Summary of Contents for VADO SENSORI SmartTouch
- Page 1 Digital Shower Controller User Guide Keep for future reference WHERE INSPIRATION FLOWS...
-
Page 2: Table Of Contents
Contents Important Information ................3 Digital Controller ..................4 Quick Start ....................5 Shower Operation ..................6 - Waking the Shower ................6 - Starting the Shower ................. 6 - Stopping the Shower ............... 6 - Cold Setting ..................6 - Adjusting the Showering Temperature .......... -
Page 3: Important Information
The Digital Mixer Processor unit MUST only be used with the AC power supply cable provided. If this supply cable is damaged, it must be replaced by a VADO engineer or similar qualified persons to avoid a potential hazard. This product can be used by children aged 8 years and above and... -
Page 4: Digital Controller
Digital Controller Single Outlet Product Display Screen Temperature Flow Volume Setting Outlet Icon Outlet Start/Stop Control Temperature Flow Increase Increase Temperature Flow Decrease Decrease Dual Outlet Product Display Screen Temperature Flow Volume Setting Outlet Icon 2 Outlet Icon 1 Outlet Flow 2 Outlet Start/Stop Control 1... -
Page 5: Quick Start
Quick Start Wake the shower from Start and stop the shower Change outlets using the Sleep Mode using the using the START/STOP corresponding OUTLET START/STOP control control controls NOTE: The available outlets will vary depending on the product configuration. Increase the showering Increase the water temperature using the flow using the... -
Page 6: Shower Operation
Shower Operation WAKING THE SHOWER If the shower has been inactive for a period of 3 minutes, it will return to Sleep Mode, in order to conserve electricity. To wake the shower from Sleep Mode, use the START/STOP control STARTING THE SHOWER To activate the shower with the default outlet running, use the START/STOP control Alternatively, to activate the shower with a specified outlet, use the corresponding OUTLET control... -
Page 7: Adjusting The Showering Temperature
Shower Operation ADJUSTING THE WATER TEMPERATURE Current The water temperature can be adjusted between 32°C and Temperature Setting the maximum showering temperature setting (47°C), in 1°C increments. The showering temperature is adjusted using the TEMP + and TEMP - controls. The maximum showering temperature is factory set to 47°C, but it can be restricted using the maximum temperature setting in the Configuration Mode (See page 9). -
Page 8: Selecting Outlets
Shower Operation SELECTING OUTLETS The available shower outlets will vary depending on the product configuration, as shown below. Outlet Control 1 Outlet Control 1 Outlet Control 2 Start/Stop Start/Stop Single Outlet Dual Outlet Product Product When starting from Sleep Mode, you can operate the shower with the default outlet running using the START/STOP control On subsequent uses, if the shower is restarted using the START/STOP control within 3 minutes of being stopped, it will restart with the last used outlet running. -
Page 9: Configuration Mode
Configuration Mode The Sensori Digital Mixer has many features that can be configured to personalise your showering experience, using the Configuration Mode. You can enter the Configuration Mode at any time by holding the TEMP + TEMP - controls together for 3 seconds. NAVIGATE THE CONFIGURATION MENU When in the configuration mode, a selection arrow is shown next to the... -
Page 10: Configuration Options
Configuration Mode MAXIMUM SHOWER TEMPERATURE This limits the outlet water temperature delivered to all outlets. It can be adjusted between 32°C and 47°C, in 1°C increments. Factory set to 47°C maximum. MAXIMUM SHOWER TIME When the maximum showering time is reached, the shower will automatically return to the Sleep Mode. - Page 11 Configuration Mode DEFAULT OUTLET When the shower is woken from Sleep Mode, it will start on the default outlet setting. If this setting is disabled, the shower will start at the last used setting. It can be set to any outlet of your choice. Factory set to outlet 1 as standard.
-
Page 12: Remote Start/Stop Operation
Remote Start/Stop Operation When the shower is in Sleep/Standby mode: Press the remote button once to activate outlet 1. Press the remote button twice to activate outlet 2*. Once the shower is running: Press the remote button once to select outlet 1 On/Off. Press the remote button twice to select outlet 2 On/Off. - Page 13 VADO Identity and i-tech products have a 5 year guarantee (2 year parts and labour plus 3 years parts only). All other VADO products have a 3 year guarantee (2 years parts and labour plus 1 year parts only) [SEE NOTE 2].
- Page 16 MY SHOWER IS NOT WORKING, WHAT DO I DO? 01934 745163...
