Parts List - Quietside QVM 9-090W1-NG Manual

Models : QVM9-090/125/150W1-NG
No Part Code
1 C21701155A BBR15012041
C21701221A BBR15012042
2 C21701340A BBK05011024
C21701341A BBK05011025
3 C21750164A BH2505188A
4 C20109029B BH2505012A
5 C21606016B BH2423034A
6 C21701216A BH2505055A
7 C21701217A BH2505062A
8 C22203009A BH1419007A
9 C21605023A BH2405002A
C21601042A BH2405001A
10 C21014139E NACR1GS20602 Main Controller
11 C22601008A BH3101003A
C22602020A BH3102010A
12 C21708271A BH2507155A
C21708274A BH2507156A
C21708311A BH2507157A
13 C21213011A BH1409002A
14 C21708267A BH2507152A
15 C20501022A BH1101014A
16 C20313022A BH0902015A
17 C21708253B BH2507087A
18 C21708275A BH2507154A
19 C20301006D BH2507004A
20 C21708268A BH2507143A
21 C20901011B BH1301010A
22 C21708255B BH2507097A
23 C20307017A BH0905006A
24 C21899001C BH2501224A
25 C21708261A BH2507081A
26 C40306019B BBXCC087008
C40306022B BBXCC087009
27 C21707120C BH2501200A
C21707123C BH2501203A
C21707199B BH2501204A
28 C21707114B BH2501170A
C21707115B BH2501171A
C21707146B BH2501172A
29 C21750162A BH2501221A
C21750168A BH2501220A
30 C21707116B BH2501114A
C21707118B BH2501116A
C21707197A BH2501118A
31 C21605026A BH2405006A
C21605028A BH2405007A
C21605040A BH2405008A
32 C40306016A BBXCC088001
C40306018A BBXCC088002
C40306024A BBXCC088003
33 C21002008A BH1401007A
34 C20701079A BH1201004A
35 C21002016A BH1401004A
36
QVM 9
Series

Parts List

Part Name
Front Cover
〃
Cabinet
〃
Base Bracket
Flue Exhaust
Flue Exhaust Packing
Combustion Air Intake
Combustion Air Intake Plate
High Limit Fuse
Adiabatic Plate
〃
Expansion Tank
〃
Heat Exchanger Inlet Pipe
〃
〃
Heating Flow Sensor
Air Vent Outlet Pipe
Circulation Pump Assembly
3-Way Valve
Heating Supply Connection
Air Vent Outlet Connection
Heating Air Vent
Air Vent Inlet Pipe
Heating Strainer
Heating Return Connection
Pressure Relief Valve
Siphon
Heating Outlet Pipe
Fan Assembly
Fan Assembly
Orifice
〃
〃
Mixing Chamber Assembly
〃
〃
Mixing Chamber Bracket
〃
Nozzle
〃
〃
Mixing Chamber Packing
〃
〃
Burner Assembly
〃
〃
High Limit Sensor
Ignition Transformer
High Limit Sensor
Flame Observation Port
40
Q'ty Material
1 SCP1 QVM9-090/125W1
1 SCP1 QVM9-150W1
1 SCP1 QVM9-090/125W1, 0.8T
1 SCP1 QVM9-150W1, 0.8T
2 SBHG1 All QVM9
1 STS All QVM9
1 EPDM All QVM9
1 PP All QVM9
1 PP All QVM9
1 All QVM9, Fuse Type
1 AL+CERAMIC QVM9-090/125W1, 2T
1 AL+CERAMIC QVM9-150W1, 2T
1 All QVM9, KDC-206-3M V1.4
1 QVM9-090/125W1
1 QVM9-150W1
1 C1220T QVM9-090W1
1 C1220T QVM9-125W1
1 C1220T QVM9-150W1
1 NYLON 66 All QVM9, φ20
1 C1220T All QVM9
1 All QVM9, CS-0125V, 115V/60Hz
1 All QVM9, A3-18-223A, 115V/50/60Hz
1 C3712 All QVM9
1 C3712 All QVM9
1 All QVM9
1 C1220T All QVM9
1 All QVM9
1 C3712 All QVM9
1 All QVM9
1 PE All QVM9
1 C1220T All QVM9
1 AL QVM9-125/150W1, Without Air Filter
1 AL QVM9-090W1, Including Air Filter
1 STS QVM9-090W1, LNG, φ27.4
1 STS QVM9-125W1, LNG, φ29.5
1 STS QVM9-150W1, LNG, φ28.5
1 ALDC QVM9-090W1
1 ALDC QVM9-125W1
1 ALDC QVM9-150W1
1 SBHG1 QVM9-090/125W1
1 SBHG1 QVM9-150W1
1 C3712 QVM9-090W1, LNG, φ5.95
1 C3712 QVM9-125W1, LNG, φ6.60
1 C3712 QVM9-150W1, LNG, φ6.30
1 CERAMIC QVM9-090W1, 5T
1 CERAMIC QVM9-125W1, 5T
1 CERAMIC QVM9-150W1, 5T
1 Metal Fiber QVM9-090W1, 150 X 100
1 Metal Fiber QVM9-125W1, 200 X 100
1 Metal Fiber QVM9-150W1, 200 X 133
1 All QVM9, MS-1P, Manual, Bi-Metal Type
1 All QVM9, DK-304, 115V/50/60Hz
1 All QVM9, MS-1P, Automatic, Bi-Metal Type
1 MICA All QVM9
(UNIT : mm)
Remarks
