- Page 3 INTRODUCTION The Market Forge Direct Connected Steam Jacketed Kettle is a steam operated pressure vessel designed for cooking. It consists of a welded satin finish of stainless steel (type 304) kettle with double wall construction, forming a surrounding chamber around the kettle into which steam is introduced as a source of heat for cooking.
- Page 4 F-60L F-80L F-100L STATIONARY TRI-LEG JOB NAME: __________________________ ITEM NO.: ___________________________ DIRECT STEAM KETTLE NO. REQUIRED: ______________________ m F-20L m F-30L MODELS: m F-40L m F-60L m F-80L m F-100L STEAM FLOW REQUIREMENTS: 34 lbs. (15.5 kg) steam per hour or 1 BHP per 20 gallons...
- Page 5 F-20L F-30L F-40L F-60L F-80L F-100L STATIONARY TRI-LEG DETAILS & DIMENSION DIRECT STEAM KETTLE MODEL CAPACITY 20 Gallon inches 22.75 16.875 16.5 17.5 16.375 59.5 F-20L 76 liter 1041 1151 30 Gallon inches 25.75 14.875 12.75 16.5 42.5 20.5 14.375 62.5...
- Page 6 FT-20L FT-30L FT-40L FT-60L FT-80L FT-100L TILTING TRI-LEG JOB NAME: __________________________ ITEM NO.: ___________________________ DIRECT STEAM KETTLE NO. REQUIRED: ______________________ m FT- 20L m FT-60L MODELS: m FT-30L m FT-80L m FT-40L m FT-100L DESCRIPTION: Will be a Market Forge Direct Steam Connected Tilting Tri-leg Steam Jacketed Kettle.
- Page 7 FT-20L FT-30L FT-40L FT-60L FT-80L FT-100L TILTING TRI-LEG DETAILS & DIMENSION DIRECT STEAM KETTLE MODEL CAPACITY 20 Gallon inches 34.5 28.5 28.5 15.25 16.875 59.5 FT-20L 76 liter 1041 1512 30 Gallon inches 37.75 31.5 20.75 42.5 13.25 12.5 14.875 62.5 FT-30L 114 liter...
-
Page 8: Receiving And Installation
RECEIVING AND INSTALLATION RECEIVING: The kettle is shipped strapped and bolted to a skid and covered by a carton which is nailed to the skid. The packing materials must be carefully removed prior to installation. Inspect each unit. If any damage has been incurred during shipment, report same within two days to both the carrier and Market Forge Ind., Inc. -
Page 9: General Theory Of Operation
OPERATING INSTRUCTIONS GENERAL THEORY OF OPERATION: The Market Forge Series (F-20L, F-30L, F-40L, F-60L F-80L and F-100L) and (FT-20L, FT-30L, FT-40L, FT-60L FT-80L and FT-100L) kettles are tri-leg mounted, stainless steel jacketed kettles. The inner liner is jacketed by an outer shell which creates a space between the two walls and cooking is achieved by allowing steam flow within this space. -
Page 10: Inspection Checks
RETURN, CONDENSATE (STEAM TRAP ASSEMBLY - ERWEL) 97-5030 VALVE, STEAM CONTROL (DAHL) 97-5031 BRUSH, NYLON (NOT SHOWN) STRAINER, PERFORATED 97-5105 1.5" 97-5106 2" 97-5113 3" 97-5032 FOOT, FLANGE SHIPPING WEIGHTS MODEL: LBS.: F-20L F-30L F-40L F-60L F-80L F-100L FT-20L FT-30L FT-40L FT-60L FT-80L FT-100L... - Page 11 PARTS LIST STATIONARY KETTLE DIMENSIONS - FRONT VIEW F-20L - 21 [533] F-60L - 29.5 [749] F-30L - 24 [610] F-80L - 33 [838] F-40L - 26 [660] F-100L - 35.5 [802] F-20L - 59.5 [1151] F-30L - 62.5 [1588] F-40L - 63.5 [1613]...
- Page 12 PARTS LIST STATIONARY KETTLE DIMENSIONS - TOP VIEW WALL F-20L - 16.5 [419] F-30L - 16.5 [419] F-40L - 17 [432] F-60L - 19 [483] F-80L - 20.5 [521] F-100L - 22 [559] F-20L - 22.75 [578] F-30L - 25.75 [654] F-40L - 27.75 [705]...
- Page 13 PARTS LIST TILTING KETTLE DIMENSIONS - FRONT VIEW F-20L - 59.5 [1512] F-30L - 62.5 [1588] F-40L - 64 [1626] F-60L - 71.5 [1816] F-80L - 76 [1930] F-100L - 83 [2108] F-20L - 18 [457] F-30L - 20 [508] F-40L - 22.5 [572]...
- Page 14 PARTS LIST TILTING KETTLE DIMENSIONS - TOP VIEW F-20L - 28.5 [724] F-30L - 30 [762] F-40L - 32 [813] F-60L - 35.75 [910] F-80L - 40 [1016] F-100L - 42 [1066] fig. 3 (FT) TOP...
- Page 16 MODEL CAPACITY FT-20P 20 Gallon inches 21 22.75 11.75 15.5 18.75 13.5 59.5 17.25 76 liter 533 457 419 1511 FT-30P 30 Gallon inches 24 25.75 12.5 16.5 16.75 25.5 14.5 62.5 17.25 114 liter 610 508 368 1588 FT-40P 40 Gallon inches 26 22.5 27.75 12.5 17.5 14.25...
- Page 17 An Employee Owned Company...
- Page 18 MODEL CAPACITY 20 Gallon inches 33.75. 13.5 15.25 20.5 59.5 17.25 11.25 FT-20P 76 liter 1041 1511 30 Gallon inches 36.75 16.25 21.75 13.25 62.5 17.25 11.75 FT-30P 114 liter 1092 1587 40 Gallon inches 22.5 38.75 17.25 22.75 15.5 10.75 18.5 63.5...
