GM1020 gigaMESH Quick Start Guide
This document provides general installation practices for the
Calix GM1020 gigaMESH.
This document also provides guidance for site preparation,
installation, and basic troubleshooting.

Package Contents

gigaMESH Satellite - Model GM1020
GM1020 gigaMESH Quick Start Guide (this guide)
Product identifi cation labels with login credentials (x2)
www.calix.com
Scan the QR code at left to access the
installation instructions for this product. All
product documentation is available online
from the Calix Resource Center (support.
calix.com).
P/N 220-01106, Rev 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM1020 gigaMESH and is the answer not in the manual?

Questions and answers

Summary of Contents for Calix GM1020 gigaMESH

  • Page 1: Package Contents

    All product documentation is available online from the Calix Resource Center (support. calix.com). Package Contents gigaMESH Satellite - Model GM1020 GM1020 gigaMESH Quick Start Guide (this guide) Product identifi cation labels with login credentials (x2) www.calix.com P/N 220-01106, Rev 10...

  • Page 2: A Quick Look

    7931 AC Power Brief Overview The GM1020 gigaMESH off ers the following key features: Mesh Enhanced Carrier Class Wi-Fi - In conjunction with the gigaSPIRE and Calix Support Cloud (CSC), the GM1020 gigaMESH provides an end-to-end wireless network over the dual 802.11b/g/n/ac 2.4 GHz and 5 GHz radios.
  • Page 3 Mounting the gigaMESH The GM1020 gigaMESH must be plugged into an AC power outlet. Orientation can be either up or down relative to the Powering the 804Mesh power outlet. To power the equipment: Unbox the gigaMESH and remove the outer plastic bag.
  • Page 4 To complete the network connection, ensure the gigaMESH has completed boot-up and connect in either of two options: Connect the GM1020 gigaMESH to the upstream gigaSPIRE using a CAT5 or better Ethernet cable. The gigaMESH will automatically synchronize with the upstream gigaSPIRE.

  • Page 5: Frequently Asked Questions

    Q: What if the User Name or password are forgotten for the gigaSPIRE? A: Press the reset button of the gigaSPIRE for at least ten seconds. Q: What mounting options are available for installing the GM1020 gigaMESH? - 5 -...

  • Page 6: Potentially Explosive Atmosphere

    A: The gigaMESH must be plugged into any available 110 VAC standard outlet. The unit can be oriented in any direc- tion. Q: What is the diff erence of “Ethernet-WAP mode” vs “Wi-Fi backhaul mode” of the gigaMESH? A: In Ethernet-WAP mode, the 5 GHz Wi-Fi bandwidth is shared with all client devices and employs an Ethernet cable to support backhaul traffi...

  • Page 7: Utilisation Prévue

    CAUTION! Use of any controls, adjustments, or procedures other than those specifi ed herein may result in hazardous radiation exposure. Utilisation prévue Ce produit est classé comme équipement de télécommuni- cation non destiné à l’achat direct par le public. Ce produit est conçu et approuvé pour utilisation en intérieur uniquement.

  • Page 8: Environmental Conditions

    Environmental Conditions Maximum environmental values during use: Temperature: 0° C to +40° C (32° to 104° F), Humidity: 10% to 90% RH, non-condensing, 200 - 10,000 feet altitude. License Information Open Source Software Utilization Notice The gigaMESH uses Open Source Software Programs. Such software programs are made available subject to certain third-party terms and conditions.
  • Page 9 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 10 Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
  • Page 11 Industry Canada statement: This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’...
  • Page 12 Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé à plus de 23 cm entre le radiateur et votre corps.
