- Page 1 REDBACK RB4 5KVA MANUAL...
- Page 2 REDBACK QUICK SETUP GUIDE Oil/ Service/ Filter access panel Using the screwdriver provided loosen 2 screws open oil / service /air filter access panel. Unscrew filler remove. Using container provided fill your generator up with 450ml 10W30 oil. Refit filler...
-
Page 3: Table Of Contents
CONTENTS KNOW YOUR REDBACK………………………………………………..2 INTRODUCTION…………………………… ……………………………3 SAFETY INSTRUCTIONS …… ………………………………………….3 ELECTRICAL SAFETY ……………………… ……………………………3 USING AN EXTENSION CABLE ……………………… ………………..4 SAFETY WARNINGS………………..………………………………….4 …………………………….6 PREVENTION OF ELECTROCUTION AND FIRE BEFORE USING YOUR GENERATOR……………..……………………9 ……………………………..………………………..9 CHECK THE OI LEVEL …...10 CHECK THE BATTERY CONNECTION............. -
Page 4: Know Your Redback
KNOW YOUR REDBACK Easy Roll Wheels 1.Fuel Cap / Fuel Sediment Tray 7.Oil / Service/ Filter 2.Spark Plug Access Panel Access Panel 3.Control Panel 8. Fuel Tap 4.Fast Recoil Start Cable 9.Battery Access Panel 5.Sturdy Rubber Feet CONTROL PANEL 1. Digital Display 2. -
Page 5: Introduction
Failure to do so could result in i n j u r i n g yourself or damaging your generator. SAFETY INSTRUCTIONS WARNING! When using your REDBACK Generator, basic safety precautions, including the following, should always be followed to reduce the risk of electric shock, fire, personal injury and material damage. -
Page 6: Using An Extension Cable
Ensure you read the complete manual before operating your REDBACK Generator with due care. Keep this manual in a safe place so it is available at all times. If you give your REDBACK Generator to any other person/s, ensure you give them this manual as well. - Page 7 • Do not a dusty or sandy environment. Doing say cause sand and dust to sucked up into the REDBACK Generator • Keep away from rotating parts while the generator is running. • The generator is potential source of electrical shocks when...
-
Page 8: Prevention Of Electrocution And Fire
The Redback must could result in fire or electrocution. be repaired by an authorized Removal of casing could expose service agent. Do not operate electrically charged components the generator with no case. - Page 9 gases, or from electrical fire extinguisher certified spark. to handle fuel fires. Sparks, fire or hot objects. Cigarettes, sparks, fires, add fuel tank in well other hot objects cause ventilated area. Make fuel fuel vapors ignite. sure there are sources ignition near generator.
- Page 10 HAZARD WHAT COULD HAPPEN PREVENTION Operation of the sources energy include Review understand generator in careless potential for injury. the operating manner. Unsafe operation or Instructions and warnings Maintenance your this manual, become generator could familiar with the lead serious injury operation controls...
-
Page 11: Before Using Your Generator
BEFORE USING YOUR GENERATOR CAUTION! Ensure your REDBACK Generator is on a flat, solid surface. DO NOT use on a sandy or dusty surface. If using in a generator box it must be appropriately ventilated. CHECK LEVEL... -
Page 12: Checkthebatteryconnection
CAUTION! Operating your REDBACK Generator with low oil may cause damage. The oil alert system will shut down the REDBACK generator automatically before the oil levels fall under the safety line. Ensuring oil is full will prevent unexpected stoppage. CHECKTHEBATTERYCONNECTION... -
Page 13: Check The Fuel Level
WARNING! Petrol can explode under certain conditions. Please keep well ventilated whilst refueling your REDBACK generator. DO NOT add petrol while your generator is running. Be careful not to spill petrol. If there is an overflow, ensure that all spilt petrol evaporates before starting your REDBACK Generator. -
Page 14: Starting Your Generator
’Quick Setup Guide’. 2. Ensure the fuel in the ’on’ position. NOTE: Switch the fuel tap to the “off” position when the REDBACK Generator is not in use There are ways to start your REDBACK Generator, key start, easy recoil pull start and remote start. - Page 15 CAUTION! Do not let the easy coil starter cable recoil freely. Recoil the cable slowly. Ensure you hold your REDBACK Generator tightly when pulling the easy coil starter cable to prevent your generator tilting over. Remote switch ‘on ‘position NOTE: The remote start overrides the key start function.
-
Page 16: Using Your Generator
Failure to do so may cause feedback to the power line and may cause injury to utility workers or other persons. Failure to do so may cause the REDBACK Generator to explode, burn, cause a fire or cause injury. -
Page 17: Using The Ac Power
14v you must immediately disconnect the battery. Failure to do so can result in overcharge and may cause fire or explosion. Connect the alligator clips first and then insert the ‘T’ plug into your REDBACK Inventor Generator. If charging a car battery, ensure the battery is disconnected from your car. DO NOT starts your car while the charging cable is connected. -
Page 18: Digital Display
If the REDBACK Generator overloads short circuits, the digital display will show ’over’. If an overload occurs power will be produced. If your REDBACK Generator overloads, first disconnect your equipment and Check the equipment is faulty. nothing is faulty, check... -
Page 19: Switching Off Your Generator
SWITCHING YOUR GENERATOR there an emergency, shut down your REDBACK Generator by turning the key to the 'off’ position. If you started your REDBACK Generator using the remote control, you can turn your generator off quickly by using the remote switch the CONTROL PANEL. -
Page 20: Maintenance
REDBACK service agent. When you require your generator to be serviced, you must contact the retailer you purchased your REDBACK from. They will assign you an approved service agent. By following the maintenance schedule provided, it will ensure a long-life span of your REDBACK generator and keep it working to peak performance. -
Page 21: Changing The Oil
Tilt your REDBACK Generator forward pour the oil into suitable container. Using the oil container provided, fill the REDBACK Generator with 450mI of 10W30 oil. Unscrew and remove the oil discharge pipe. Refit the oil filler cap and tighten finger tight. -
Page 22: Air Filter Maintenance
AIR FILTER MAINTENANCE dirty air filter can block air flow. In order prevent malfunction, ensure you carry out frequent maintenance. WARNING! DO NOT use petrol or low flash point solvents to clean the generator as they are flammable and explosive under certain conditions. Oil/Service/ Air Filter access panel Filter cartridge Using the screwdriver provided... -
Page 23: Spark Plug Maintenance
SPARK PLUG MAINTENANCE Spark Plug Access Panel Ignition Lead Using the screwdriver provided, loosen the screw and open the spark plug assess panel. Remove ignition lead. Using the spark plug socket, unscrew and remove the spark plug. Inspect spark plug. If there damage, replace with spark... -
Page 24: Transporting Your Generator
DO NOT store in sealed area or at high temperatures. Doing so may lead to fuel becoming volatile and may cause an explosion. Avoid rough roads. If transporting on rough roads is necessary, drain the generator before use. Before storing you REDBACK Generator for long periods: • Ensure the storage area is dry and clean. -
Page 25: Troubleshooting
Remove the spark plug, then pour tablespoon of clean engine into the cylinder. Slowly pull the easy recoil pull start times until you feel pressure and then refit the spark plug. This will raise the pistons and help with compression stroke and prevent engine from rusting. - Page 26 Connected device doesn’t start Digital display shows ‘over’ Digital display shows 240v Return unit to dealer Check if device is faulty Shutdown after display shows ‘over’ and re-start the generator. Still shows ‘over’? -Replace your device -Have your device repaired Return unit to dealer DC socket doesn’t work Is the DC protection button...
- Page 27 Power shortage Is there a power shortage? Check the air filter DIRTY Check if petrol is deteriorated Clean or replace the air filter Change the petrol Return unit to dealer...
-
Page 28: Warranty
Pre-delivery set up, adding oil, connecting battery etc. Normal adjustments e.g. Idle speed adjustments. Any component not sold or manufactured by REDBACK. All consumables such as, wheels, spark plugs, filters, fuel lines, clamps, batteries, starter ropes, lubricants and periodic tune up services. -
Page 29: Warranty
Responsibilities of The Consumer Under This Warranty Deliver or ship the REDBACK product covered under this warranty to a nominated service agent. Freight costs, if any, to and from the nominated service agent will be paid by the owner. Use reasonable care in operation, and storage of the product as explained in the owner’s manuals.
