- Page 1 MANUAL RH 136D RH 137D RH 330LD RH 340LD RH 341LD RH 355LD RH 356LD RH 360LD RH 361LD English Type H20 / 60 T.D. 05/98 821 2675 -11...
-
Page 2: Table Of Contents
INTRODUCTION FOR YOUR SAFETY 2.1 Warnings and Safety Advice 3 2.2 Coolants WARRANTY AND CUSTOMER SERVICE INSTALLATION 4.1 The Purpose of this Manual 4.2 Tools/Materials Required 4.3 Unpacking 4.4 Cleaning 4.5 Installation 4.6 Securing 4.7 Connecting the Device to the Electricity Supply 4.8 Changing the Sliding Hinge 4.9 Changing the Doorhang... -
Page 3: Introduction
INTRODUCTION You have made an excellent choice by choosing the Electrolux miniBar. We are convinced that you will be satisfied with your new appliance in every way. Silent in operation, the miniBar fulfils high quality standards and guarantees an efficient use of resources and energy during its entire working life, i.e. -
Page 4: Installation
INSTALLATION The Purpose of this Manual The manual shows you how to: install the miniBar correctly. Ÿ operate the miniBar correctly. Ÿ guarantee the miniBar´s correct maintenance and functioning. Ÿ deal with faults by yourself. Ÿ Tools / Materials Required You will need the following tools for initial operation: mild detergent Unpacking... -
Page 5: Installation
Installation The following illustrations (A,B,C,D) show four different ways for installing the miniBar. 1 = ventilation grid 2 = air going in 3 = air coming out Note: The ventilation grids (1) must have a clear cross section of at least 200cm Warning: Please take great care to observe the following points in order to... -
Page 6: Securing
Securing 4.6.1 RH356LDE 2. Put on cap. 1. Tighten screw. 4.6.2 RH136, RH137, RH330, RH340, RH341, RH360, RH361 The miniBar must be screwed onto the cupboard using the lower hinges. 1. Tighten screw. 2. Put on cap. 4.6.3 Old Version RH136, RH137 1. -
Page 7: Connecting The Device To The Electricity Supply
If the fuse cover-carrier is lost, a replaceement can be obtained from the Electrolux service Shops. The fuse cover/carrier must be of the same colour as that of the coloured insert in the base of the plug. -
Page 8: Changing The Sliding Hinge
If the plug supplied on the mains lead is not suitable for the socket in your home, it should be cut off and disposed of safely, or destroyed, to avoid any possible shock hazard resulting from the plug being inserted into a 13 amp socket elswhere in the use. -
Page 9: Changing The Doorhang
Changing the Doorhang ( RH136D, RH137D, RH330, RH340, RH341, RH 360, RH 361) -
Page 10: Instruction For Use
INSTRUCTION FOR USE Initial Operation The device must be plugged into a properly Ÿ earthed socket. The miniBar achieves its operating Ÿ temperature after several hours. The miniBar operates silently ! Temperature Control The miniBar is fitted with an electronic temperature control. -
Page 11: Automatic Door Control (Adc)
Automatic Door Control (ADC) The following descriptions only apply to devices with ADC. Using a red dot in the display window (A, point 3), the ADC shows that the miniBar´s door has been opened. 1. Open the miniBar, check its contents and - if applicable- stock it up again. -
Page 12: Interior Light
Changing bulbs: 1. Pull out the 2. Remove the 3. Remove defective mains plug. reflector disk. bulb. 4. Insert new bulb. 5. Clip reflector disk back in. To obtain spare bulbs, please contact your Electrolux Service Centre. -
Page 13: Environmental Advice
Enviromental Advice miniBars manufactured by Electrolux Siegen are free from CFCs and fluorinated hydrocarbons. The cooling unit uses ammonia as the coolant (a natural compound of hydrogen and nitrogen). Cyclopentane, which does not damage the ozone layer, is used as propellant for the insulation made from PU-foam. -
Page 14: Check List
5.11 Check List 1. Problem: No cooling (the aggregate at the back of the device is cold). Possible Cause Self Help Authorised Service a.) The thermostat is set to “0”. a.) Set temperature control to middle position. b.) The device plug is not b.) Plug in device plug. -
Page 15: Technical Data
5.12 Technical Data Model RH330LD RH340LD RH341LD RH355LD Built-in Built-in Freestanding / Freestanding Built-in Casing Metal Metal Metal Wood Gross Contentss (litres) cooled / uncooled 30 / - 40 / - 40 / - 35 / 20 Dimensions (mm) (H x W xD) 522x384x412 554x401x446 554x401x449... - Page 16 Electrolux GmbH In der Steinwiese 16 D-57074 Siegen Phone: +49-(0) 271 / 692 0 Fax: +49-(0) 271 / 692 300 www.electrolux.com/minibar...
