Checks and inspections
Dashboard
Diagnosis
Changing the CODE
If you know the code, just enter it and then a new code that will be automatically stored in the memory.
If the vehicle is new, the user code is: 00000
Resetting the CODE
This function is used to set a new code when the old one is not available; in this case, at least two of
the programmed keys have to be inserted in the ignition lock.
After the first key has been inserted, the second one is requested with the following message:
INSERT KEY II
If the second key is not inserted within 20 seconds, the operation is finished.
After recognising the second key, the new code is required with the message:

ENTER NEW CODE

Once the operation is finished, the instrument panel goes back to the SET-UP menu.
DIAGNOSIS
Access to this menu (diagnosis functions), for the technical service only, after requesting a service code.
It will read: ENTER THE SERVICE CODE the code is: 28315
The functions in this menu are
•
Exit
•
ECU errors
•
Instrument Panel Errors
•
Delete errors
•
Reset Service
•
Update
•
Change Keys
ECU ERRORS
The instrument panel receives only the current errors from the control unit.
Description Error code
Throttle Valve Error DC V DC ECU 10
Throttle Valve Error DC Gnd ECU 11
Engine Temperature Error DC V DC ECU 14
