features mentioned in this document.

  • Page 6: Specific Functions Of Each System Component

    Example of a setting adjusting the fan speed according to temperature: Instead or in addition of the temperature sensor, it is possible to connect the following inputs, available on the market, respecting the technical features mentioned in this document. Aereco S.A.

  • Page 7: Operation Of The Management System With Wind Gauge

    During the “boost airflow” period: Maximum speed of the setting.  Out of “boost airflow” periods: Operation according to the temperature (if sensor) or minimum speed (=  “natural ventilation” mode). Aereco S.A.

  • Page 8: Technical Characteristics Of The Components

    Connection to the electric circuit : 250 V~max and 10A max. Main module Power supply in 5VDC Aereco – ref. VB21119 1 for up to 25 3 wires input for probe fans Output « alarm relay » 2 wires: 0-5V (max.

  • Page 9: Dimensions

    9/36 Component Characteristics Supplier / reference Quantities Temperature Temperature range = - 55°C to +125°C Aereco – ref. 1 per Main Signal type = « 1 wire » (specific) AVE1146XX module probe Wind gauge 230 VAC supply HAGER – ref : TG050 1 per Main Temperature range = -25°C to +50°C...

  • Page 10: Installation & Electrical Connections

    Terminal 11-12 : Output “NC” (normally closed before setting off)  The scheme next page is showing an overview of the system connections, as recommended by Aereco. Other installation are possible; please check the compliance with your local regulation. Aereco S.A.
  • Page 11 11/36 Aereco S.A.

  • Page 12: Sensor(S) Electrical Connections

    10 m maximum length,  Ambient condition resistant (including UV resistance)  The cable must not include driver colour "yellow / green", colour used for ground only.  The power in the cables does not exceed 20 mA. Aereco S.A.

  • Page 13: Temperature Sensor Connection Only

    13/36 Temperature sensor connection only Aereco S.A.

  • Page 14: Wind Gauge Connection Only

    14/36 Wind gauge connection only Aereco S.A.

  • Page 15: Clock Connection Only

    15/36 Clock connection only Aereco S.A.

  • Page 16: Temperature Sensor + Wind Gauge Connection

    16/36 Temperature sensor + wind gauge connection Aereco S.A.

  • Page 17: Temperature Sensor + Clock Connection

    17/36 Temperature sensor + clock connection Aereco S.A.

  • Page 18: Fan(S) Connection

    Each fan must have a number for easy installation and maintenance: Note a number on the label of the fan and copy it  on the label of the corresponding module (insert " N. "). Identify both cable endings using the same  number. Aereco S.A.
  • Page 19 Fan module terminal '4 ' on terminal '4' of the fan  Electronic driving box of the fan 3) Check that the jumper pin located at the top right of the electronic driving box of the fan is on pins '1 '& '2' "MS mode". Aereco S.A.

  • Page 20: Start-Up

    1) Identify each fan that you want to group together and note the group number in the insert "Gr" on each corresponding Fan module. Important: a maximum of 5 groups are possible having each a maximum of 5 fans. Aereco S.A.
  • Page 21 & 15 are not used and correspond to the fan off (See § “Defects and failures”) The setting of the module can be done at every time, even when the appliance is working, the new setting will be then applied. The reset of the appliance won’t erase this setting. Aereco S.A.

  • Page 22: General Operation

    Running procedure system Reset A RESET must be done during the initial start-up to ensure reset of all system components. 1) Push down the button (" PB ") on the Main module and then turn on the system. Aereco S.A.
  • Page 23 2) The button must remain pressed during 3 sec; this time corresponds to the loading time shown below. If the button is released before the end, the RESET operation system is not performed. 3) At the end of the RESET, 2 flashes show the end of the operation. The button can be released. Aereco S.A.

  • Page 24: Initialisation

    1) TEST relay output The relay output is engaged during 3 seconds and then disengaged: 2) LOADING of the Main module During this operation, a descending flashing light is shown on the two rows of the Main module: Aereco S.A.

  • Page 25: Configuration Procedure

    If this is not the case, please make a RESET.  The Main module displays the configuration mode (SETUP mode) as well as the group being input (here, group n ° 1) A maximum of 5 fans can be connected to 1 group. Aereco S.A.
  • Page 26 3) Repeat operations '1 '& '2' as many times as necessary. 4) To END and save the configuration procedure, press 2 times the Main module push button. If the Main module capacity is full then the configuration procedure is ended and saved automatically. Aereco S.A.
  • Page 27 The end of the configuration procedure is indicated by 2 flashes: In case of:  mistake of manipulation or information,  1 fan stays in « FAULT » mode (red light), Turn off the system. When it is on again, perform a RESET and repeat the configuration procedure. Aereco S.A.

  • Page 28: Running System

     It is also the default mode if no input 'probe' is connected or read (see § “Defects and failures”).  NATURAL mode: every fan is at its minimum level (Active wind gauge). See chart on page 6. Aereco S.A.
  • Page 29 11°C ≤ to < 15°C 8°C ≤ to < 11°C 2°C ≤ to < 8°C - 55°C ≤ to < 2°C (minimum probe) INFORMATION on the Fan module:  Fan on with the good speed level (see the modes above) Aereco S.A.

  • Page 30: Defects And Failures

     The module displays the "Fault" mode and indicates a temperature default by the light "Setup / Probe".  The system shows the “MAXIMUM LEVEL” mode on the row of LEDs on the right.  The Fan modules display a normal operation Aereco S.A.

  • Page 31: Default 'Fan

    LEDs on the right (in this example group 4 is off). INFORMATION on Fan modules: Group(s) in good Group(s) in default operating Fan turned off having a Fan turned off in default Fan turned off but OK Fans on wrong setting Aereco S.A.

  • Page 32: Permanent "Maximum Level" Mode

    Fixed module into one of the 2 position below: If a fan module is staying in this position, it can be a problem of setting  proceed to a RESET and set again the appliance. If the problem persists, contact your reseller. Aereco S.A.

  • Page 33: Technical Maintenance

    NORMAL mode.  Release the button. WAIT 5 minutes. If the problem has not been fixed by the previous operations then the system will fall back to the FAULT mode. In this case, please contact your reseller. Aereco S.A.

  • Page 34: Warranty

    This guarantee is valid for two years from the original date of purchase of your appliance, for faults of the appliance, which have been caused by faulty construction. On these conditions, Aereco guarantee the replacement or the supply of the equipment found to be defective after inspection by its after sales service. In any case, the warranty may not cover additional costs, of labour, transport or compensation of any kind.
  • Page 35 35/36 Aereco S.A.
  • Page 36 36/36 Manufacturer: Aereco S.A. 62 avenue de Lamirault Collégien 77615 MARNE LA VALLEE CEDEX 3 FRANCE Aereco S.A.
