Your Work Never Looked Better

USER MANUAL

FOR YOUR SAFETY -------------------------------------------------- 1

SAFETY PRECAUTIONS -------------------------------------- 2

Before You Operate The Monitor ---------------------- 3

Features -------------------------------------------------------- 3

PACKING LIST --------------------------------------------------- 3

Installation Instructions --------------------------- 3

Controls And Connectors -------------------------- 4

Operating Instructions ------------------------------------- 5

General Instructions ---------------------------------- 5

How To Adjust A Setting ------------------------------ 6

Adjusting The Picture ---------------------------------- 7

Power Management Feature -----------------------

Plug And Play ------------------------------------------------ 9

Technical Support(Faq) -------------------------------------10

Appendix ---------------------------------------------------------------11

Specifications -------------------------------------------11-12

Factory Preset Timing Table ---------------------- 13

Connector Pin Assignment ------------------------- 13

Limited Three-Year Warranty ------------------------14-15

Thank you very much for choosing the AOC Color Monitor.

We recommend that you take a few minutes to read carefully through this

brief but comprehensive manual before installing and switching on the

4V/4Vlr

4VA/4VlrA

ENGLISH

DEUTSCH

FRANÇAI S

ESPAÑOL

ITALIANO

Table of Contents

Need help?

Do you have a question about the Spectrum series and is the answer not in the manual?

Questions and answers

Summary of Contents for AOC Spectrum series

Page 1 CONNECTOR PIN ASSIGNMENT ------------------------- 13 LIMITED THREE-YEAR WARRANTY ------------------------14-15 Thank you very much for choosing the AOC Color Monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the...
Page 2 Before operating the monitor please read this manual thoroughly. This Plug & Play Drivers for the AOC Spectrum Series Monitors are available manual should be retained for future reference. at AOC’s Web Site: www.aoc-europe.com FCC Class B Radio Frequency Interference Statement...
Page 3 To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.
Page 4 PRECAUTIONS l Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. l Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.
Page 5 BEFORE YOU OPERATE THE MONITOR FEATURES FEATURES • 35.5cm(14”) Color Monitor • Crisp, Clear Display for Windows • Supports Resolutions up to 1024 × 768 • Power Management • Ergonomic Design (MPR II Approved for 4Vlr/4VlrA) • Space Saving, Compact Case Design FEATURES CHECKING THE CONTENTS OF THE MONITOR PACKAGE The product package should include the following items:...
Page 6 POWER CORD Power Source: 1. Make sure the power cord is the correct type that required in your area. 2. This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area ( No user adjustment is required.
Page 7 2. Earphone (4VA/4VlrA only) 3. Audio In (4VA/4VlrA only)
Page 8 OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS The power switch is located at front panel of the monitor. Press the power switch to turn the monitor on or off. The other control knobs are located at the base of the monitor ( See Figure 3). By changing these settings, the picture can be adjusted to your personal preferences.
Page 9 NOTES • Do not install the monitor in a location near heat sources such as radiators or air ducts , or in a place subject to direct sunlight , or excessive dust or mechanical vibration or shock. • Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor.
Page 10 ADJUSTING THE PICTURE The description for function control LEDS CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H-SIZE Adjust the picture’s horizontal size. H-CENTER Adjust the horizontal position of the picture. V-SIZE Adjust the picture’s vertical size. V-CENTER Adjust the vertical position of the picture.
Page 11 • Suspend Mode When the V-sync signal from the computer is off, the monitor enters into Suspend Mode which reduces the power consumption to less than 15W. The screen becomes dark, and the power indicator turns to orange. From Suspend Mode, the screen reappears instantaneously when the keyboard or the mouse is touched again.
Page 12 PLUG AND PLAY Plug & Play DDC1/2B Feature This monitor is equipped with VESA DDC1/2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
Page 13 configuration. The other end terminates with a molded-on type connector female configuration. body, rated 10A, 250V, having standard CEE-22...
Page 14 *Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the AOC Monitor Drivers are installed (AOC Monitor Drivers are available at: www.aoc-europe.com) No picture *Computer Power Switch should be in the...
Page 15 BLUE) bent.
Page 16 APPENDIX SPECIFICATIONS 35.5cm(14"), 90º deflection, CRT Size 29mm neck Viewable Image 33.5cm (13.2"), diagonal Size Type 0.28mm dot pitch Video 0.7Vpp, R,G,B Analog Input Separate Sync. TTL Level H./V.- Sync. Positive / Negative Scanning H-Frequency 30kHz - 54kHz Frequency V-Frequency 50Hz-120Hz Max.
Page 17 • Switch Power On/Off switch • Up/Down Key • Function Key • External Controls: Functions Contrast • Brightness • H-Size • H-Center • V-Size • V-Center • Pincushion • Trapezoid • Volume (for 4VA/4VlrA only) Plug & Play DDC1/2B Power Management EPA, VESA DPMS Power Consumption ( Maximum ) 90 Watts...
Page 18 FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL RESOLUTION STANDARD FREQUENCY FREQUENCY 720 x 400 31.47kHz 70Hz 640 x 480 31.47kHz 60Hz VESA/85 640 x 480 43.3kHz 85Hz VESA/85 800 x 600 53.67kHz 85Hz VESA/60 1024 x 768 48.36kHz 60Hz CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable PIN NO.
Page 19 If the product appears to be defective, please contact your local dealer or refer to the warranty card when attached to the product. Deliver the product freight pre-paid, along with the dated proof of purchase, to the AOC Authorized Service Center. If you cannot deliver the product in person: •...
Page 20 THEORY, SHALL NOT EXCEED THE PRICE OF THE INDIVIDUAL UNIT WHOSE DEFECT OR DAMAGE IS THE BASIS OF THE CLAIM. IN NO EVENT SHALL AOC INTERNATIONAL (EUROPE) GMBH BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE OR FACILITIES OR EQUIPMENT, OR OTHER INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE.
Page 21: For Your Safety
CONNECTOR PIN ASSIGNMENT ------------------------- 13 LIMITED THREE-YEAR WARRANTY -----------------------14-15 Thank you very much for choosing the AOC Color Monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the...
Page 22 Before operating the monitor please read this manual thoroughly. This Plug & Play Drivers for the AOC Spectrum Series Monitors are available manual should be retained for future reference. at AOC’s Web Site: www.aoc-europe.com FCC Class B Radio Frequency Interference Statement...
Page 23 To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.
Page 24 PRECAUTIONS l Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. l Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.
Page 25: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES FEATURES • 38.1cm(15”) Color Monitor • Crisp, Clear Display for Windows • Supports Resolutions up to 1024 × 768 • Power Management • Ergonomic Design (MPR II Approved for 5Elr/5ElrA) • Space Saving, Compact Case Design FEATURES CHECKING THE CONTENTS OF THE MONITOR PACKAGE The product package should include the following items:...
Page 26: Controls And Connectors
POWER CORD Power Source: 4. Make sure the power cord is the correct type that required in your area. 5. This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area ( No user adjustment is required.
Page 27 2. Earphone (5EA/5ElrA only) 3. Audio In (5EA/5ElrA only)
Page 28: General Instructions
OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS The power switch is located at front panel of the monitor. Press the power switch to turn the monitor on or off. The other control knobs are located at the base of the monitor ( See Figure 3). By changing these settings, the picture can be adjusted to your personal preferences.
Page 29 NOTES • Do not install the monitor in a location near heat sources such as radiators or air ducts , or in a place subject to direct sunlight , or excessive dust or mechanical vibration or shock. • Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor.
Page 30: Power Management Feature
ADJUSTING THE PICTURE The description for function control LEDS CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H-SIZE Adjust the picture’s horizontal size. H-CENTER Adjust the horizontal position of the picture. V-SIZE Adjust the picture’s vertical size. V-CENTER Adjust the vertical position of the picture.
Page 31 • Suspend Mode When the V-sync signal from the computer is off, the monitor enters into Suspend Mode which reduces the power consumption to less than 15W. The screen becomes dark, and the power indicator turns to orange. From Suspend Mode, the screen reappears instantaneously when the keyboard or the mouse is touched again.
Page 32: Plug And Play
PLUG AND PLAY Plug & Play DDC1/2B Feature This monitor is equipped with VESA DDC1/2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
Page 33 configuration. The other end terminates with a molded-on type connector female configuration. body, rated 10A, 250V, having standard CEE-22...
Page 34 *Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the AOC Monitor Drivers are installed (AOC Monitor Drivers are available at: www.aoc-europe.com) No picture *Computer Power Switch should be in the...
Page 35 BLUE) bent.
Page 36: Appendix
APPENDIX SPECIFICATIONS 38.1cm(15"), 90º deflection, CRT Size 29mm neck Viewable Image 35.1cm (13.8"), diagonal Size Type 0.28mm dot pitch Video 0.7Vpp, R,G,B Analog Input Separate Sync. TTL Level H./V.- Sync. Positive / Negative Scanning H-Frequency 30kHz - 54kHz Frequency V-Frequency 50Hz-120Hz Max.
Page 37 • Switch Power On/Off switch • Up/Down Key • Function Key • External Controls: Functions Contrast • Brightness • H-Size • H-Center • V-Size • V-Center • Pincushion • Trapezoid • Volume (for 5EA/5ElrA only) Plug & Play DDC1/2B Power Management EPA, VESA DPMS Power Consumption ( Maximum ) 90 Watts...
Page 38: Factory Preset Timing Table
FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL RESOLUTION STANDARD FREQUENCY FREQUENCY 720 x 400 31.47kHz 70Hz 640 x 480 31.47kHz 60Hz VESA/85 640 x 480 43.3kHz 85Hz VESA/85 800 x 600 53.67kHz 85Hz VESA/60 1024 x 768 48.36kHz 60Hz CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable PIN NO.
Page 39: Limited Three-Year Warranty
If the product appears to be defective, please contact your local dealer or refer to the warranty card when attached to the product. Deliver the product freight pre-paid, along with the dated proof of purchase, to the AOC Authorized Service Center. If you cannot deliver the product in person: •...
Page 40 THEORY, SHALL NOT EXCEED THE PRICE OF THE INDIVIDUAL UNIT WHOSE DEFECT OR DAMAGE IS THE BASIS OF THE CLAIM. IN NO EVENT SHALL AOC INTERNATIONAL (EUROPE) GMBH BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE OR FACILITIES OR EQUIPMENT, OR OTHER INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE.
