Using Winplot And Accumark - Gerber Technology GERBERplotter MP Series User Manual

g) In the Type list, select the GERBERplotter MP Series.
h) In the Server or Plotter list, select the plotter by its IP address and port number. If there is only one plotter con-
nected, then the default selection appears.
i) Click Apply, and then click OK to save your changes. WinPlot and AccuMark can now use the GERBERplotter
MP Series.
Reboot the computer.
6

4.4 Using WinPlot and AccuMark

To use the GERBERplotter MP Series with WinPlot or AccuMark after you install the update:
If it is not automatically running, open the Server Manager software.
1
If it is not automatically running, open the User Manager software.
2
Minimize both applications if you want.
3
Open the WinPlot or AccuMark software.
4
Work in WinPlot or AccuMark as usual with User Manager and Server Manager also
5
running.
GERBERplotter MP Series User Manual
61
