Generex CS141 Manual

CS141 SNMP / WEB / MODBUS MANAGER
Slot
Version
3
2
6
7
CS141SC
Description Function
1 COM1 Port Serial Interface to connect an UPS or another device with a original RS232 cable
To connect additional devices for example (GSM Modem, temperature and humidity sensor,
2 COM2 Port
SENSORMANAGER_II, Fieldbus devices (MODBUS RS232, Profibus, LONBus, etc.).
Available at CS141L, CS141SC, CS141MINI & CS141R_2 = RS232
Available at CS141LM & CS141SCM =RS485
(not equipped CS141BL, CS141BSC)
Ethernet 10/100 Mbit Interface with integrated status LEDs
3 LAN Port RJ 45
(green LED: Connection to network established, yellow LED: network traffic)
external device: supplied by a 12V switching adapter (delivered with the device)
4 DC Input
internal device: supplied via the slot interface of the device
5 AUX Equipped at CS141L, CS141LM, CS141SC and CS141SCM to connect CON_R_AUX4
and BACS etc.
Operation Status CS141
6 Status LEDs
Unpacking the operating system (update procedure)
(red / green)
Error while unpacking the operating system
Boot process of the operating system
Communication to external device lost (e. g. UPS)
Normal operation - connection to external device established
For switching between different boot options
7 Slide Switch
.
DIP Switch
Slide Switch in the middle position
CS141 in the configuration mode and activated the default IP address
10.10.10.10. after a cold start.
Slide Switch in the right position
DHCP Mode, the IP is set by the DHCP Server. Check the MAC address
of your device to identify your device in the network.
Slide Switch in the left position
The network settings of the HTTP interface are used it is also possible
to configure DHCP Mode.
8 USB
External
Version
3
2
6
5
8
1
4
7
5
CS141L
/ 1 + 2 position OFF: To set the
/ 1 position OFF + 2 position
/ 1 position ON + 2 position
3
6
2
CS141MINI
LED Notification
red blinking
red fast blinking
red long on
red and green
green blinking
ON:
OFF:
Version: 2017-11-23
7
