OPTIONAL ACCESSORIES
CASTER KIT
P/N 430291
To improve maneuverability
on hard paved surfaces.
HOLD DOWN KIT
P/N 430299
For use on truck or trailer to
provide quick hold down for
your QB.
Operator Owner's Manual
3
E ngine: HP
E ngine:Ty pe
E ngine: Fuel c ap.
E ngine: Oil Cap.
W eight : Unit
W eight : S hipping
E ngine W eight:
UNIT SIZE: OVERALL LENGTH: 51.75"(1.31m) OVERALL WIDTH 28.5" (0.72m)
Part No. 430316
T h a n k Yo u f o r S e l e c t i n g
The Powerful QUIET BLOW
Patent Pending
For Models:
QB884H, QB1004, QB1104H

Specifications

Q B 884H
8.0 HP (5.97 k W )
HO NDA OH V
6.4 qt. (6.1 L)
1.16 qt. (1.1 L)
136 # (61.7 K g)
155 # (70.3 K q)
52.0 # (23. 6 K g)
Page 1 of 12
BLOWER
®
Q B 1004
10.0H P (7. 45k W )
11.0H P (8. 2k W )
B & S INTE K I/C
HO NDA OH V
4.0 qt. (3.8 L)
7.4 qt. ( 7.0 L)
0.875 qt.(0.8L)
1.2 qt.(1.13L)
136 # (61.7 K g)
152 # (68.9 K g)
155 # (70.3 K q)
169 # (76.7 K g)
52.0 #(23.6 K g)
68.4 #(31.0 K g)
OVERALL HEIGHT
Q B 1104H
39" (0.99m)
Form No. F083100A
