6.3 Monthly Checks

6.3.1 Cleaning the scanner dust-proof glass

Conditions
Perform this maintenance operation with the power on.
Requirements
ï Blower brush
1.
Select the 240 lane of the film feed unit.
I
MPORTANT
ï If the 135 lane of the film advance unit is selected, it is necessary to select the 240 lane by following
the procedure below. If the 135 lane is selected, the film advance top cover cannot be opened fully.
(1)
Slightly open the front cover, then close it.
N
OTE
ï Closing the front cover selects the 240 lane of the film feed unit.
2.
Open the front cover and side cover (left).
Front cover
3.
Clean the dust-proof glass of the scanner with the blower brush, etc.
If dirt is hard to remove, wipe it off using cleaning cloth.
Front cover
Side cover (left)
6.3 Monthly Checks
G088421
G087613
6 ñ 7
