Whirlpool WIN852 GS Service Manual

Top mount no frost refrigerator, 220l graphite
Hide thumbs

Advertisement

Quick Links

WHIRLPOOL OF INDIA LTD
Service Manual
Top Mount
No Frost Refrigerator
1

Advertisement

loading

Related Manuals for Whirlpool WIN852 GS

Summary of Contents for Whirlpool WIN852 GS

  • Page 1 WHIRLPOOL OF INDIA LTD Service Manual Top Mount No Frost Refrigerator...

  • Page 2: Table Of Contents

    INDEX Sno. Detail Page No. MODEL RANGE SAFETY PRECAUTIONS FEATURE/ TECHNICAL SPECIFICATION GENX CONTROL CONFIGURATION COOLING CONTROL WIRING DIAGRAM EXPLODED VIEWS SERVICE PART LIST...

  • Page 3: Model Range

    NO FROST REFRIGERATOR MODEL RANGE: 220L GRAPHITE – WIN852 GS...

  • Page 6: Feature/ Technical Specification

    TECHNICAL /FEATURE SPECIFICATION: MODEL 220L Type Frost free Capacities (L) total net 220L Product Dimensions (mm) Width Height 1441 Depth Gross Weight (kg) 54Kg Voltage / Hz 220-240V/60Hz Compressor ASD65 Oil Capacity 180 cu.cm Comp. Run Capacitor PTC Relay QP2-15G Motor Protector BT60-120Y Fan motor...

  • Page 7: Genx Control Configuration

    GENX CONTROLS CONFIGURATION: GENX Controls Configuration Product Configuration 220L Product Control RC Controlled RC Illumination Yes(Lamp) Control Board Defrost heater Yes (Radiant Heater 180 W) Fan motor FAN MOTOR MI Compressor ASD65 Run Capacitor Door Reversibility...

  • Page 8: Cooling Control

    Cooling control: Adaptive Defrost Control The defrost cycle shall be started after the Defrost timer has expired. According to the following defrost procedure: Defrost must be executed every time one of the following event occurs: 1. After 8 hours (+/-10 minutes) of compressor running, calculated considering just the thermostat function. 2.

  • Page 9: Wiring Diagram

    WIRING DIAGRAM:...

  • Page 10: Exploded Views

    EXPLODED VIEWS:...

  • Page 14: Service Part List

    SERVICE PART LIST: MODEL PART NO. DESCRIPTION 220L WIN 852 GS W10415631 OIL CHARGED COMPRESSOR ASSEMBLY ASD65 1 EA W10585346 FC FOAMED DOOR BASF GRAPHITE -220L/250L 1 EA GASKET DOOR - FC, OPERA PROFILE 1 EA A211453000A SLEEVE- HINGE 1 EA A2010870000 W10585341 RC FOAMED DOOR BASF GRAPHITE-SURGE,220L...
  • Page 15 GROMMET SOUND DEADENING- FRONT 2 EA A201637000A GROMMET SOUND DEADENING- BACK 2 EA A2016380000 SCREW- HEX WASHER HEAD 2 EA A201670000A W10487839 ICE COLLECTOR, NEO 1 EA W10479967 ICE TWISTER SUB ASSY WITH GRAPHICS 1 EA FC GRILL FRAS 1 EA A208546000E DAMPER FREEZER CONTROL,G4G- 220L BLUE 1 EA...
  • Page 16 W10429122 Plenum Front GNF With New Graphics 1 EA W10595056 AIR DIFFUSER ASSY SURGE -220L 1 EA W10536639 CRISPER M0 GENX2(GARDEN FRESH) 1 EA W10407007 TRIVET RC TOP OPAL W/O GRAPHICS 1 EA W10407008 TRIVET BOTTLES OPAL W/O GRAPHICS 2 EA W10413270 THERMOSTAT GNF-220L/240L 1 EA...
