Specifications - Sony KV-32LS65AUS Instruction Manual

Specifications

TV system:
B
Colour system:
PAL
SECAM, NTSC 3.58, 4.43 (only Video
In)
Channel Coverage:
VHF: C00-C05, C05A, C06-C09, C09A,
C10-C12
UHF: C20-C69
CABLE: S02-S44
Picture Tube:
Flat Display FD Trinitron WIDE:
32" (approx. 82 cm. measured
diagonally)
Rear Terminals
1/ 1
21-pin Scart connector
including audio/video
input, YUV input, TV
audio/video output.
2/ 2
21-pin Scart connector
including audio / video
input, YUV input,
monitor audio/video
output.
3 3
/ 21-pin Scart connector
S
including audio / video
input, S video input,
selectable audio / video
output.
audio outputs (Left/
Right) - phono jacks
Design and specifications are subject to
change without notice.
Ecological Paper - Totally Chlorine Free
Side Terminals
4
S Video input – 4 pin DIN
S
4
video input – phono jack
4
audio input – phono jacks
headphones jack
Sound Output:
2 x 20 W (music power)
2 x 10 W (RMS)
Power Consumption:
130 W
Standby Power Consumption:
0.3 W
Dimensions (w x h x d) :
approx. 892 x 565 x 584 mm.
Weight:
approx. 62.2 Kg.
Accessories supplied:
1 Remote Control (RM-934)
2 Batteries (IEC designated)
1 Scart adaptor
2 Scart cables
Other features:
• 100 Hz picture, Digital Plus.
• Teletext, Fastext, TOPtext (250 page TEXT
memory).
• Sleep Timer.
• Dolby Virtual.
• BBE.
• PIP.
• Auto Format.
Additional Information
EN
21
