Spearhead QUADSAW 1602/2002/2402

CORRECT LIFTING OF THE QUADSAW

Spearhead recommends that the Quadsaw is stored on a suitable pallet when not in
use. If it needs to be moved use a pallet lifter or forklift. Alternatively it can be lifted
with an authorized rope or something similar. The 1602 weighs 110 kg, the 2002
weighs 198 kg and the 2402 weighs 239 kg. The rope must be authorized for the
required weights as a minimum, but preferably more for greater safety.
Twist and loop the
strap for safety
(not shown in picture)
After Storage:
Follow the recommended maintenance advice given in this manual. Pay particular
attention to the condition of the sawblades and belts.
Remember that the Quadsaw (all models) is constructed to resist even the toughest
conditions and that with some care and attention it will supply you with many years of
problem-free service. To avoid problems and ensure that it is covered by the
guarantee, always use original spare parts and make sure that the machine is not
used for anything else than described in this manual.
Before attempting to repair, maintain
or adjust the machine, always make
REMEMBER:
Regular maintenance will increase the lifespan and the resale
price of the machine.
WARNING!
sure that the tool has stopped, the
ignition key is removed, hydraulics
disconnected, hand brake secured
and the tool is safe on the ground.
51
