Precision Products SW38PRE Owner's Manual And Parts List

38” tow behind lawn sweeper
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

SW38PRE - 38" Tow Behind Lawn Sweeper
PLEASE DO NOT RETURN THIS MERCHANDISE TO THE STORE. CALL US AND WE WILL TAKE CARE OF ANY
PROBLEM YOU MIGHT HAVE WITH THIS PRODUCT. Phone (800) 225 - 5891 EXT. #204
When ordering parts always give model
number, part description & part number.
Send To: Precision Products, Inc.
Parts Division
316 Limit Street
Lincoln, IL 62656
Owner's Manual and Parts List
Precision Products, Inc.
Customer Service & Warranty Information
Phone (217) 735-1590
Fax
(217) 735-2435
LIMITED WARRANTY
This unit is warranted against defects in materials and workmanship to the original
purchaser, under normal use and service, for a period of ninety (90) days from date
of sale. During the Warranty Period, we will repair or replace at our option free of
charge to the original purchaser, any part of the Unit that our examination shows to
be defective in workmanship or materials. This Warranty Does Not apply to damage
caused by misuse, abuse, neglect, accident, normal wear, or alterations by
unauthorized persons.
01/04
Parts list on back page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW38PRE and is the answer not in the manual?

Questions and answers

Related Manuals for Precision Products SW38PRE

Summary of Contents for Precision Products SW38PRE

  • Page 1 SW38PRE - 38” Tow Behind Lawn Sweeper Owner’s Manual and Parts List Precision Products, Inc. 01/04 Customer Service & Warranty Information Parts list on back page PLEASE DO NOT RETURN THIS MERCHANDISE TO THE STORE. CALL US AND WE WILL TAKE CARE OF ANY PROBLEM YOU MIGHT HAVE WITH THIS PRODUCT.

  • Page 2: Tools Required For Assembly

    Your new SW38PRE lawn sweeper is precision manufactured using the finest in tools and materials. Although it is ruggedly constructed, do not subject this unit to misuse. Be sure to wipe off your unit after each use. Store in a dry place out of direct sunlight.
  • Page 3 Fig. 1 NOTE: ALL REFERENCES TO “RIGHT” AND “LEFT” DIRECTIONS ARE IN REFERENCE TO POSITION BEHIND SWEEPER. Step 1 Sweeper Attach the Pivot Stand Brace (pre-attached to Sweeper Chassis) Chassis to the Sweeper Chassis using a 1/4” x 1-1/4” Bolt. Repeat this step for the other Pivot Stand Brace.
  • Page 4 Step 3 Fig. 6 Fig. 7 Attach both Hitch Arms together using one 5/16” x 3-1/4” Hex Head Bolt and FRONT 5/16” x 2-1/4” one 5/16” Lock Nut. Fig. 6 Do not tighten Hex Head Bolt this bolt yet. BACK 5/16” x 2-1/4” 5/16”...
  • Page 5 Fig. 11 Step 6 For Packaging purposes the Top Side Hamper Tubes (2 - one each side) are put on upside-down. Remove the nut on each end of the Tie Rod and re-attach the Top Side Hamper Tubes as shown Tie Rod in illustration.
  • Page 6 Fig. 15 Step 7 Insert the Hamper Dump Rope through center hole on the Sweeper Chassis Assembly. Next, lay the Hamper Dump Rope behind the sweeper. Fig. 15 Hamper Dump Rope Loosen the bolts holding both right and left Hamper Pivot Bracket Assemblies. Fig. 14 Install the Hamper Assembly onto the Pivot Frame Assembly.

  • Page 7: Operation

    OPERATION: Fig. 18 Brush Adjustment: Your new trailer-sweeper is equipped with a handy, “From Your Seat” brush Height Adjustment adjustment. To raise, push Height Adjustment Tube High Tube back and down until desired sweeping height is attained. To lower, push Height Adjustment Tube back and pull up to desired sweeping height (See Fig 18).
  • Page 8 Parts List for SW38PRE Ref # Part # Part Description Qty. Ref # Part # Part Description Qty. 3/8” Pilot Nut 1745 Height Adjustment Tube 1773 1746 Handle Grip RH Hamper Pivot Bracket 1774 1747 Caster Assembly Top Pivot Cross Tube...
