Zebra 4 FM Instruction Manual
4. Replacement Parts & Accessories
The following is a listing of replacement parts and
accessories available for the Laser radio series from your hobby dealer.
A. TX Antenna (#58005)
B. Neck strap (#58311)
C. Trainer cord (#58310)
D. Switch harness (#57215S)
E. Heavy duty gold pin switch harness (#54407)
F. Stick extensions (#56381)
G. Flight Preserver (#58480)
5. Precautions
- Always turn your transmitter on first and off last.
- Never fly your airplane without first performing a proper range check.
- FCC regulation in the USA prohibits consumers from changing the crystal in the transmitter.
For channel changes send your system to an authorized service/repair center.
- Never fly around or over houses, people or power lines.
- Always charge your batteries before you fly.
- It's a good idea to check your receiver batteries with a tester like the Hitec
Power Mate II (part# 44110). This will verify the charge level in your receiver batteries.
- Always fly responsibly and respect the rights of others.
- Make sure your frequency is clear before turning on your system.
Congratulations again and have fun!
Austria, Belgium, Denmark, Finland,
France, Germany, Greece, Iceland,
Ireland, The Netherland, Italy, Spain,
Norway, Portugal, United Kingdom,
Luxembourg, Sweden, Switzerland
Made in the Philippines
8
NEON 4 FM INSTRUCTION MANUAL
Instruction Manual
Advertisement
Table of Contents
Related Manuals for Zebra 4 FM
Summary of Contents for Zebra 4 FM
- Page 1 Zebra 4 FM Instruction Manual NEON 4 FM INSTRUCTION MANUAL 4. Replacement Parts & Accessories The following is a listing of replacement parts and accessories available for the Laser radio series from your hobby dealer. A. TX Antenna (#58005) B. Neck strap (#58311) C.
- Page 2 Thank you for purchasing the Zebra 4 FM digital proportional radio control system. 1. TRANSMITTER The Zebra 4 FM is easy to use and utilizes the latest in solid-state components for A. Features unsurpassed reliability and performance. It is important that you read and - Ergonomically designed 4 channel FM transmitter.
- Page 3 D. Servo Reversing the corrections were applied in the proper direction. - The Zebra 4 FM transmitter is equipped with servo reversing on all channels. - If you need to change travel direction of rotation, open the battery case and move the servo reversing switch.
- Page 4 If not, check your wiring or crystals if the servos do not move at all. - The Zebra 4 FM is equipped with a trainer system. (Slave mode only) - Use trainer cord. (Not included) Include the part number of the trainer cord for this radio system...
