Liko Sabina II EE Instruction Manual

Sabina™ II
Sit-to-stand lift
Instruction Guide
Sabina II EE Prod. No. 2020003
SlingBar 350
Comfort SlingBar
The Sabina sit-to-stand lift is especially designed for people
who have difficulty in standing up on their own from a
seated position.
Sabina sit-to-stand lift is intended for use with patients
who are able to actively participate in the raising motion.
When standing, they can be moved to a wheelchair or to a
toilet; this gives them standing practice in connection with
the transfer.
There are two different sling bar options for Sabina sit-to-
stand lift, as well as many different sit-to-stand vests.
The patient's overall mobility determines the choice of
sling bar and sit-to-stand vest.
In this document, the person being lifted is referred to as the patient, and the person helping is referred to as the caregiver.
is a warning triangle used for situations which require extra care and attention.
IMPORTANT!
Read the instruction guide for both the patient lift and lifting accessories before use. Lifting and transferring a person always involves
a certain level of risk. It is important to completely understand the contents of the instruction guide. The equipment should be used
by trained personnel only. Please contact Hill-Rom in the event of any uncertainties or questions.
7EN155106 Rev. 1
ENGLISH
Product Description
The Sabina sit-to-stand lift equipped with the Comfort
SlingBar combined with the Liko ComfortVest provides an
especially gentle lifting action without putting pressure
under the arms. This combination is suitable for those who
are especially sensitive to pressure under the arms, such as
people who are paralyzed on one side.
Sabina sit-to-stand lift can also, to a limited extent, be used
for passive lifting of a patient sitting in a sling.
