Summary of Contents for Concordia XPRESS

  • Page 1 XPRESS Technician’s Manual...
  • Page 2 Concordia Coffee Systems 1287 120 Avenue NE Bellevue, WA 98005 (425) 453-2800 (800) 778-0990 (425) 453-2167 Fax http://www.concordiacoffee.com/ Technical Writer and Editor: Shana McKibbin Technical Support: Gary Williams, Gery Jaggars, Chris Collier, Dana Klatt, Allen Moore, Dave Davis Graphic Engineers: Dan Gilbert, Quan Nguyen...
  • Page 3 Revision Change Log Replace With New Brief Description Date Old Section Section Revision...

  • Page 4: Table Of Contents

    Table of Contents Section 1 :: Xpress Overview ..............1-1 Xpress Overview ....................1-2 Xpress Components.................... 1-3 Flavor System Overview ..................1-4 Flavor System Components ................1-5 Section 2 :: Installation and Removal ............2-1 Technical Specifications and Site Requirements ..........2-2 Machine Dimensions ...................
  • Page 5 Software Menu Informational Screens .......... 4-2 Categories ..................4-2 Service Switch ..................... 4-3 Navigating the Software Menu ............4-4 Accessing a Sub-Category ............4-4 Exiting the Menu System ............... 4-5 Accessing the Grand Total Drink Count ........4-5 Accessing Total Drink Count Statistics ......... 4-5 Accessing Daily Drink Count Statistics .........
  • Page 6 Pressure Gauge ................5-13 Heating Elements ................ 5-13 Pressure Relief Valve ..............5-13 High Temperature Limit Switch ........... 5-13 Steam Valves ................5-14 Left Steam Valve ................. 5-14 Center Steam Valve ..............5-15 Right Steam Valve ............... 5-15 Air Purge Process ............... 5-15 Captive Water Purge System ............
  • Page 7 Air Vent Needles ................7-6 Connection of Milk Pump Assembly and Air Gate Valve Assembly 7- Alt Milk Valve ....................... 7-6 Steam Delivery Components ................7-7 Steam Valves ................7-7 Mixing TEE Assembly ..............7-7 Refrigeration Unit Overview ................7-8 Placing Milk in the Machine ............
  • Page 8 Daily Maintenance..................... 11-2 Concordia Cleaning Products............11-2 Cleaning Timers ....................11-3 Preventive Maintenance ................... 11-3 Section 12 :: Concordia Procedures ............12-1 Service Call Process ..................12-2 Arrival to Site ................12-2 Machine Repair ................12-2 Hold for Parts Procedures ............12-2 Departing from Site ..............
  • Page 9 Vending System: No Display on Card Reader ......15-57 Section 16 :: Parts Lists & Diagrams ............16-1 Recommended Tools List ................. 16-2 Standard Tools ................16-2 Concordia Stocked Tools ............16-2 Consumables ................16-2 Parts Lists and Diagrams .................. 16-3 Diagram 1: Machine Overview ............ 16-4 Diagram 1, Parts List: Machine Overview ........
  • Page 10 Diagram 10: Parts List, Milk Pump Assembly ......16-23 Diagram 11: Product Delivery Assembly, Xpress 6 ....16-24 Diagram 11, Parts List: Product Delivery Assembly, Xpress 6 . 16-25 Diagram 12: Product Delivery Assembly, Xpress 0 ....16-26 Diagram 12, Parts List: Product Delivery Assembly, Xpress ..16-27 Diagram 13: Refrigeration Unit Assembly .........
  • Page 11 Page Intentionally Left Blank...
  • Page 12 Page Intentionally Left Blank...

  • Page 13: Section 1 :: Xpress Overview

    Section 1 :: Xpress Overview Xpress Overview Xpress Components Flavor System Overview Flavor System Components...

  • Page 14: Xpress Overview

    Section 1: Xpress Overview 3033-001B Xpress Overview Concordia Xpress Technical Support Manual 2900-300B...

  • Page 15: Xpress Components

    Product Delivery Bracket The product delivery bracket holds the milk bowl (not shown) and the syrup manifold. Product Delivery Nozzle The finished drink is poured through the product delivery nozzle and into the customer’s cup. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 16: Flavor System Overview

    Section 1: Xpress Overview 3033-001B Flavor System Overview CHOCOLATE HEATER ASSEMBLY Concordia Xpress Technical Support Manual 2900-300B...

  • Page 17: Flavor System Components

    Power Supply The power supply provides 24Vdc power to the control unit. Chocolate Heater Assembly The chocolate heater assembly provides heat to the chocolate sauce, to ensure a minimum temperature of 85°F (29.4°C) is maintained. Concordia Xpress Technical Support Manual 2900-300B...
  • Page 18 Section 1: Xpress Overview 3033-001B Page Intentionally Left Blank Concordia Xpress Technical Support Manual 2900-300B...

  • Page 19: Section 2 :: Installation And Removal

    Section 2 :: Installation and Removal Technical Specifications and Site Requirements Machine Dimensions Installation Plumbing Flavor System Additional Tasks Required at Installation Operational Configuration Machine Calibration Customer Training 10. Installation Checklist 11. Removal Procedures...
  • Page 20 A fresh water bypass is required for sites with a reverse osmosis filter system Scalex Water Treatment System Included with the unit: two cartridges (one carbon, one softener) 25”H x 11”W x 5.25”D 63.5cmHx28cmWx13.34cmD Concordia Xpress Technical Support Manual 2900-300B...

  • Page 21: Machine Dimensions

    Section 2: Installation and Removal 3033-002B Machine Dimensions Concordia Xpress Technical Support Manual 2900-300B...

  • Page 22: Installation

    Plug and Receptacle – US only Confirming Receptacle Voltages Connections Voltage IBS6+ Equipped w ith 4 prong 208 volt plug Xpress equipped with 4 prong 208 volt plug 110Vac – 120Vac L1 to Ground 110Vac – 120Vac L1 120VAC L2 to Ground TO NEUTRAL 110Vac –...

  • Page 23: Configuring Transformer Auxiliary Connector #1

    VOLTAGE RANGE SETTING 200 – 205 NO ADJUSTMENT 206 – 215 NO ADJUSTMENT 216 – 225 220-240 #3 GREEN WIRE 226 – 235 220-240 #4 WHITE WIRE 236 – 245 220-240 #2 ORANGE WIRE Concordia Xpress Technical Support Manual 2900-300B...

  • Page 24: Plumbing

    Water source must be located within five feet (1.5 meters) of machine  All machines ship with a Scalex water treatment system Prior to connecting the water filter to the machine, flush the water filtration system with 2 gallons (8 liters) of water. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 25: Problems With Reverse Osmosis Water System

    It is important to verify flavor volume and ensure it meets the requirements and preferences of the customer. Please see the Changing the Flavor Pour Rate topic in Section 9: Flavor System, for information and directions for adjusting the time and volume of flavor pours. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 26: Additional Tasks Required At Installation

    Install the cup stand beneath the product outlet. Operational Configuration The Xpress is configured with a default recipe. However, it may still be necessary to make minor adjustments to the grinder settings or milk levels, depending on an existing customer recipe or customer preference.

  • Page 27: Machine Calibration

    Concordia within 24 hours of installation. Removal Procedures Prepare and package machine and components following the procedure described in the Concordia Shipping Kit (PN 2900-142). 1. Record the drink GRAND TOTAL on the service invoice. 2. Record the machine serial number.
  • Page 28 11. If Demo Machine: remove, clean, and pack water filtration system. 12. Ensure the User Guide and cleaning cards are included with the unit. 13. Coil the power cord, water supply line, and drain hose and secure with a Ty-Wrap®. 2-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 29: Section 3 :: Electrical

    Section 3 :: Electrical Electrical Block Diagram Fuses Backplane AC Drawer Assembly DC Power Supply Board CPU Board Peripheral Connections Configuration Transformer Power Into the Machine 10. DC Power Supply Board LEDs 11. Heater Element Wiring Diagrams 12. Jumper Plug Connector Detail...

  • Page 30: Electrical Block Diagram

    Chip #2 Air Valve Motor Motor DC Voltage Fuse Speed Cntrl Syrup Fuse # on DC Board Mini Backplane Control Box Jumper Plug on Back Board Vent Display Plane Valve Expansion PCA F16 F17 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 31: Fuses

    Transducer, Display, CPU, Analog Board, Steam Tank, Level Sensor Fans, Valves, Relays, Main AC Contactor Group Motors Rear Grinder Panel Block Two 20amp ceramic fuses per element protect the machine in the event the heating element shorts out. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 32: Backplane

    DC Power Supply Board Output Board DC Power Supply Board Input from Transformer DC Input/Output Signals for Grinders and AC Drawer Pump Mounts below Backplane Connects to AC Board/Drawer Relays Power In Heating Elements Concordia Xpress Technical Support Manual 2900-300B...

  • Page 33: Ac Drawer Assembly

    MOUNTING PLATE Solid State Relay Configuration The Solid State Relay configuration is based on the wiring configuration: Single Phase: Two Relays Triple Phase: Three Relays High Leg: One Relay Diagram is single phase configuration. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 34: Dc Board Assembly

    Section 3: Electrical 3033-003B DC Board Assembly TEST POINTS LED'S 200VAC 220VAC 240VAC DC FUSES Concordia Xpress Technical Support Manual 2900-300B...

  • Page 35: Cpu Board

    Inhibit auto-run of brew At times, inhibiting brew group initialization is Initialize brew group group initialization required.  Load software Reserved Reserved. Factory use only. (Press button 1 at the Bottom (no current function) same time) Concordia Xpress Technical Support Manual 2900-300B...
  • Page 36 Section 3: Electrical 3033-003B Concordia Xpress Technical Support Manual 2900-300B...
  • Page 37 Section 3: Electrical 3033-003B Air Vent on Air Gate Assembly Concordia Xpress Technical Support Manual 2900-300B...

  • Page 38: Peripheral Connections Configuration

    CONTROL BOX CONTROL BOX side view front view milk dc voltage pumps input syrup syrup syrup pumps valves control SYRUP RACK WITH WARMING MAT 115vac WARMING CIRCUIT SYRUP DRIVER POWER SUPPLY 3-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 39: Transformer

    SECONDARY OUTPUT 15 Pin Transformer Plug output to DC Power Supply Board ORANGE 240V AUXILIARY GREEN 220V CONNECTOR 1 PRIMARY INPUT WHITE WHITE 230V BLUE TRANSFORMER BROWN 4 Pin Transformer Plug (from JP9) Concordia Xpress Technical Support Manual 3-11 2900-300B...
  • Page 40 All remaining components operate on DC voltage. All control voltage is Valves All water and steam valves in the Xpress function using a negative switching circuit. Voltage is always present at the component. The drives for the valves are located on CPU board. The CPU provides the ground to close the circuit and energize the valve.
  • Page 41 Large Flavor 4 Small Flavor 5 Green Hazelnut Large Flavor 5 Small Flavor 6 Blue Sugar-Free Vanilla Large Flavor 6 For additional information on the flavor system, please see Section 9: Flavor System. Concordia Xpress Technical Support Manual 3-13 2900-300B...
  • Page 42 CPU boards  LED display on CPU  CPU buttons  Backplane  Line voltage test receptacle  Electrical enclosure fan Electrical Enclosure           3-14 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 43: Power Into The Machine

    10. The DC power supply board converts the AC voltages to many legs of DC voltage. 11. DC voltages are distributed through the backplane, through JP4. 12. The backplane distributes voltage to the rest of the machine. Concordia Xpress Technical Support Manual 3-15 2900-300B...
  • Page 44 Setting the DC Jumper Plug (J1)  Confirming Receptacle Voltages Plug and Receptacle Connections Voltage XPRESS 6 Equipped with 4 prong 208 volt plug L1 to Ground 110Vac -120vac 110Vac – 120Vac L1 120VAC L2 to Ground TO NEUTRAL 110Vac –...
  • Page 45 13. Reinstall back panel and proceed with machine installation. Transformer is accessible from the back of the machine CONNECTORS #2, #3, #4 AUXILIARY ORANGE 240V CONNECTOR #1 GREEN 220V WHITE WHITE 230V BLUE TRANSFORMER BROWN Concordia Xpress Technical Support Manual 3-17 2900-300B...

  • Page 46: Dc Power Supply Board Leds

    DC Board, Hall-Effect Controlled Sensors, Flowmeter Current 11Vdc± Refer Chip 1  Non-Fused 4amp 11Vdc±  Non-Fused Refer Chip 2 4amp 11Vdc±  Non-Fused Refer Chip 3 4amp CPU, Display, and  -12Vdc Transducer 3-18 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 47 A fuse block containing four 20amp ceramic Slo Blo fuses protects the machine in the event of a heating element short. Steam and Water Tank Heater Connections Fuse Block, CE High Leg Concordia Xpress Technical Support Manual 3-19 2900-300B...

  • Page 48: Heating Element Wiring Diagrams

    3033-003B Heating Element Wiring Diagrams The water and steam tank heating elements must be wired in relation to the voltage configuration supplied to the machine. The fuse block shown below is single phase. 3-20 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 49: Jumper Plug Connector Detail

    Section 3: Electrical 3033-003B Jumper Plug Connector Detail Jumper Plug 1 BACKPLANE JP10 Power In P1 CONNECTOR DETAIL (viewed from back of machine) SOLID STATE SOLID STATE Concordia Xpress Technical Support Manual 3-21 2900-300B...
  • Page 50 3033-003B BACKPLANE Jumper Plug 2 JP10 Power In 24Vdc for TOP FANS AND RECIR FAN SHARE 24Vdc & EXHAUST FAN MILK PUMP & LATTE AIR GATE Jumper Plug 3 BACKPLANE JP10 Power In 3-22 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 51 Section 3: Electrical 3033-003B Jumper Plug 6 BACKPLANE JP 6 CONNECTOR DETAIL JP10 Power In Jumper Plug 7 BACKPLANE JP10 Power In Concordia Xpress Technical Support Manual 3-23 2900-300B...
  • Page 52 Section 3: Electrical 3033-003B Jumper Plug 8 BACKPLANE JP10 Power In BACKPLANE Jumper Plug 10 JP10 Power In 3-24 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 53 Power In from AC Drawer (For Steam Tank Elements) To Steam Tank Elements BACKPLANE JP10 To Water Tank Elements Power In Power In from AC Drawer WATER TANK ELEMENTS (For Water Tank Elements) Concordia Xpress Technical Support Manual 3-25 2900-300B...
  • Page 54 Section 3: Electrical 3033-003B Page Intentionally Left Blank 3-26 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 55: Section 4 :: Software

    Section 4 :: Software Software Overview Service Switch Software Quick Reference Table Calibration Espresso Extraction Pre-Treatment Options CPU Board Loading New Software to a Machine...

  • Page 56: Software Overview

    Section 4: Software 3033-004B Software Overview The Xpress user interface contains drink statistics, programming access, and diagnostic service information. Software Menu Informational Screens GRAND TOTAL Displays the total number of drinks dispensed. PART NUMBER Displays the Concordia part number of the installed software.

  • Page 57: Service Switch

    Once the service switch is in the CLEAN position, press the PROGRAM button three times. The display will change from SELECT DRINK to SELECT CATEGORY. When not cleaning the machine or accessing the software menu, ensure the service switch is in the VEND position. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 58: Navigating The Software Menu

    EXAMPLE Viewing the LAST MILK CLEAN date and time 1. Press the PROGRAM button three times. SELECT CATEGORY will appear in the display. 2. Navigate to MILK TIMINGS - HOT > LAST MILK CLEAN. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 59: Exiting The Menu System

    4. Press the PROGRAM button. 5. Press the SCROLL UP arrow to scroll through the statistics. 6. Press the PROGRAM button once to exit. To Exit: 1. Press the PROGRAM button once. 2. Press any drink button. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 60: Software Quick Reference Table

    : All machines are shipped with factory defaults. Default settings change periodically, so if you need to verify a specific default, please contact Concordia Beverage Systems for assistance at 1-800-778-0990. NOTE : If the machine is configured for a non-US location, temperatures will be shown in Celsius and currency will be shown using either the euro or British pound symbol.
  • Page 61 0.5 gram Single Decaf 23.0 0.5 gram Double Decaf 23.0 0.5 gram Triple Decaf 23.0 0.5 gram Small Coffee Decaf 23.0 0.5 gram Large Coffee Dec 23.0 0.5 gram Grind Adj Arrows ON, OFF Concordia Xpress Technical Support Manual 2900-300B...
  • Page 62 Adjustable by Single 5 mL Double 5 mL Triple 5 mL Small Americano 5 mL Large Americano 5 mL Sm Brewed Coffee 5 mL Lg Brewed Coffee 5 mL Hot Water Time 60.0 1.0 second Concordia Xpress Technical Support Manual 2900-300B...
  • Page 63 Tpl Lg Cappuccino 0.5 second Small Chai Latte 0.5 second Large Chai Latte 0.5 second Small Hot Choc 0.5 second Large Hot Choc 0.5 second Sm Steamed Milk 0.5 second Lg Steamed Milk 0.5 second Concordia Xpress Technical Support Manual 2900-300B...
  • Page 64 Small Chai Latte 99.00 0.05 Large Chai Latte 99.00 0.05 Sm Steamed Milk 99.00 0.05 Lg Steamed Milk 99.00 0.05 Espresso 99.00 0.05 Extra Shot 99.00 0.05 Small Syrup 99.00 0.05 Large Syrup 99.00 0.05 4-10 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 65 1°F 100°F 145°F 1°F Normal Steamed 145°F 165°F 1°F Extra Hot Steamed 165°F 180°F 1°F Kid Frothed 100°F 145°F Normal Frothed 1°F 165°F 165°F Extra Hot Frothed 1°F 180°F 180°F Froth Air Start Concordia Xpress Technical Support Manual 4-11 2900-300B...
  • Page 66 Left Drive Milk Level HI-CAP CONFIGURATION Ext Milk Pump Rear ONLY HI-CAP CONFIGURATION Ext Milk Pump Frnt ONLY Syrup Purge Valve Syrup Wand Steam Valve Wand Vac Valve Wand Air Pump WAND VACUUM VALVE 4-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 67: Calibration

    Section 4: Software 3033-004B Calibration Concordia refers to calibration as the process of adjusting the Xpress to extract the perfect drink. The Xpress may require adjustment to perform within specific extraction parameters using the customer’s choice of beans and settings.

  • Page 68: Calibrating Pump Pressure

    The bean hoppers only need to be configured if the machine will not be serving regular and decaffeinated espresso drinks. However, the Xpress can also be programmed to serve both espresso drinks and coffee drink. 1. Place coffee beans in the rear grinder.

  • Page 69: Espresso Extraction And Temperature Parameters

    Extraction Temperature Parameters Unless otherwise specified, the calibration goal for the Concordia Xpress is to extract a double espresso in 18-23 seconds. The extraction time for a single shot of espresso is based on the extraction time for a double.

  • Page 70: Calibrating Milk Timings

    One fluid ounce equals approximately 30mL. For example, calculating the brewed coffee timing for a 12oz cup would 12 x 30 = 360mL The default settings for brewed coffee are 12oz/355mL and 16oz/475mL. 4-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 71: Calibrating Flavor Timings

    This pre-infusion process enhances the quality of the espresso shot. The Xpress has eight pre-treatment options, each varying in the specific pressure used to pack the ground beans, the amount of water used to pre-infuse, and the delay between the pre-infusion and the brewing. The pre-treatment settings for single, double, and triple shots are individually adjustable.
  • Page 72 Pressure on the ground coffee is slightly increased. PRE-TREATMENT #7  Espresso grounds are pre-infused for 4/10 of a second.  A four-second delay before brewing.  Pressure on the ground coffee is slightly increased. 4-18 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 73: Cpu Board

    Inhibit auto-run of brew At times, inhibiting brew group initialization is Initialize brew group group initialization required.  Load software Reserved Reserved. Factory use only. (Press button 1 at the Bottom (no current function) same time) Concordia Xpress Technical Support Manual 4-19 2900-300B...

  • Page 74: Loading New Software To A Machine

    HyperTerminal. Configuring HyperTerminal 1. Open HyperTerminal. 2. Go to File > New Connection. 3. Select the COM port assigned to the serial adapter being used from the Connect using: drop-down menu. 4-20 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 75 Section 4: Software 3033-004B 4. Click Configure. 5. Select 9600 from the Bits per second: drop-down menu Concordia Xpress Technical Support Manual 4-21 2900-300B...
  • Page 76 Section 4: Software 3033-004B 6. Select 8 from the Data bits: drop-down menu. 7. Select None from the Parity: drop-down menu. 4-22 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 77 Section 4: Software 3033-004B 8. Select 1 from the Stop bits: drop-down menu. 9. Select None from the Flow control: drop-down menu. 10. Click OK. Concordia Xpress Technical Support Manual 4-23 2900-300B...
  • Page 78 Section 4: Software 3033-004B 11. Select Terminal Keys under the Function, arrow and ctrl keys act as section. 12. Select Ctrl + H under the Backspace key sends section. 4-24 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 79 Section 4: Software 3033-004B 13. Select ANSI from the Emulation: drop-down menu. 14. Enter 999 as the Backscroll buffer lines value. Concordia Xpress Technical Support Manual 4-25 2900-300B...
  • Page 80 Section 4: Software 3033-004B 15. Click ASCII Setup…. 16. Check the box for Wrap lines that exceed terminal width. 17. Click OK. 18. Click OK. 4-26 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 81: Connecting A Laptop To A Machine

    NOTE: Newer laptops may require a USB-to-RS232 adapter. 3. Press the service switch into the SERVICE position. 4. Open HyperTerminal and press Enter. 5. If the connection was successfully made, Field will appear in the HyperTerminal window. Concordia Xpress Technical Support Manual 4-27 2900-300B...
  • Page 82 Section 4: Software 3033-004B 6. Type Load, and then press Enter. 7. Go to Transfer > Send File. 4-28 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 83 Section 4: Software 3033-004B 8. Select Browse, and then navigate to the directory with the file to download. 9. Highlight the file to download, and then click Open. Concordia Xpress Technical Support Manual 4-29 2900-300B...

  • Page 84: Updating Software For Customers With Custom Drink Recipes

    3. Select Browse, and then navigate to the directory with the file to download. 4. Select the recipe file to download. NOTE : A recipe file has a Concordia part number as part of the file name. Ensure you select the correct part number for the customer. 5. Click Send.

  • Page 85: Section 5 :: Plumbing

    Section 5 :: Plumbing The Water System Hot Water Tank Water Pump and Motor The Steam System...
  • Page 86 Milk Pump WAND (ASW) (Optional) High Limit Switch Syrup Manifold (Xpress 6) To Drain Milk Manual Manual Milk (w/Syrups - Xpress 6) Drain Valve Drain Valve Air Gate Valve System Check Valve WATER Alt Milk Valve External Water Filtration REFRIGERATOR...

  • Page 87: Line Pressure

    The back-flow prevention device (check valve) is required by many state and local health codes and inhibits reverse water flow into the water supply. Water Filtration System The Scalex® water treatment system includes a carbon filter cartridge and a water softener cartridge. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 88: Hot Water Tank

    The water tank is located behind the brew group. Temperature/Level Probe Pressure Relief Valve Hot Water Valve Brew Valve Hot Water Output Hi Temp Limit Switch Coffee Output Water Inlet Heating Elements Flowmeter Concordia Xpress Technical Support Manual 2900-300B...

  • Page 89: Temperature/Level Probe

    Water Tank and Level Probe Not Grounded When the circuit is open and the CPU detects low water, the brew water valve opens and allows water into the tank. The heating elements are then inhibited. LOW WATER Concordia Xpress Technical Support Manual 2900-300B...

  • Page 90: Temperature Probe

    Water Inlet Water is supplied from the wall source to the hot water tank through the water inlet fitting. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 91: Flowmeter

    The hot water valve is used for dispensing hot water into the cup. The hot water valve is the top front solenoid on the dual manifold valve assembly located on top of the hot water tank. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 92: Draining The Hot Water Tank

    The pump is only activated when brewing espresso, pouring hot water and filling steam tank. The pump does not inhibit line pressure or water flow. The water pump and motor is located behind the brew group and underneath the hot water tank. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 93: Water Pressure Gauge

    60 seconds, the machine will time out and CHK WATER FLOW will appear on the machine’s display. To troubleshooting this error message, please see the Check Water Flow troubleshooting tree in Section 15: Troubleshooting. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 94: The Steam System

    The steam system heats the water that is used to froth milk for drinks. The steam tank is located in the upper right side of the machine and is accessed by removing the right side panel of the Xpress machine. Steam Tank – Front View...

  • Page 95: Steam Tank - Rear View

    Section 5: Plumbing 3033-005B Steam Tank – Rear View Concordia Xpress Technical Support Manual 5-11 2900-300B...

  • Page 96: Steam Tank Fill Valve

    ROUTINES, the probes will read either dry or wet. Verifying the water level probes in the steam tank uick 1. Navigate to TEST ROUTINES > UPPER STEAM PROBE. 2. WET is displayed, if probe is seeing ground. 5-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 97: Pressure Gauge

    260°F (127°C) In the event that the steam tank should overheat, the high temperature limit switch cuts the 24Vdc control signal to the solid state relay, which opens the circuit to the heating elements. Concordia Xpress Technical Support Manual 5-13 2900-300B...

  • Page 98: Steam Valves

    3033-005B Steam Valves The Xpress uses three steam valves, referred to as the left, center, and right steam valves. Each steam valve operates on the same voltage and has a different orifice size for regulating the steam flow from the steam tank.

  • Page 99: Center Steam Valve

    5. Close the steam drain valve. The red handle should be horizontal. 6. Replace the grounds bin in the machine and close the machine doors. 7. Reconnect the water supply at the source. 8. Reconnect the power supply to the machine. Concordia Xpress Technical Support Manual 5-15 2900-300B...
  • Page 100 Section 5: Plumbing 3033-005B Page Intentionally Left Blank 5-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 101: Section 6 :: Coffee System

    Section 6 :: Coffee System The Coffee System Grinders Bean Hoppers Brew Group Brew Group Components Gearbox Installation and Removal...

  • Page 102: The Coffee System

    Pressurized hot water is then introduced into the brew chamber where the coffee is extracted from the ground beans and delivered to the cup. Only espresso-roast beans can be used in the Xpress. Espresso Path With ground beans in the brew chamber, the chamber is sealed and hot water (195°F/85°C) between 135-140psi is forced through the ground...

  • Page 103: Grinders

    The upper burr remains stationary as the lower burr spins and the coffee beans are ground. The burrs are made up of two identical halves: an upper and lower burr. Double Grinder Assembly ASSY SWITCH –MAG-4 PT#2510-027 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 104: Calibration: Espresso Grind

    Four double espresso pours must occur in order to ensure the change of grind is fully implemented. It is possible to calibrate the Xpress for two different types of espresso- roast beans or for one espresso-based drink and one brewed coffee.

  • Page 105: Grinder Adjustment Diagram

    The GRIND ADJUST arrows and the espresso shot timer normally default to OFF when the Xpress machine is re-booted. Viewing the GRIND ADJUST arrows 1. Navigate to COFFEE PWDR DOSE > GRIND ADJ uick ARROWS.

  • Page 106: Coffee Powder Channel

    If the grinder adjustment flex cables are disconnected, the grinder adjustment should be set to mid-scale when reinstalled. When reinstalling the grinder, ensure the electrical harness wires are not trapped under the grinder bottom plate. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 107: Replacing The Grinder Burrs/Blades

    Adjust the grinder to the desired grind. It may be necessary to reset the indicator to mid-scale a second time. GRIND FLEX ADJUST SCREW CABLE FRONT GRINDER SCREW FINE COARSE CW = FINE CCW = COARSE FINE COARSE Concordia Xpress Technical Support Manual 2900-300B...

  • Page 108: Bean Hoppers

    Hopper Stopper Removing a Bean Hopper Once both hopper stoppers are in place, simply lift the bean hopper upwards. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 109: Brew Group

    After the espresso is extracted, the used grounds are directed into the grounds chute and into the grounds bin. Two 38Vdc motors drive the double-piston brew group. Pin Retaining Bracket Grounds Funnel Hot Water Tank Grounds Chute Left “Coffee” Piston Right “Brew” Piston Concordia Xpress Technical Support Manual 2900-300B...

  • Page 110: Brew Group Initialization

    Section 6: The Coffee System 3033-006B Brew Group Initialization Each time the Concordia Xpress is turned on, the brew group runs through 22 different steps to perform a self-calibration. The CPU monitors the coffee piston movement from the base of the brew chamber to the base of the brew piston.

  • Page 111: Hall-Effect Sensors

    (.089”). For reference, a credit card is approximately 1.5mm. Right Brew Piston Brew Chamber Left Coffee Piston Fixed Hall Effect Sensor Fixed Hall Effect Sensor Magnet Passes by Sensor As piston moves up Magnet Passes by Sensor As piston moves up Concordia Xpress Technical Support Manual 6-11 2900-300B...

  • Page 112: Left Piston

    68 Upper “Crash” Upper “Crash” 370-379 Home Position 358-364 102-68 Hall-Effect Sensor Hall-Effect Sensor 100-71 Lower “Crash” 80-71 Magnet 362-363 Home Position 487- 447 Lower “Crash” 6-12 Concordia Xpress Technical Support Manual Magnet Passes by Sensor 2900-300B As piston moves up...

  • Page 113: Viewing The Left Piston Movement

    Push shaft upward until lower piston head has cleared top of chamber. 9. Using a towel, grab piston head and pull upward until brew line is clear of chamber. Concordia Xpress Technical Support Manual 6-13 2900-300B...

  • Page 114: Removing The Right Piston

    12. Reinstall the upper piston assembly. 13. Verify the brew group operates correctly. 14. Reinstall the top panel and the bean hoppers. 6-14 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 115: Gearbox Removal And Installation

    This will allow the connector to move past the hot water drain line as you pull it out from the front of the machine. 10. Pull the gearbox out from the front of the machine through the grounds chute area. Concordia Xpress Technical Support Manual 6-15 2900-300B...

  • Page 116: Installing The Gearbox

    10. Re-install the lower piston into the brew chamber and secure it to the spindle shaft, using a screw. 11. Run a brew group initialization to reset. 12. Re-install the grounds chute. 6-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 117: Section 7 :: Milk System And Refrigeration Unit

    Section 7 :: Milk System and Refrigeration Unit The Milk Delivery System Milk Delivery System Components Milk System Theory of Operation Air Gate Valve Assembly Alt Milk Valve Steam Delivery Components Refrigeration Unit Overview...

  • Page 118: The Milk Delivery System

    Milk Pump The milk pump uses a gear pump to draw milk from the milk container in the refrigeration unit and through the milk system. The milk pump uses a 24Vdc motor. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 119: Milk System Theory Of Operation

    The default temperature of 241°F (116.1°C) is maintained by the steam tank during a latte or a steamed milk pour. Foamed Milk Temperature Setting The default temperature of 237°F (113.9°C) is maintained by the steam tank during a cappuccino pour. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 120: Initial Setup Of The Milk System

    9. If the temperature is above the optimal range, navigate to SET TEMPERATURES > FLAVOR OFFSET and reduce the flavor offset temperature setting and re-test the drink temperature. Repeat this process until the temperature is within 160 to 170°F (71 to 76°C). Concordia Xpress Technical Support Manual 2900-300B...

  • Page 121: Milk System Capabilities

    Section 7: Milk System and Refrigeration Unit 3033-007B Milk System Capabilities The Xpress milk system produces steamed milk at a rate of approximately 16.3mL per second up to 170°F (76°C) and dry cappuccino foam at a rate of approximately 10.4 mL per second up to 160°F (71°C).

  • Page 122: Air Gate Valves

    : When a milk-based drink is poured, voltage is sent to the alt milk valve to select the Milk #1 (front) container. When the NON-FAT MILK option is selected, the valve is not activated, and milk is drawn from the Milk #2 (rear) container. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 123: Steam Delivery Components

    Steam valves transfer steam from the steam tank into the mixing TEE. For more information, see the Steam Valves topic in Section 5: Plumbing. The Xpress espresso machine uses three steam valves, referred to as the Left, Center, and Right steam valves. Left Steam Valve Operating voltage: 24Vdc Orifice size: 0.6mm (0.025”)

  • Page 124: Refrigeration Unit Overview

    Refrigeration Unit Overview The espresso machine features a refrigeration unit, to house the milk used for drinks. The refrigeration unit is designed to accommodate two standard off-the-shelf 1-gallon (4-liter) milk containers. PT# 2320-036 PT# 98583 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 125: Placing Milk In The Machine

    If the temperature is not correct at that time, please contact Concordia Beverage Systems at 1- 800-778-0990. Concordia Xpress Technical Support Manual...

  • Page 126: Refrigeration Cooling Module Assembly

    1. Navigate to TEST ROUTINES > REFR CURRENT. 2. The current amperage across the refrigeration chips is displayed 3. If the current reading is less than 10amps, it’s possible one of the Peltier chips has failed 7-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 127: Fan Control Board

    The power for the heat sink fan is controlled by the fan control board, which is mounted on the back of the Xpress, behind the steam tank. The fan control board controls the speed of the heat sink fans by monitoring the internal temperature of the refrigeration unit.

  • Page 128: Interior Circulation Fan Assembly

    The temperature probe (PN 2660-031) is used to measure the internal temperature of the on-board refrigeration unit. The CPU monitors the temperature and adjusts the interior temperature through powering the Peltier chips in the refrigerator cooling module. 7-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 129: Milk Weight Trays

    Section 7: Milk System and Refrigeration Unit 3033-007B Milk Weight Trays The Xpress machine monitors the available milk levels using two milk weight trays. Each milk container is weighed independently. Milk levels are monitored using the milk weight trays and a notification message is displayed when milk levels are low or empty.
  • Page 130 : When calibrating a milk weight tray, adjust the magnet and remove the screwdriver from the milk weight tray. The presence of the screwdriver will affect the magnet and skew the count in TEST ROUTINES. 7-14 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 131: Adjusting A Milk Weight Tray

    6. If either number is incorrect, remove the milk container and adjust the screw on the milk weight tray until the above numbers are achieved. If the milk count does not change, verify the sensor is operating. Concordia Xpress Technical Support Manual 7-15 2900-300B...

  • Page 132: Milk Level Sensors

     If the rear container is empty, the display will read NO MILK- REAR.  If the front milk container is empty, the display will read NO MILK-FRONT.  The machine will beep. 7-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 133: Section 8 :: Steam Wands

    Section 8 :: Steam Wands Steam Wand Overview Automatic Steam Wand Automatic Steam Wand Wiring Replacing an Automatic Steam Wand Manual Steam Wand Replacing a Manual Steam Wand Installing a Steam Wand Cleaning a Steam Wand...

  • Page 134: Steam Wand Overview

    Section 8: Steam Wand 3033-008B Steam Wand Overview The Xpress has an optional steam wand feature. The steam wand can be used to steam liquids that cannot be run through the machine (e.g. eggnog, soy or flavored milks). There are two types of steam wands available: the manual steam wand and the automatic steam wand.

  • Page 135: Automatic Steam Wand Selections

    This selection will create above standard temperature steamed milk. EXTRA HOT + FROTHED This selection will create above standard temperature frothed milk. Press any steamed or frothed option button to end the manual steam process. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 136: Automatic Steam Wand Programming

    These valves are located behind the front panel. They are attached to the interior from on the right side of the machine. To remove and replace these valves, it is necessary to first remove the right side panel. Steam Valve Vacuum Break Valve Concordia Xpress Technical Support Manual 2900-300B...

  • Page 137: Automatic Steam Wand Wiring

    24Vdc for the valves. Replacing an Automatic Steam Wand Typically, to replace an automatic steam wand, the entire right door of the machine must be replaced. Call Concordia Beverage Systems for assistance at 1-800-778-0990. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 138: Manual Steam Wand

    10. Unfasten the PFA tubing at the elbow fitting. Use a 1/2" wrench. 11. Remove the four screws attaching the steam wand bracket. Use a #1 Phillip’s screwdriver. NOTE : Do not discard these screws. Concordia Xpress Technical Support Manual 2900-300B...
  • Page 139 15. Align the hole in the supplier handle assembly (PN 2790-106) with the hole in the lever adapter and install handle assembly. Tighten until flush. Use the long black 6-32 setscrew supplied (part of 2790-106). Concordia Xpress Technical Support Manual 2900-300B...

  • Page 140: Removing A Steam Wand

    Removing a Steam Wand Replacing the entire right door is required if a customer requests that the steam wand be removed from their machine(s). For instructions on replacing the door, call Concordia Beverage Systems for assistance at 1- 800-778-0990. Installing a Steam Wand Both types of steam wands are installed by the Concordia manufacturing team.

  • Page 141: Section 9 :: Flavor System

    Section 9 :: Flavor System The Flavor System Peristaltic Pumps Syrup Manifold Cleaning the Flavor Delivery System Priming the Flavor Delivery System...

  • Page 142: The Flavor System

    Before the poppet valve closes at the end of a chocolate-based drink pour, two pulses of hot water are flushed through the poppet valve, from a dedicated chocolate purge valve, to clear the poppet valve of chocolate sauce residue. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 143: Syrup Delivery Path

    The color coding of the flavor tubes is listed below. White Yellow Black Blue Green Chai Vanilla Caramel Chocolate Sugar-Free Vanilla Hazelnut Concordia Xpress Technical Support Manual 2900-300B...

  • Page 144: Flavor Storage Area

    85°F (29.4°C) or warmer. If the chocolate sauce is not warm enough to flow through the flavor tubes, you will not be able to finish installation of the Xpress. It is strongly recommended to always have to an extra box of chocolate sauce on the chocolate heater assembly, to ensure an uninterrupted supply of chocolate sauce is available.

  • Page 145: Changing The Flavor Pour Rate

    The adjustment to the milk pour time is controlled in the FLAVOR TIMINGS sub-category by the values SMALL 1-FLAVOR ADJ, SMALL 2-FLAVOR ADJ, LARGE 1-FLAVOR, LARGE 2-FLAVOR ADJ. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 146: Verifying Proper Syrup Flow

    32°F (0°C), then they are unusable. Do NOT use any syrup that has been frozen. Once the desired flavor button is pressed, the flavor will be dispensed for the time indicated. Concordia Xpress Technical Support Manual 2900-300B...

  • Page 147: Changing Flavor Boxes

    It may only be necessary to manipulate the bag for chocolate sauce to flow properly. For instructions on how to do this, please call Concordia Beverage Systems for assistance at 1-800-778-0990. 1. Place a cleaning rag under the nozzle, to catch any flavor drips.

  • Page 148: Peristaltic Pumps

    The color-coding scheme is consistent throughout the flavor delivery system and must be followed to prevent cross-contamination of syrup tubes. Chocolate Sauce Syrups Steam Input From Chocolate Purge Valve Milk Bowl Product Delivery Nozzle Concordia Xpress Technical Support Manual 2900-300B...

  • Page 149: Chocolate Rinse Purge Valve

    Milk Bowl Both the Xpress and Xpress 6 machines have a milk bowl. The milk bowl is a mixing chamber where steamed milk and flavors are fully mixed before flowing through the product delivery nozzle and into the customer’s cup.

  • Page 150: Replacing The Syrup Manifold

    6. Once the cycle completes, place the flavor tube nozzles on a clean towel, and then empty and rinse the container. 7. Refill the container with hot water as in step 2 above. 9-10 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 151 18. Reconnect the flavor tube nozzles to the appropriate bag-in-box flavors. 19. Prime the syrup system. See the Priming the Flavor Delivery System topic on page 9-12 for instructions. Concordia Xpress Technical Support Manual 9-11 2900-300B...

  • Page 152: Priming The Flavor Delivery System

    If you are purging a flavor tube because of an air bubble, continually press the appropriate flavor button until the air bubble passes. You will know when this happens because the flavor will splutter, and then run continuously and smoothly. 9-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 153: Section 10 :: Vending

    Section 10 :: Vending Vending Overview Replacing a Card Reader Installing a Vending Unit Removing a Vending Unit Troubleshooting...

  • Page 154: Vending Overview

    8. Re-attach the door handle to the front of the door assembly. 9. Re-attach the inside panel of the door assembly, using the screws previously removed. 10. Re-attach the right front door assembly on the machine. 10-2 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 155: Installing A Vending Unit

    3033-010B Installing a Vending Unit Installation of vending units is done by Concordia, prior to a customer receiving the machine. Existing units cannot be upgraded in the field by a technician. If a customer wishes to add vending to an existing machine, please contact Concordia Beverage Systems for assistance at 1-800- 778-0990.
  • Page 156 Section 10: Vending 3033-010B Page Intentionally Left Blank 10-4 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 157: Section 11 :: Cleaning And Maintenance

    Section 11 :: Cleaning and Maintenance Daily Maintenance Cleaning Timers Preventive Maintenance...

  • Page 158: Daily Maintenance

    Section 11: Cleaning and Maintenance 3033-011B Daily Maintenance In order to avoid mechanical failure and maintain cleanliness, the Xpress espresso machine must be cleaned and maintained on a daily basis. If the machine is not cleaned as indicated below, the machine will be disabled and the customer will not be able to pour drinks.

  • Page 159: Cleaning Timers

    REQUEST PM will be displayed on the message screen. A PM kit (PN 5000-038), containing all the required replacement parts and procedures, is available from Concordia Beverage Systems. Navigate to MISCELLANEOUS > RESET PM to reset the PM counter. Concordia Xpress Technical Support Manual...
  • Page 160 Section 11: Cleaning and Maintenance 3033-011B Page Intentionally Left Blank 11-4 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 161: Section 12 :: Concordia Procedures

    Section 12 :: Concordia Procedures Service Call Process Complete Call Protocol Service Call Checklist Parts Return Policy Parts Replenishment Form...

  • Page 162: Service Call Process

    Do not spread tools and parts around in the business.  Respect the customer’s business while you repair their machine.  Record current quantity on hand of Concordia cleaning products; recommend ordering or signing up for auto-shipment of cleaning products if account is low on supplies. ...

  • Page 163: Required Immediately For Call Closeout

     Closing a service call requires the following information: Time Started, Time Completed, and Service Codes for the repair. Complete Call Protocol On each service call, Concordia requires the entire machine be inspected to ensure continued operation. Machine Appearance ...

  • Page 164: Refrigeration Unit

    Triple extraction time of 23-30 seconds  Pour temperature of 175°F (79°C) ± 10°F (6°C ) Milk Pour  Latte temperature: 160°F (71°C) ± 5°F (3°C)  Cappuccino temperature: 155°F (68°C) ± 5°F (3°C) 12-4 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 165: Service Call Checklist

    MILK VALVE (Model 2500 s/i Only) □ Verify there is zero build-up in the milk valve, milk bowl, and nozzle. □ Verify plunger movement; lubricate with Superlube® pen. Customer Signature Date Technician Signature Date Concordia Xpress Technical Support Manual 12-5 2900-300B...

  • Page 166: Parts Return Policy

    Concordia will pay for shipping the part back to Concordia. The warranty for new parts from Concordia is for 90 days. This applies to both new machines and replacement parts. The warranty for a new machine is one year.

  • Page 167: Return Material Tag

    Each part must have a Return Material Tag filled out properly. If the tag is not complete, parts will not be replaced or credited. A 15% handling fee will be charged for any tags or forms not filled out completely on non-consignment returns. Concordia Xpress Technical Support Manual 12-7 2900-300B...

  • Page 168: Parts Replenishment Form

    Section 12: Concordia Procedures 3033-012B Parts Replenishment Form Concordia Beverage Systems provides a parts replenishment form for agents to submit. This form should be filled out weekly and submitted to Concordia Beverage Systems, detailing each part used during service calls over the previous week.

  • Page 169: Section 13 :: Customer Service And Training

    Section 13 :: Customer Service and Training Training the Customer Concordia Beverage System’s Value Added Service G.U.E.S.T.

  • Page 170: Training The Customer

    Section 13: Customer Service & Training 3033-013B Training the Customer Concordia requires complete customer training at the time of installation. Cleaning instructions must be reviewed during each service call. Customer Training Includes: 1. Using the User Guide. 2. Starting and resetting the machine.

  • Page 171: Cleaning

    Failure to order adequate cleaning product and to clean the machine can void the warranty. To order additional cleaning supplies or flavors, the customer needs to call or email Concordia Customer Service. To order by email, the customer should write to: Customer_service@concordiacoffee.com Order forms are available by writing to the email address above.

  • Page 172: Contacting Concordia For Assistance

    Section 13: Customer Service & Training 3033-013B Contacting Concordia for Assistance In the User Guide, review the location of the Concordia Beverage Systems customer service number (1-800-778-0990) and advise the customer to call Concordia with any questions about their new machine.

  • Page 173: Concordia Beverage Systems' Value-Added Service

    Technicians are the ambassadors of the companies they represent. As a Concordia technician, you will see Concordia customers to perform routine maintenance an average of 3-5 times per year; more than any other representative of Concordia.

  • Page 174: Value-Added Service

    You win because you can recommend more reliable equipment and make your job a more enjoyable. Your company wins because they reap the benefits of a solid reputation and potential new sales. 13-6 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 175: Greet The Customer

    Ask to speak to the person who requested service Greeting “Hi, I’m Alex with Awesome Service XYZ Company, is Bob here? He reported a problem with your Concordia espresso machine.” (going to get caller) “Hi Bob, (Hand out business card if you have one) I’m Alex with Awesome Service XYZ Company.

  • Page 176: Understand Your Customer

    These factors will help lead you to a path of discovery and machine repair. 13-8 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 177: Empathize With Your Customer

    Empathy helps build the relationship with your customer. It broadens the communication pipeline allowing you to understand their needs and get your message across. Now that you’ve got their attention, earn their trust and respect. Concordia Xpress Technical Support Manual 13-9 2900-300B...

  • Page 178: Solve The Problem

    Keeping the refrigeration compartment free of foreign objects  Changing water filter/softener cartridges at regular intervals  Simple lubrication points  Daily cleaning requirements Always end your conversation by thanking the customer for their business. 13-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 179: Section 14 :: Messages

    Section 14 :: Messages Troubleshooting Display Messages...

  • Page 180: Troubleshooting Display Messages

    Troubleshooting Display Messages Warning messages appear on the machine display. Other operational messages exist, which do not require action. If you see a message which is not included on this list and need assistance, please call Concordia Beverage Systems at 1-800-778-0990. DISPLAY...
  • Page 181 GRNDS BIN reset message. Bad connection between Check cable from front panel to CPU board and front panel. CPU board. FRONT PANEL FAIL Defective front panel Replace the front panel circuit (PCA). board assembly. Concordia Xpress Technical Support Manual 14-3 2900-300B...
  • Page 182 Verify the IR sensor is not affected REAR the IR sensor beam line. by ambient light. Verify milk level. NO MILK- Front milk count is 75 or Verify milk weight tray is properly FRONT lower. installed and calibrated. 14-4 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 183 Open sensor = 0.8°F (-17°C). See Section 15: Troubleshooting for detailed instructions. Close refrigeration unit door. REFR DOOR Door to the refrigeration Verify door seal is in good OPEN unit is open. condition. Concordia Xpress Technical Support Manual 14-5 2900-300B...
  • Page 184 See Section 15: Troubleshooting for STEAM TEMP detailed instructions. Call Concordia Beverage Systems Steam temperature setting for assistance. higher than STEAM HI setting. 1-800-778-0990 Relay failed in CLOSED Verify relay operation, replace if mode. necessary. 14-6 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 185 Failed heater elements. Check and replace if necessary. displayed Failed solid-state relay or Check and replace if necessary. fuse. Failed temperature limit Check and replace if necessary. switch. Failed lower steam probe. Verify probe assembly. Concordia Xpress Technical Support Manual 14-7 2900-300B...
  • Page 186 Verify steam temperature. Adjust CHECK high/low. Steam wand not as needed. STEAM WAND physically connected to Check wiring to steam wand. machine. MISSING ASW Install PCA expansion board (PN PCB not installed. 2612-060). 14-8 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 187 Low milk level in front milk Replenish milk supply. FRONT supply. REFILL Low milk level in lower milk Replenish milk supply. LOWER MILK supply. MILK CLEAN Milk system needs to be Clean milk system. cleaned. Concordia Xpress Technical Support Manual 14-9 2900-300B...
  • Page 188 Refer to vending documentation. See Section 15: Troubleshooting for detailed instructions. VENDING NOT Jamex payment controller READY interface failure. Call Concordia Beverage Systems for assistance. 1-800-778-0990 14-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 189: Section 15 :: Troubleshooting

    Section 15 :: Troubleshooting Troubleshooting Quick Reference Guide Troubleshooting Trees...

  • Page 190: Troubleshooting Quick Reference Guide

    Group motors do not run and both Replace blown fuse. Blown F19 fuse on the DC 38Vdc LEDs are lit NOTE power supply. : Use 5amp fuse only. on the DC power supply 15-2 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 191: Coffee System

    Gently smooth out flavor tube(s). flavor tubes and/or flavor Remove flavor tube, first, if box. necessary. Kink in flavor tube(s) Lift box and remove tube from Box resting on tube incorrect position; correctly position flavor tube. Concordia Xpress Technical Support Manual 15-3 2900-300B...

  • Page 192: Milk System

    Dirty or clogged product nozzle. during dispensing nozzle Check for dried milk or debris build- up in product nozzle. Too much or too Check air, steam, and air gate Air gate valve stuck little foam valves. 15-4 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 193: Troubleshooting Trees

    Card Swipe or Tap Not Authorized Display Says Not Configured No Display on Card Reader Front Panel Failed AC Voltage Error Check Clock Check Stats CPU Load Disp & Seq Error DC Board Failure Concordia Xpress Technical Support Manual 15-5 2900-300B...

  • Page 194: Brew System: Right Drive Timeout

    Replace roller bearings. evident? PN 2140-020 Reinstall and test. If sluggish operation persists, replace right drive motor. Replace the upper piston o-ring, run test drinks, and then run the milk and brew system clean processes. 15-6 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 195: Brew System: Invalid Stop L

    Clear the chamber functioning properly. displayed? walls of coffee debris. Remove any coffee debris on top of the gearbox, standoff, and spindle bar. Concordia Xpress Technical Support Manual 15-7 2900-300B...
  • Page 196 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-8 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 197: Brew System: Invalid Stop R

    Run several double bind. Check oblong Group espressos to verify bushings in the right initialized in 50 group is functioning seconds? drive assembly. properly. Replace the ring guide. PN 2140-020 Concordia Xpress Technical Support Manual 15-9 2900-300B...
  • Page 198 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 199: Brew System: Left Drive Timeout

    If the piston evident? continues to move slowly, replace the motor. Run the brew clean cycle, and then test machine operations. It’s possible the problem was a sticky lower piston that just needed some rinsing. Concordia Xpress Technical Support Manual 15-11 2900-300B...
  • Page 200 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 201: Grinder System: Out Of Beans

    Repair/replace Replace fuse and damaged Motor Fuse on retest grinder. If component. voltage AC drawer fuse blows again present? replace grinder and retest. Possible shorted grinder motor. Replace grinder. Concordia Xpress Technical Support Manual 15-13 2900-300B...
  • Page 202 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-14 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 203: Milk System: Overpouring Milk

    PN 2630-111 opens. Replace air gate Repair or replace and retest. damaged cables. Milk pour volume END PROCESS correct? Call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-15 2900-300B...
  • Page 204 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 205: Milk System: Cold Milk Pour

    END PROCESS Replace the air control more than temperature. correct? gate assembly. 2.5Vdc? Reset the pump control voltage using the potentiometer attached to the CPU. Concordia Xpress Technical Support Manual 15-17 2900-300B...
  • Page 206 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-18 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 207: Milk System: No Milk Pour

    2.5Vdc. Cover the top of the air vent stem with fingers and activate pump. Does Replace the air milk gate assembly. pour? PN 2712-009 Replace milk pump. PN 2340-112 Concordia Xpress Technical Support Manual 15-19 2900-300B...
  • Page 208 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-20 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 209: Milk System: Short Milk Pour

    2.50Vdc. Cover the top of the air vent stem with fingers and activate pump. Does Replace the air milk gate assembly. pour? PN 2712-009 Replace milk pump. PN 2340-112 Concordia Xpress Technical Support Manual 15-21 2900-300B...
  • Page 210 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-22 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 211: Refrigeration System: Temperature Above 40˚F

    REFR CURRENT. connections for Is current below cell or cells. board? burn marks. 10.4 amps? PN 2320-036 Replace harness Replace DC or backplane, board. JP3 housing. DC board Replace DC resistor R2 board. damaged? Concordia Xpress Technical Support Manual 15-23 2900-300B...
  • Page 212 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-24 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 213: Steam System: Steam Temperature High

    Replace relay. END PROCESS Relays PN 1312-031 Retest unit. Inspect harness for shorts. Replace CPU assembly. Retest unit for error. If error persists, call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-25 2900-300B...

  • Page 214: Steam System: Check Sensor Voltage

    Call Concordia Beverage Systems Inspect the DC board for assistance. closely for damaged 1-800-778-0990 components. Replace DC board assembly. PN 2630-034 CHECK Call Concordia SENSOR Beverage Systems VOLTAGE error for assistance. 1-800-778-0990 displayed? 15-26 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 215: Steam System: Check Steam Probes

    Verify the steam tank ground wire is secure. STEAM END PROCESS PROBES error displayed? Call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-27 2900-300B...

  • Page 216: Steam System: Check Steam Tank

    Replace valve. shorted? Retest. CHECK STEAM TANK END PROCESS error displayed? Reconnect fill tubing to tank and retest unit. CHECK Call Concordia STEAM TANK Beverage Systems error for assistance. 1-800-778-0990 displayed? END PROCESS 15-28 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 217: Steam System: Steam Temperature Low

    Retest for failure. Steam Clean or replace level probes level probes. clean? Retest for failure, Check input voltage to transformer. Replace as Call Concordia required. Beverage Systems for assistance. 1-800-778-0990 END PROCESS Concordia Xpress Technical Support Manual 15-29 2900-300B...

  • Page 218: Water System: Water Temperature Too High

    Power unit down Identify the source and allow tank to of heat in tank. cool. Replace Call Concordia probe and retest. Beverage Systems for assistance. 1-800-778-0990 Tank still END PROCESS overheating? Replace AC drawer. 15-30 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 219: Water System: Water Temperature Too Low

    Replace voltage connections to AC drawer. present? backplanes. Power unit down. Reconnect/repair/ Harness voltage at Check fuses for replace harness. element? blown fuse. Check element Replace resistance. AC drawer. Replace and retest. Concordia Xpress Technical Support Manual 15-31 2900-300B...
  • Page 220 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-32 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 221: Water System: Check Water Supply

    Call Concordia Beverage Systems for assistance. 1-800-778-0990 Locate break in Continuity wiring harness or present? connector, and repair. Check pins and connectors going to CPU for possible dislodged pin. Replace CPU as last resort. Concordia Xpress Technical Support Manual 15-33 2900-300B...
  • Page 222 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-34 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 223: Water System: Water Tank Limit Switch Open

    Possible shorted Call Concordia drinks and verify Unit relay. Replace on Beverage Systems the water functioning rear grinder plate. for assistance. temperature is correctly? PN 1312-031 1-800-778-0990 maintained. Temperature END PROCESS END PROCESS Concordia Xpress Technical Support Manual 15-35 2900-300B...
  • Page 224 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-36 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 225: Flavor System: Cross-Contamination Of Syrup Lines

    Remove manifold head from bowl, END PROCESS check poppets for damage, leaks etc. Poppet Repair or replace Correct valve manifold as syrup pours in failing? needed. drink? Call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-37 2900-300B...

  • Page 226: Flavor System: Too Much Flavor In Drink

    Flavor 3 = Vanilla Flavor 4 = Chai Flavor 5 = Sugar-Free Vanilla Flavor 6 = Hazelnut Exit to the software menu after making changes and run some test drinks. Test drink flavor END PROCESS 15-38 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 227: Flavor System: Not Enough Flavor In Drink

    OK. flavor. sticking. Repair and replace as needed. Retest. Navigate to FLAVOR Clean/repair/ TIMINGS and END PROCESS replace tubing or adjust flavor as fittings as needed. needed. Concordia Xpress Technical Support Manual 15-39 2900-300B...
  • Page 228 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-40 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 229: Flavor System: No Flavor In Drink

    END PROCESS syrup head for blockages. Replace tubing as needed. Replace tubing as Tubing needed. blockage? PN 2790-201 through PN 2790-206 Flavor pours during drink? Call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-41 2900-300B...
  • Page 230 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-42 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 231: Electrical System: Check Analog Board

    5Vdc F16 = 5Vdc present? F17 = 12Vdc F18 = 24Vdc PN 1342-005 Replace CPU assembly. Retest unit for error. Retest unit. Call Concordia Error Beverage Systems present? for assistance. 1-800-778-0990 END PROCESS Concordia Xpress Technical Support Manual 15-43 2900-300B...

  • Page 232: Electrical System: Incorrect Software For Touchpad

    Download correct software to match the current touchpad on the unit. Download any user setting via the command file. Perform keyboard test to verify touchpad and CPU match. END PROCESS 15-44 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 233 See the Milk Probable hardware Overpouring Software problem. Isolate troubleshooting current? pump power. tree for further assistance. Upgrade unit with correct upgrade kit. PN 2820-027 END PROCESS Concordia Xpress Technical Support Manual 15-45 2900-300B...

  • Page 234: Electrical System: Front Panel Failed

    Retest. Keyboard Replace touchpad test and retest. Front panel END PROCESS passed? Replace CPU assembly. Retest. Call Concordia Front Beverage Systems panel for assistance. passed? 1-800-778-0990 15-46 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 235: Electrical System: Check Clock

    Exit the PROGRAM menu and power the unit off for 10 seconds. Then power the unit back on. Verify CHECK CLOCK error is not present. CHECK Replace CPU CLOCK error assembly. present? END PROCESS Concordia Xpress Technical Support Manual 15-47 2900-300B...

  • Page 236: Electrical System: Check Stats

    10 seconds. Then power the unit back on. Verify CHECK STATS error is not present. Replace CPU CHECK assembly, and STATS error then reload message displayed? software. END PROCESS 15-48 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 237: Electrical System: Cpu Load Disp And Seq Error

    Replace CPU. message Retest unit displayed? functionality. Navigate to TEST ROUTINES and activate all options. Verify all systems work. Exit TEST ROUTINES and run several drinks and verify unit is functional. END PROCESS Concordia Xpress Technical Support Manual 15-49 2900-300B...
  • Page 238 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-50 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 239: Electrical System: Ac Voltage Error

    Beverage Systems element is not element element is not element relay? for assistance. shorted. shorted? shorted. shorted? 1-800-778-0990 Replace Replace Replace steam tank water tank shorted element. element. relay. PN 2650-019 PN 2650-008 Concordia Xpress Technical Support Manual 15-51 2900-300B...
  • Page 240 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-52 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 241: Electrical System: Dc Voltage Failure

    Inspect harness & LEFT DRIVE and RIGHT DRIVE and backplane for activate. activate. damage. Replace lower Replace lower Replace CPU END PROCESS piston motor. piston motor. assembly. PN 2130-013 PN 2130-013 PN 2630-111 Concordia Xpress Technical Support Manual 15-53 2900-300B...
  • Page 242 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-54 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 243: Vending System: Card Swipe Or Tap Not Authorized

    10,0. Blinking Recheck signal LED? strength for 10,0. Probable bad unit or poor or no signal. Call USA Technologies service line 1-888-561-4748 and select option 1. Call Concordia Beverage Systems for assistance. 1-800-778-0990 Concordia Xpress Technical Support Manual 15-55 2900-300B...

  • Page 244: Vending System: Not Configured

    Vending System: Not Configured Display Says NOT CONFIGURED Unplug vendor backpack from power source. Wait 10 seconds then repower vending unit. Error Replace G8 returned? processor. Run several drinks to verify functionality. END PROCESS 15-56 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 245: Vending System: No Display On Card Reader

    G8 processor and VMC. Replace G8 Display modem or VMC. present? Retest vending pack. 110Vac Check circuit present at breaker. wall? 12Vdc Replace power present from supply. DC supply? END PROCESS Concordia Xpress Technical Support Manual 15-57 2900-300B...
  • Page 246 Section 15: Troubleshooting 3033-015B Page Intentionally Left Blank 15-58 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 247: Section 16 :: Parts Lists & Diagrams

    Section 16 :: Parts Lists & Diagrams Recommended Tools List Parts Lists and Diagrams...

  • Page 248: Recommended Tools List

    Group Motor Removal Tool 4100-014 Small Pin Remover 4100-016 Consumables CONCORDIA PART NUMBER Heat sink compound 3900-003 Superlube pen 3100-002 Teflon tape – 1/4” & 1/2” 3300-013 Ty-Wrap (100) 1454-014 RTV silicone seal 3200-003 16-2 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 249: Parts Lists And Diagrams

    Grinder Assembly Grinder Adjustment Assembly Group Upper and Lower Piston Assembly Group Drive System Milk Pump Assembly Product Delivery Assembly Xpress 6 Product Delivery Assembly Xpress 0 Refrigeration Unit Cooling Assembly Chocolate Sauce Delivery System Syrup Delivery System Refrigeration Unit Cooling Assembly...

  • Page 250: Diagram 1: Machine Overview

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 1: Machine Overview PT# 2710-010 PT# 2320-036 MANUAL 16-4 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 251: Diagram 1, Parts List: Machine Overview

    ASSY – PRODUCT DELIVERY 2790-198 Fuses and Relays: not shown Available RELAY-SOLID STATE 45 AMP 1312-034 FUSE- 5 AMP- TR5- DC SPLY 1342-005 FUSE- 5 AMP 5X20MM AC LOW 1342-006 FUSE 20A CERAMIC TIME DLY 1342-010 Concordia Xpress Technical Support Manual 16-5 2900-300B...

  • Page 252: Diagram 2: Grounds Bin Door, Refrigerator Door With Hot Water Button Assembly

    PT# 1500-163 X0 only PT# 1500-309 X6 only X6 only X6 only X6 only ASSY FRG DR W/STM XPRESS MANUAL STEAM WAND PT# 2510-194 X0 only ASSY FRG DR XPRESS 6 PT# 2510-179 ASSY FRG DR XPRESS 0 PT# 2510-193...

  • Page 253: Diagram 2, Parts List: Refrigerator Door With Hot Water Button Assembly

    LBL DREGS DOOR 1500-164 PH PHIL MS SS 6-32 X 1/8 1410-194 ASSY RFR DR W/HOT WTR SW (X6 2510-179 only) ASSY FRG DR W/STM XPRESS (X0 2510-194 only) SW HOT WATER I6 (X6 only) 1311-025 STRIKE FASTEX 1456-024 LBL RFR DOOR 2.5K (X0 only)

  • Page 254: Diagram 3: Refrigerator Door With Steam Wand Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 3: Refrigerator Door with Steam Wand Assembly 16-8 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 255: Diagram 3, Parts List: Refrigerator Door With Steam Wand Assembly

    ASSY RFR DR W/STEAM WAND 2510-194 STRIKE FASTEX 1456-024 ASSY-DOOR INTERIOR-2500 2510-004 PH PHIL SS 6-32 X 3/16 1410-094 FH PH MS SS UCT 4-40x1/4 1410-087 ASSY KNOB STEAM WAND 2790-106 ASSY STM WAND 2500 2790-107 Concordia Xpress Technical Support Manual 16-9 2900-300B...

  • Page 256: Diagram 4: Front Panel

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 4: Front Panel PT# 1420-002 16-10 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 257: Diagram 4, Parts List: Front Panel

    DISPLAY BLUE 2640-081 PH PHIL MS SS 4-40X ¼ 1410-065 CBL-FRONT DOOR 2670-121 PH PHIL NYLON 6-32 X 3/8 1410-092 KIT – FRONT PANEL SLIDES 98430 XPRESS 6 TOUCHPAD 2640-078 XPRESS 0 TOUCHPAD 2640-089 Concordia Xpress Technical Support Manual 16-11 2900-300B...

  • Page 258: Diagram 5: Top Panel

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 5: Top Panel 16-12 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 259: Diagram 5, Parts List: Top Panel

    PNL TOP DOUBLE CCS X6 1110-852-00 PNL TOP FAN COVER CCS X6 1110-861-00 PLUG HOLE COVER .562 1240-045 GUARD FAN THRU HOLE 1330-007 FH PHIL SS 6-32 X 2 1410-134 EXHAUST FAN- 24VDC 2510-044 Concordia Xpress Technical Support Manual 16-13 2900-300B...

  • Page 260: Diagram 6: Grinder Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 6: Grinder Assembly 16-14 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 261: Diagram 6, Parts List: Grinder Assembly

    2510-027 PH PHIL MS SS 4-40x1/4 1410-065 STUD BALL MOUNT 1452-004 NUT HEX SS M6 2120-054 WASH LOCK LWR PISTON M6SS 2120-056 NUT HEX SS M8 1420-029 WSHR SPLIT LOCK SS M8 1430-024 Concordia Xpress Technical Support Manual 16-15 2900-300B...

  • Page 262: Diagram 7: Grinder Adjustment Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 7: Grinder Adjustment Assembly PT# 2510-219 PT# 1500-305 1500-306 16-16 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 263: Diagram 7, Parts List: Grinder Adjustment Assembly

    PNL GRIND FRONT CN 1110-553 PH PHIL MS SS 4-40x1/4 1410-065 ASSY- SWITCH- MAG- 4 2510-027 PH PHIL MS SS 6-32 X 1/4 1410-007 CABLE MENU SWITCH 2670-243 LBL GRNDR ADJ VRT XPRESS 1500-305 Concordia Xpress Technical Support Manual 16-17 2900-300B...

  • Page 264: Diagram 8: Group Upper And Lower Piston Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 8: Group Upper and Lower Piston Assembly 1260-093 PT# 1260-093 16-18 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 265: Diagram 8, Parts List: Group Upper And Lower Piston Assembly

    ASSY PISTON LOWER SGL 2130-023 CARRIER- SIEVE- RR GROUP 2140-037 E-CLIP- LOWER PISTON 2140-048 KIT- LWR PISTON SIEVE 98436 O-RING-LWR PISTON-CARRIER 2140-023 SEAL PISTON 2.5K 1260-093 RING- WIPING- LWR PISTON 1260-091 HOLDER- LWR PISTON SIEVE 2140-059 Concordia Xpress Technical Support Manual 16-19 2900-300B...

  • Page 266: Diagram 9: Group Drive System

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 9: Group Drive System 16-20 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 267: Diagram 9, Parts List: Group Drive System

    BOLT- DISTANCE- BRASS 2140-032 PLATE- FASTENING 2140-034 DRIVE DUAL W/SPINDLE & CAST 2130-014 SCREW- ALLEN- M6X65 2140-004 PIN- M- AMP- MED 1353-009 HSG- AMP- 3PIN M- WHT 1353-003 HSG- AMP- 4PIN M- WHT 1353-004 Concordia Xpress Technical Support Manual 16-21 2900-300B...

  • Page 268: Diagram 10: Milk Pump Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 10: Milk Pump Assembly PT# 1232-140 PT# 1250-019 PT# 1430-030 PT# 1250-016 16-22 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 269: Diagram 10: Parts List, Milk Pump Assembly

    PH PHIL MS SS 4-40 X ¼ 1410-065 PH PHIL MS SS 8-32 X ½ 1410-101 TRIM 3/16 EDGE RUBBER BLK 1240-062 NOT SHOWN 1430-030 WASH NYL.443IDX.750X1/8 NOT SHOWN 1232-140 CONN BARB 1/8 X LUER MALE Concordia Xpress Technical Support Manual 16-23 2900-300B...

  • Page 270: Diagram 11: Product Delivery Assembly, Xpress 6

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 11: Product Delivery Assembly, Xpress 16-24 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 271 1260-114 PH PHIL SS 8-32 X 1-1/4 1410-075 ASSY- NOZZLE- HOT WATER 2790-089 ASSY- NOZZLE- ESPRESSO 2790-090 ASSY SYRUP MANIFOLD X6 2790-197 ASSY ADAPTER MLK BOWL X6 2790-208 ASSY PRODUCT NOZZLE X6 2790-209 Concordia Xpress Technical Support Manual 16-25 2900-300B...
  • Page 272 Section 16: Parts Lists & Diagrams 3033-016B Diagram 12: Product Delivery Assembly, Xpress 16-26 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 273 Number ASSY ADAPTER MLK BOWL X6 2790-208 NOZZLE MILK DEL XPRESS 1120-356 O RING- MILK VALVE-NOZZLE 1260-032 BOWL MILK MAN X6 1120-352 O-RING -130 MILK BOWL X6 1260-114 CVR BOWL MILK XO 1120-366 Concordia Xpress Technical Support Manual 16-27 2900-300B...

  • Page 274: Diagram 13: Refrigeration Unit Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 13: Refrigeration Unit Assembly PT# 2310-043 PT# 2340-118 PT# 2340-118 PT# 98583 16-28 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 275: Diagram 13, Parts List: Refrigeration Unit Assembly

    1210-046 ELBOW ¼ NPT X 3/16 BARB 1232-135 ASSY MILK DBL PICK-UP X6 2340-118 ASSY- INTERNAL FAN- 2310-031 ASSY- PROBE- TMP- REFR- 2660-031 ASSY- DEFLECTOR- INT FRIDGE 2310-033 ASSY WEIGHT TRAY SMALL 2310-027 Concordia Xpress Technical Support Manual 16-29 2900-300B...

  • Page 276: Diagram 14: Chocolate Sauce Delivery System

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 14: Chocolate Sauce Delivery System 16-30 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 277 CONN KENT 1/4 BARB F 1232-119 CONN KENT 1/4 BARB M 1232-120 TUBE .187X.375 NORPRENE 1250-023 CONN SYRUP BAG SCHOLLE 1232-104 ASSY PRODUCT DELIVERY X6 2790-198 TUBE PFA 5/32 ID X 1/4 OD 1250-006 Concordia Xpress Technical Support Manual 16-31 2900-300B...

  • Page 278: Diagram 15: Syrup Delivery System

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 15: Syrup Delivery System 16-32 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 279: Diagram 15, Parts List: Syrup Delivery System

    BRKT SEAL FAN RFR X6 1110-851 FH PHIL #10 X 5/8 FAN MNT 1410-184 FAN EXTERNAL FRIDGE 2.5K 1332-004 HSG AMP 2PIN M WHT 1353-002 PIN M AMP MED 1353-009 FILTER AIR X6 1120-362 Concordia Xpress Technical Support Manual 16-33 2900-300B...

  • Page 280: Diagram 16: Refrigeration Unit Cooling Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram Refrigeration Unit Cooling Assembly PT# 1410-184 16-34 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 281: Diagram 16, Parts List: Refrigeration Unit Cooling Assembly

    BRKT SEAL FAN RFR X6 1110-851 FH PHIL #10 X 5/8 FAN MNT 1410-184 FAN EXTERNAL FRIDGE 2.5K 1332-004 HSG AMP 2PIN M WHT 1353-002 PIN M AMP MED 1353-009 FILTER AIR X6 1120-362 Concordia Xpress Technical Support Manual 16-35 2900-300B...

  • Page 282: Diagram 17: Steam Tank, Front

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 17: Steam Tank, Front PT# 2730-047 16-36 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 283: Diagram 17, Parts List: Steam Tank, Front

    CONN BRASS 1/4M X 1/4M 1231-019 PLUG BRASS 1/8M 1231-024 NOT SHOWN 98525 KIT KIPVLV STEAM 30PSI VALVE STEAM HIGH TEMP 1210-017 CONN 1/8M X 3/8T 1231-059 PH PHIL MS SS 6-32 X 1/4 1410-007 Concordia Xpress Technical Support Manual 16-37 2900-300B...

  • Page 284: Diagram 18: Steam Tank, Rear

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 18: Steam Tank, Rear 16-38 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 285: Diagram 18, Parts List: Steam Tank, Rear

    ELBOW BRASS 1/8M X 1/8T 1231-015 O RING- HTG ELEMENT 1260-054 ELEMENT HTG 3KW CHROMALOX 2650-019 ASSY PRESS RLV VLV 2730-040 VLV PRESS RLF STM 30PSI 1210-044 ELBOW 1/2F X 3/8M 1231-093 CONN 1/2M X 1/4T 1231-045 Concordia Xpress Technical Support Manual 16-39 2900-300B...

  • Page 286: Diagram 19: Water Pump And Motor

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 19: Water Pump and Motor 16-40 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 287: Diagram 19, Parts List: Water Pump And Motor

    ASSY WTR PMP MTR 2.5K 2400-023 MOUNT ISOL M/M M4X0.7 1450-021 WASHER FLAT SS #10 1430-002 NUT NYLOC M4 1420-039 PUMP WATER PAO74Z 30-GPH 2710-013 ASSY- EXPANSION VLV 2790-072 CONN 3/8M X 1/4T 1231-087 Concordia Xpress Technical Support Manual 16-41 2900-300B...

  • Page 288: Diagram 20: Hot Water Tank

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 20: Hot Water Tank PT# 1140-014 PT# 2660-057 16-42 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 289: Diagram 20, Parts List: Hot Water Tank

    1231-053 CONN BRASS 1/8F NOT SHOWN 1210-024 VALVE SINGLE STATION NOT SHOWN 1232-097 ELBOW 1/8NPT X X1/4T PH PHIL SS 8-32 X 1-1/4 1410-075 COVER WATER TANK 2000/995 1140-014 FLOWMETER GICAR PLASTIC 2660-057 Concordia Xpress Technical Support Manual 16-43 2900-300B...

  • Page 290: Diagram 21: Water/Steam Gauge/ Air Valve Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 21: Water/Steam Gauge/ Air Valve Assembly FRONT REAR PT# 2510-180 9 PT# 1245-014 LAVENDER NEEDLE 8 PT# 1245-013 RED NEEDLE PT# 2790-044 PT# 2790-038 16-44 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 291: Diagram 21: Parts List: Water/Steam Gauge/Air Valve Assembly

    CONN BRASS 1/8F X 1/8T 1231-048 DISK ORIFICE 5/16X.01X.01 1110-383 ORIFICE SPACER 1120-229 BRKT GAUGES AND AIR X6 1110-839 ELBOW BRASS 1/8F X 1/8T 1231-043 VENT AIR 25GA ¼ RED 1245-013 VENT AIR 30GA ¼ LAV 1245-014 Concordia Xpress Technical Support Manual 16-45 2900-300B...

  • Page 292: Diagram 22, Parts List: Drain Valve Bridge Web Assembly

    Section 16: Parts Lists & Diagrams 3033-016B Diagram 22, Parts List: Drain Valve Bridge Web Assembly PT# 1231-057 16-46 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 293: Diagram 22, Parts List: Drain Valve Bridge Web Assembly

    VALVE BALL 1/8 FPT 1210-031 CONN BRASS 1/8M X 1/4T 1231-008 ELBOW BRASS 1/8M X 1/8T 1231-015 ELBOW BRASS 1/8M X 1/4T 1231-016 CONN BRASS 1/8M X 1/8M 1231-020 ELBOW 45 DEG STR-1/8 1231-057 Concordia Xpress Technical Support Manual 16-47 2900-300B...
  • Page 294 Section 16: Parts Lists & Diagrams 3033-016B Page Intentionally Left Blank 16-48 Concordia Xpress Technical Support Manual 2900-300B...

  • Page 295: Section 17 :: Index

    Section 17 :: Index...
  • Page 296 DC Jumper Plug ..2-4, 3-16 Captive Water Purge System . 5- DC Power Supply... 2-4, 3-11, 3- 14, 3-15, 3-16, 3-18, 15-2 Card Reader Default Settings ....4-13 Replacing ....... 10-2 Diagram Ceramic Fuses .... 3-3, 3-19 17-2 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 297 14, 3-15 Grinder Panel ......3-3 Electrical Settings ....2-4 Grinders ......1-3, 6-3 EMPTY GRNDS BIN ..14-3 Removal ......6-6 Espresso ......4-15 GROUNDS BIN OUT ..14-4 Group ......3-3, 3-18 Concordia Xpress Technical Support Manual 17-3 2900-300B...
  • Page 298 Lower AC Board . 3-3, 3-15, 3-16 Chocolate Sauce Delivery Lower Piston ......6-5 System ..... 16-31 Machine Drain Valve Bridge Web Resetting ......13-2 Assembly ....16-47 Starting......13-2 Front Panel ....16-11 Machine Dimensions .... 2-3 17-4 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 299 Starting The Machine ..2-8 Site Requirements ....2-2 Power Supply Software Flavor System ....1-5 Accessing ....... 13-3 Pressure Gauge ....5-13 Accessing A Sub-Category 4- Preventive Maintenance ..11-3 Probe Categories ......4-2 Concordia Xpress Technical Support Manual 17-5 2900-300B...
  • Page 300 Total Drink Counts ....4-2 Touch Pad ......1-3 Steam Temperature Low .. 15- Train The Customer ..13-10 Transducer ..3-3, 3-18, 5-12 Too Much Flavor In Drink . 15- Transformer ....2-4, 3-11 17-6 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 301 WATER TEMP HI ....14-7 Steam...... 5-14, 7-7 WATER TEMP LO ....14-8 Steam And Vaccum ..8-4 Water Valve ......5-5 Steam Tank Fill ....5-12 Water Volume ....... 4-2 Vacuum Break ....8-4 Concordia Xpress Technical Support Manual 17-7 2900-300B...
  • Page 302 Section 17: Index 3033-017B Page Intentionally Left Blank 17-8 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 303 Section 18 :: Service Bulletins...
  • Page 304 Section 18: Service Bulletins 3033-018B Table of Contents – Service Bulletins Section 18 :: Service Bulletins ..................18-1 Table of Contents – Service Bulletins ..........18-2 Service Bulletins ................18-3 18-2 Concordia Xpress Technical Support Manual 2900-300B...
  • Page 305 Section 18: Service Bulletins 3033-018B Service Bulletins Concordia Xpress Technical Support Manual 18-3 2900-300B...
  • Page 306 Section 18: Service Bulletins 3033-018B Page Intentionally Left Blank 18-4 Concordia Xpress Technical Support Manual 2900-300B...

Table of Contents

Save PDF
