D-Sub Pin Assignments
PC 15-Pin mini D-Sub
Dimensions
40
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
177 mm/6
15
⁄
˝
16
Signal to be connected
Red
Green
Blue
GND
GND
Red GND
Green GND
Blue GND
No Connection
Digital GND
GND
SDA
Horizontal Sync
Vertical Sync
SCL
61 mm/2
48 mm/
1
7
⁄
˝
8
13
⁄
˝
32
11 mm/
7
⁄
˝
16
